Add EMAG to your IMTS show planner HERE.
FARMINGTON HILLS, MI – At IMTS 2014, EMAG will feature Manufacturing Systems for Precision Metal Components with multiple machines from its new modular standard VL and VT product families on display. These Modular Standard Machines offer a systematic approach that is advantageous to establishing a highly efficient manufacturing process, with different operations offered on the same platform allowing for easy interlinking and eliminating any great outlay for automation.
The VL 2 Vertical Turning Machine from EMAG is designed for the quality- and cost-conscious manufacturer and sub-supplier: a universal production aid that impresses with its small footprint and advantageous price-performance ratio – automatic workhandling included.
The VL vertical pick-up lathe series opens up new opportunities for the machining of a wide range of chucked components. Small gearwheels, planetary gears, sun gears, sliding sleeves synchronizer rings or flange components, for example, can be machined with great efficiency. The smallest lathe of the VL product family, the VL 2, machines workpieces with a maximum diameter of four inches and a length of up to six inches. Increasing in size, the VL 4, VL 6 and VL 8 offer a number of different turning and milling operations within the framework of a single closed-loop production process. Specially designed for the handling of large components the largest vertical turning machine of the series, the VL 8, ideal for commercial vehicle production, handles workpieces up to 16 inches in diameter and 12 inches in length.
Built within the same modular concept is the VT-Series for machining large quantities of shaft components. With four axes, a self-loading turret and integrated automation, the VT 2-4 machines shafts with a max diameter of 2.5 inches and 16 inches in length. Spindle speeds of up to 6,000 rpm achieve extremely short cycle times as the shaft is clamped vertically between workspindle and tailstock and machined from two sides. The vertical alignment of the workpiece ensures process integrity, where the unhindered chip flow prevents the build-up of chip nests in the machining area.
Machining area of the VL 2: 12 turning or, alternatively, up to 12 driven drilling and milling tools can be employed to carry out a large number of operations in a single setup. The machine can also be equipped with an optional Y-axis.
All machines of the VL and VT product families offer the same advantages for every size workpiece:
The VLC 200 H is designed for the machining of gear-type workpieces of maximum 200 mm diameter and module 4.
Integrating the technologies of the EMAG Group into these new modular standards, the VLC 200 H will make its North American debut at the McCormick Center. The VLC 200 H hobbing machine integrates EMAG-KOEPFER technology into the EMAG vertical platform, including the pick-up design where the main spindle removes the raw part from the conveyor belt, transfers it to the tailstock flange and removes it from the machining area after the completion of the hobbing cycle. Gears with a maximum diameter of 8 inches and module 4 can be dry-milled at greatly shortened cycle times.
Machining area of an EMAG PO 900 BF for the machining of blisks using Precise Electro-Chemical Machining (PECM) technology.
EMAG will also present its entire portfolio of production technologies, from turning, hobbing and grinding to those that complement traditional metalworking processes, such as its production Laser Welding, Heat Shrink Technology and Electro-Chemical Machining (ECM) capabilities. ECM processes offer non-contact machining with no heat affected zone or mechanical stress to components with no tool wear. An ECM machined blisk will also be on display.
EMAG invites manufacturers to visit them at booth N-6846 to meet with technology experts to discuss production solutions for the automotive and commercial vehicle, aerospace, and oilfield industries. For more information on the entire EMAG Group portfolio, visit www.emag.com
Add EMAG to your IMTS show planner HERE.
For more information on this information, please contact:
Kristal Kilgore
EMAG LLC
38800 Grand River Avenue
Farmington Hills, MI 48335
Tel: (248) 875-0313
Fax: (248) 477-7784
E-mail: kkilgore@emag.com
Web: www.emag.com
BOOTH E-5010: Click here to add Siemens to your IMTS Show Planner!
Siemens SINUMERIK Family
From the job shop to the retrofit operation, moldmakers to mass production departments at the world’s leading auto, aero and medical manufacturers, Siemens continues to push the envelope on CNC technology. With the introduction of the Sinumerik 808D at IMTS in 2012, we took a bold step into the job shop world, as this basic CNC brings the power, flexibility and reliable performance of Siemens technology to the job shop. Already accepted as an OEM component by numerous mill and lathe builders, the 808D provides job shops the unique opportunity to apply advanced and unmatched CNC power to their existing machines, breathing “new life into old iron,” as the saying goes.
