Siemens Offers New 230V, Single- and 3-Phase AC Power Modules for its Sinamics G120 Drives

A new line of PM240-2 power modules is now available from Siemens, extending the use of the popular Sinamics G120 drives family.  A significant change is the addition of 230V single- and three-phase line supply units featuring quick-connect pull-off terminals on the motor, line supply and braking resistor connections allowing the new PM240-2 to offer an even more simplified installation and maintenance.  In addition, these new power modules can be mounted side-by-side without derating.

PM240-2 power modules are now available from Siemens for use with Sinamics G120 drives.  Various mounting, frame and power rating sizes now offered from stock.

PM240-2 power modules are now available from Siemens for use with Sinamics G120 drives. Various mounting, frame and power rating sizes now offered from stock.

All versions of the new PM240-2 power modules are rated IP20.  However, an optional push-through version is available allowing the heat sink to extend out the backside of the cabinet.  The seal for the push-through heat-sink will maintain and enclosure rating of IP55 (NEMA 12).  As a result, the new PM240-2 power modules will reduce the overall required cabinet size and cabinet cooling requirements.

Among the unique, new features of the PM240-2 power modules is the variable speed cooling fan, controllable to run based upon actual conditions vs. simple on / off operation, thereby reducing both the noise generated and the power required when
in use.

The PM240-2 power modules are suitable for use with general-purpose and servo-drive styles.  Options on these PM240-2 power modules include braking resistors, input reactors and output reactors.

For more information about this new line of power modules, please visit:  www.usa.siemens.com/sinamics-g120.

For specific product information and inquiries, call (800) 879-8079 ext. Marketing Communications or send an e-mail to: SiemensMTBUMarCom.industry@siemens.com.



Continue reading