The 808D rounds out the growing family of CNC models from Siemens, which now spans the range from the most basic 3-axis machines to dedicated milling and turning center controls in the Sinumerik 828D to CNC for the most advanced five-axis machining centers, with full robotic integration, secondary ops management and transfer line capability, all on a single control, the Sinumerik 840D sl solution line, still the benchmark by which all other CNC technology in the market is judged. Simply put, nobody matches the muscle of Siemens. Come to booth E-5010 and see the difference. Productivity in Motion!
For more information about Siemens CNC solutions for the machine tool industry, visit the website: www.usa.siemens.com/cnc.
Please forward all inquiries to:
SIEMENS INDUSTRY, INC.
DRIVE TECHNOLOGIES
MOTION CONTROL
MACHINE TOOL BUSINESS
390 Kent Avenue
Elk Grove Village, IL 60007
Phone: 847-640-1595
Fax: 847-437-0784
Web: www.usa.siemens.com/cnc
Email: SiemensMTBUMarCom.sea@siemens.com
Attention: John Meyer, Manager, Marketing Communication
Follow us on Facebook: www.facebook.com/SiemensCNC or Twitter: www.twitter.com/siemens_cnc_us.
—
Siemens Industry Sector is the world’s leading supplier of innovative and environmentally friendly products, solutions and services for industrial customers. With end-to-end automation technology and industrial software, solid vertical-market expertise, and technology-based services, the sector enhances its customers’ productivity, efficiency and flexibility. With a global workforce of more than 100,000 employees, the Industry Sector comprises the Industry Automation, Drive Technologies and Customer Services Divisions as well as the Metals Technologies Business Unit. For more information, visit http://www.usa.siemens.com/industry.
The Siemens Drive Technologies Division is the world’s leading supplier of products, systems, applications, solutions and services for the entire drive train, with electrical and mechanical components. Drive Technologies serves all vertical markets in the production and process industries as well as the infrastructure/energy segment. With its products and solutions, the division enables its customers to achieve productivity, energy efficiency and reliability. For more information, visit http://www.usa.siemens.com/drivetechnologies.
Continue readingAdvanced Machine & Engineering Co. (AME) will be exhibiting their machine tool component products in both the East and West buildings this year at IMTS 2014. In the West building, at booth W-2405, they will be showing their fixturing product lines under the Amrok brand name, which consists of the following products:
• Amrok Epoxy-mineral Tombstones
• Amrok Cast Iron Tombstones
• Triag Modular Workholding
• Jakob Clamping
Amrok Epoxy Tombstone
Click here to add AME to your IMTS Show Planner!
In the East building, at booth E-5718, they will be showing the remainder of their product lines consisting of the following products:
• Amlok Rod Locks
• Ott-jakob Power Drawbars
• Stotz Air Gaging
• Spieth, Ambush & Amdisk Precision Components
• Ott Gears
• Sitema Press Safety
• Amsaw Carbide Production Saws
Click here to add AME to your IMTS Show Planner!
Also see their sister company Hennig Inc. for machine protection products at booth E-5610.
Click here to add Hennig to your IMTS Show Planner!
For more information, visit www.ame.com or contact:
Tim Waterman
ADVANCED MACHINE & ENGINEERING CO.
2500 Latham St.
Rockford, IL 61103
Phone: 815-316-5277
Fax: 815-962-6483
E-mail: info@ame.com
Connect with AME online:
Hennig Inc. will be exhibiting their machine protection products at IMTS 2014. In the East building, at booth E-5610, they will be showing the following products:
• Chip Conveyors
• Chip Disc Filtration (CDF) Systems
• Telescopic Steel Covers
• Folded Bellows
• Flex-Protect Systems
• Machine Enclosures
• Roll-up & Flexible Apron Covers
• Wiper Systems
• XYZ-Modules
Hennig Chip Conveyor
Click here to add Hennig to your IMTS Show Planner!
Also see their sister company, Advanced Machine & Engineering Co., at booths W-2405 and E-5718 for machine tool component products.
Click here to add AME to your IMTS Show Planner!
For more information contact:
Tim Waterman
Hennig Inc.
9900 N. Alpine Rd.
Machesney Park, IL 61115
(815) 316-5277
info@hennig.ame.com
www.hennigworldwide.com
Connect with Hennig online:
Leading supplier of quenchants to commercial and captive heat treaters will also display assortment of Chemtool lubricants and greases for the industry
Photo courtesy of Scot Forge
Pioneers in the development of polymer quenchants back in the 1960’s, Tenaxol, part of the Chemtool family of companies in Rockton, Illinois, will demonstrate its comprehensive line of UCON® brand polymer quenchants at this year’s Furnaces North America show, being held October 6-8 in Nashville, Tennessee. Tenaxol will be located in Booths 300-302 at the show.
Photo courtesy of Scot Forge
Polymer quenchants were developed by Ross Blackwood, the founder of Tenaxol, in the early 1960’s and the first UCON® products were patented in 1965 as a safe alternative to oil quenching, owing to their unique polyalkylene glycol chemistry plus corrosion inhibitors. The products also yield superior surface integrity on all ferrous and non-ferrous metals, when compared to water quenching, especially in the areas of thermal cracking and distortion. UCON® brand polymer quenchants have become the industry standard over the years and the full range of products today includes UCON® ULTRAQUENCH PLUS, featuring advanced anti-microbial protection and enhanced foam control, plus a non-nitrite corrosion inhibitor for improved surface protection. Additionally, UCON® ULTRAQUENCH RL PLUS is an ideal solution for quenching medium high-carbon steels and most alloyed grades, including 300 and 400 Series stainless.
Chemtool is a global leader in the formulation and supply of various lubricants, cleaning agents, cutting fluids for metalworking machinery and other solutions for a wide variety of industrial applications.nThe company is also a major private label supplier to the distribution channels at many of the giants in the off-highway and other machinery markets.
During the show, Tenaxol personnel will be available to discuss all quenchant applications and metallurgical quench conditions.
Tenaxol has factory sales based in the Rockton, Illinois headquarters, near Chicago, plus manufacturers’ representative offices in strategically located cities throughout North America.
For more information, please contact:
TENAXOL TECHNOLOGIES
A Chemtool Company
801 West Rockton Road
Rockton, IL 61072
Phone: 815-957-4140
Web: www.chemtool.com
Email: sales@chemtool.com
Attention: Jim Harrison
Major manufacturer of tube and bar processing machinery Rattunde today announced the appointment of the following individuals to new positions at the company, based in Caledonia, Michigan, near Grand Rapids. This announcement was made by company president Rick Stadler.
The new staffers include:
Chad Luptowski- Control System Technician
Chad has been a member of the IBEW (International Brotherhood of Electrical Workers) for 10 years and is also a Certified Master Electrician. Chad will be training new and current customers as well as commissioning new machines in the field. His other duties will include handling the customer help line and assisting the service team.
Janelle Crum- Project Coordinator
Janelle was brought onboard to fill a wide spectrum of duties. She will be responsible for pre- and post-sales communications between customers and internal resources, plus the planning and scheduling of machine installations. Janelle was an executive assistant for the past 3 years and has spent time in both inside and outside sales.
Will Richards- Associate of Business Development
Will was hired by Rattunde to handle multiple functions. His primary duty will be to help maintain the Rattunde customer relationships that have been generated over the last 8 years in North America. A further reason he was hired is to help with market research, assisting Rattunde in its expansion into new markets. A third area of responsibility will be marketing. Will has a sales background, having worked the last 9 years in the automotive industry, selling components.
Carlos Galan- Order Fulfillment Agent
Carlos, who is fluent in Spanish, was hired for inside sales to support the Mexican and Latin American markets Rattunde currently sells and seeks to develop further. Carlos is responsible for quoting and fulfilling tooling and spare part orders for all North American customers, with special emphasis on the Mexican and Latin American companies. Carlos was previously in logistics.
For more information on this development, please contact:
RATTUNDE CORPORATION
4980 Kendrick Street SE
Grand Rapids, Michigan 49512
Phone: 616-940-3340
Fax: 616-940-2771
Web: www.rattunde-corp.com
Email: company@rattunde-corp.com
Attention: Richard Stadler or Alec Banish
No. 957 is a 300ºF, electrically-heated vertical conveyor oven from Grieve, currently used for curing potting compounds at the customer’s facility. Workspace dimensions of this oven measure 36” W x 38” D x 92” H. 20 KW installed in Incoloy-sheathed tubular elements heat the oven chamber, while a 4200 CFM, 3-HP recirculating blower provides vertical upward airflow to the workload.
This Grieve vertical conveyor oven features 4” insulated walls, top-mounted heating chamber, aluminized steel interior and exterior, air-operated lift door at the loading/unloading position, two access doors for the heating chamber and floor of the workspace plus eleven workload trays, each 30” wide by 14” long, supported on each side by heavy-duty roller chain driven by a ½-HP motor controlled by a variable frequency drive.
The oven is built to JIC/NEMA 12 electrical standards. Controls on No. 957 include a digital indicating temperature controller, manual reset excess temperature controller with separate contactors, recirculating blower airflow safety switch and a tower light to indicate oven status.
For more information, please contact:
THE GRIEVE CORPORATION
500 Hart Road
Round Lake, IL 60073-2898
Phone: (847) 546-8225
Fax: (847) 546-9210
Web: www.grievecorp.com
Email: sales@grievecorp.com
Attention: Frank Calabrese, VP
Ann Arbor, Michigan – GMTA (German Machine Tools of America) represents various top-quality German metalworking machine builders, including Profilator, Pittler, Praewema and WMZ. These machines are sold to the North American market by GMTA primarily for gear and spline production, as well as other power transmission applications. The company’s target markets include automotive, off-highway, OCTG and other heavy equipment manufacturing. Machines are provided for gear honing, gear grinding, the patented Scudding® process for gearmaking, polygon milling, turning, gear tooth pointing and multi-task machining operations.
In the news…
-Effective immediately for North America, GMTA now represents two additional lines of quality German machines. Agreements have been finalized for GMTA to handle the Rosink line of parts washers plus the Arnold line of laser welding machines. According to Scott Knoy, VP at GMTA, “These are natural complements to our existing lines and will strengthen our value proposition in current and also new market segments, going forward.” A Rosink parts washer will be on display in the GMTA booth during the upcoming IMTS in Chicago.
-GMTA proudly announces the sale of multiple Profilator Scudding® machines to General Motors for gear production. It is estimated this purchase saved GM over $4 million in capital expenditures, compared with acquiring the multiple machines that would have been necessary to achieve the same production levels.
-GMTA also announces the sale of Profilator Scudding® and gear pointing machines to Magna Mexico, plus machines to Magna Canada for polygon generation.
-GMTA has sold nine (9) Praewema honing machines to Ford.
Claudia Hambleton, GMTA administrative manager and corporate treasurer, at her MBA graduation ceremony at Eastern Michigan University in Ypsilanti
-Last but not least, by any means, GMTA proudly announces Claudia Hambleton, corporate treasurer and administrative manager, received her MBA from Eastern Michigan University (EMU) on April 27, 2014. Claudia has been a GMTA associate since the company opened its doors in January, 1991. As Claudia notes, “I am very grateful to GMTA for supporting my efforts to acquire an MBA. I look forward to using my new skills to further enhance the business at our company. It was also very rewarding to network with the business school students and staff at EMU, where GMTA now has a working relationship with their German business development track.” GMTA routinely hosts a program in German for students in the EMU business school who plan to work for or with German companies as a career path.
For more information on this announcement, please contact:
GMTA (GERMAN MACHINE TOOLS OF AMERICA)
4630 Freedom Drive
Ann Arbor, MI 48108
Phone: 734-973-7800
Fax: 734-973-3053
Web: www.gmtamerica.com
Email: scott@gmtamerica.com
Attention: Scott Knoy
Connect with GMTA online:
American Gear Manufacturers Association presents achievement award at 2014 annual meeting in St. Petersburg, Florida
Scott Knoy receives the prestigious Next Generation award from Lou Ertel, Chairman of Overton Chicago Gear and also current Chairman of the Board of Directors for AGMA at the 2014 AGMA annual meeting in Orlando, Florida
Ann Arbor, Michigan– German Machine Tools of America (GMTA, formerly American Wera) proudly announces the winning of the prestigious Next Generation award from the American Gear Manufacturers Association by its vice president Scott Knoy. The award was presented at the association’s recent annual meeting on April 11, 2014 at the Vinoy Renaissance Resort in St. Petersburg, Florida.
The Next Generation award from AGMA “honors individuals who, while early in their career, are emerging as contributors, innovators and/or leaders in the gear industry and who serve as role models for others in the next generation of the gear industry,” according to the AGMA Awards Committee
The Next Generation award, in the words of the AGMA Awards Committee, “honors individuals who, while early in their career, are emerging as contributors, innovators and/or leaders in the gear industry and who serve as role models for others in the next generation of the gear industry.” Knoy has been active in service to the gear industry for 20 years, serving first for 11 years with major machine tool supplier Gleason and now in his ninth year with GMTA, where he oversees the sales, strategic planning, project management and marketing efforts for this major supplier of machinery to the gear, powertrain and other industries. In addition, along with company president Walter Friedrich, he spearheads the ongoing effort at GMTA to educate and nurture the next generation of leaders in the gear industry, an endeavor to which the company has a great commitment. GMTA supports local schools in their tech training and also Eastern Michigan University in its unique “business in a second language” program.
Scott and his wife Holly Knoy at the event
According to the AGMA website recap of the event, “Scott Knoy grew up in the industry with his father, Jerry Knoy, working at the Gleason Corporation and followed in his father’s footsetps, joining Gleason Cutting Tools. Scott began his career with Gleason as a regional sales manager, where he was the key contact for clients such as TRW, Ford Motor Company, General Motors, Dana Corporation, Parker-Hannifin and General Electric. Following his time at Gleason, Scott joined German Machine Tools of America (then American Wera), where he now serves as GMTA Vice President of Sales and Marketing. He is active with the AGMA Strategic Resources Network and has been attending the Annual Meeting, Gear Expo and other AGMA activities for many years.”
For more information on this announcement, please contact:
GMTA (GERMAN MACHINE TOOLS OF AMERICA)
4630 Freedom Drive
Ann Arbor, MI 48108
Phone: 734-973-7800
Fax: 734-973-3053
Web: www.gmtamerica.com
Email: scott@gmtamerica.com
Attention: Scott Knoy
Connect with GMTA online:
No. 864 is a 350ºF, natural gas-heated belt conveyor oven from Grieve, currently used for drying gold ore samples at the customer’s facility. Workspace dimensions of this oven measure 6-1/2’ W x 35’ D x 1-1/2’ H. 1,650,000 BTU are installed in a modulating natural gas burner to heat the oven chamber, while a 24,500 CFM, 20 HP recirculating blower provides vertical downward airflow to the workload.
This Grieve oven features a 5’ long open belt loading zone, 35’ long insulated heat zone with recirculated airflow and 1’ long open belt unloading zone, plus 4” insulated walls, aluminized steel interior and exterior. A 6’ wide, 1” x 1” galvanized steel, flat wire conveyor belt with ¼ HP motor drive, variable from 5 to 50 feet per hour, transports the workload. Side access doors are provided along the length of the workspace to inspect the load and service the heating chamber.
All safety equipment required by IRI, FM and NFPA Standard 86 for gas-heated equipment are provided on this belt conveyor oven, including a 1500 CFM, 2 HP powered forced exhauster.
Controls on No. 864 include a conveyor belt start/stop, digital indicating current proportioning temperature controller, manual reset excess temperature controller, variable SCR drive to control conveyor belt speed, pilot lights to indicate when blower and heat are energized, pushbutton electronic ignition, on-off heat switch and main oven control pushbuttons. The NEMA 12 control panel is equipped with a lockable fused disconnect switch.
For more information, please contact:
THE GRIEVE CORPORATION
500 Hart Road
Round Lake, IL 60073-2898
Phone: (847) 546-8225
Fax: (847) 546-9210
Web: www.grievecorp.com
Email: sales@grievecorp.com
Attention: Frank Calabrese, VP
