ANCA’s newest ULTRA machine makes micro tool grinding easier, more precise and more productive as the only nano-level resolution micro tool grinder
ANCA CNC Machines, a leading manufacturer of precision grinding machines, have launched the highly anticipated MicroX ULTRA.
This innovative six-axes grinding machine is meticulously designed for volume production of nano and micro cutting tools down to D0.03mm. Offering a superior solution for manufacturing high-quality, high-performance micro cutting tools, the MicroX ULTRA introduces groundbreaking technologies exclusive to the cutting tool industry.
The brain behind the machine is Pat McCluskey, a passionate machine tool designer, who is this year celebrating the 50th anniversary of ANCA, the company he co-founded with Pat Boland in 1974.
Pat McCluskey remarked, “I have been designing ANCA machines for 50 years – always with the goal of making machines better, more efficient, and user-friendly. It is a trademark of ANCA that you just have to do it differently, and the latest machine, the MicroX ULTRA, is the only micro tool grinder with nanometer resolution. This nano-level precision is a significant advancement in the field, utilizing the very best of ANCA’s technology developed over five decades to offer superior micro tool production.”
Key features of the MicroX ULTRA:
With nanometer resolution and control over the tool grinding path, the MicroX ULTRA delivers a high level of surface and edge quality. This achievement is made possible through intelligent algorithms that operate collaboratively and in synchrony.
The C-axis refers to the wheel swivel axis centerline, which is aligned with the wheel’s 9 o’clock grind point. This specific design is critical in the grinding of ballnose, corner radius and profile tools. In the case of a ballnose tool, the X and Y interpolations during the grinding process will be nearly equal to the radius of the ballnose tool.
Advanced algorithms ensure precise nanometer-level control of tool grinding paths, guaranteeing superior surface and edge quality. These algorithms collaborate and synchronize to reject disturbances swiftly, enhancing axis stiffness and robustness. They actively mitigate disturbances from spindle speed variations caused by imbalanced or runout grinding wheels. Encoder subdivision error compensation automatically detects and corrects inherent encoder errors on both linear and rotary encoders.
The LaserUltra takes process stability to an even higher level by closely controlling tolerances and incorporating in-process compensation mechanisms. This advanced system adapts to factors like wheel wear, resulting in superior precision and reliability.
Seamless integration with ANCA Integrated Manufacturing System (AIMS) facilitates effortless transition to automated, lights-out production, enhancing operational efficiency and productivity.
For more information, visit https://machines.anca.com/MicroX
For further information, please contact:
Amanda Bakun
Marketing & Communications Manager – Americas
248-497-1168
amanda.bakun@anca.com
ANCA is a market leading manufacturer of CNC grinding machines. It was founded in 1974 in Melbourne, Australia where the company still has its global headquarters. ANCA has offices in the UK, Germany, China, Thailand, India, Japan, Brazil, Korea and the USA as well as a comprehensive network of representatives and agents worldwide.
ANCA CNC grinders are used for manufacturing precision cutting tools and components across a diverse range of competitive industries including cutting tool manufacture, automotive, aerospace, electronics and medical.
Continue reading
Bringing together a number of its hardware automation, digitalization software and services, Siemens will present the new path towards digitalization for machine tool users and machine builders
At the upcoming IMTS 2024 in Chicago, September 9–14, Siemens will present its extensive machine tool CNC portfolio and digitalization software technology, highlighted by the digital native SINUMERIK ONE control platform for machining applications. Also, using a sports theme of “Speed, Agility and Endurance,” aimed at the machine shop on its path to digitalization, Siemens will introduce MACHINUM to the North American market. MACHINUM brings together machine tool controls, digitalization software and machine shop services from Siemens to help manufacturers optimize their production processes, to provide agility for quick adaptation to changing customer requirements and calculated uptime needs, plus enable digitally proven endurance to maximize the productivity of the entire machine shop or production department.
Detailing the elements of MACHINUM:
Speed
Siemens adaptive feedrate control reduces cycle times, while maintaining a stable machining process. This results from instantaneous and continuous analysis of the current cutting conditions on a machine tool in real time, automatically optimizing the feedrate.
Agility
Through strategic digitalization and software that seamlessly integrates the machine tool CNC systems and a shop’s internal communications, MACHINUM can significantly boost the agility of a machine shop or production department to accommodate changes in design, quantity output and even machining characteristics, based upon customer input and overall production and workflow landscape characteristics.
Endurance
Continuing the sports theme, over the long “run”, MACHINUM enables a heightened level of maintenance capability with leading “edge” machine monitoring that anticipates potential issues before they escalate. This results in reduced cost and substantially less downtime on machines, due to unplanned maintenance. This feature is especially useful for linked and sequential production lines.
MACHINUM also offers substantial benefits to machine builders, as Siemens integrated digital twin technology allows more streamlined off-machine programming and machining simulation in an office environment. This approach facilitates faster prep time, more accurate design specs on the final machine, faster component acquisition near the build time and a reduction in costly downtime, due to last-minute design changes, as those are anticipated, simulated and resolved, all in a virtual world. MACHINUM also represents the integration of existing Siemens digitalization software such as Create MyVirtual Machine, Run MyVirtual Machine, Adaptive Control and Monitoring (ACM), Analyze MyWorkpiece and Manage MyMachines.
Under the theme “Empowering the Digital Machine Shop”, Siemens will display its digital threads, from blueprint to finished part, digital twin to simulation, part production, as well as the total integration of these processes into the digital factory for job shops and production departments, all brought to life by Siemens hardware automation and digitalization software.
eRod Continues Its Path
Building off the successful rollout of its eRod “electric buggy” at IMTS 2022, Siemens will further demonstrate the end-to-end production of the aluminum wheel rim and gear housing for this electric vehicle on display in the booth. The wheel rim is made by traditional 5-axis and multi-technology machining (mill-turn, turn-mill) and the gear housing is manufactured through additive/subtractive machining processes. At every stage of each part’s development, including machining, displays will take visitors through the digital manufacturing process. From the popular Siemens NX CAM software, which enables the use of 3D models, data and processes to seamlessly connect planning and shopfloor operations, to the powerful SINUMERIK ONE, the digital-native CNC that permits a digital twin of the machine tool and its full operation in production, Siemens has streamlined machine shop operations as well as leading automotive, aerospace, off-highway, medical part and myriad consumer durable production facilities worldwide.
Additional highlights of the Siemens booth will include:
Aimed at developing a complete eco-system for the machine tool builder and end-user, the Siemens Xcelerator portfolio brings together the breadth of engineering and manufacturing to provide the optimum solution for customers of any size in any industry.
Digitalization solutions will shorten the machine tool builder’s time-to-market through Digital Twin technology, where all machine design and operational kinematics are simulated prior to the machine being built. This development enables substantial savings for the builder and end-user alike — not only in the design, building and commissioning, but also during the startup and training phases of machine implementation.
With SINUMERIK ONE, Siemens is accelerating the digital transformation of the machine tool industry. The new CNC control platform works with software to create the machine controller and the associated digital twin from a single engineering system and thus contributes to the total integration of hardware and software. Thanks to its seamless interaction between the virtual and real worlds, including high-performance PLC, drive and motor hardware, SINUMERIK ONE is setting new standards in terms of productivity, performance and digitalization. It is the future-proof machine controller in the increasingly digital world of manufacturing.
With Create MyVirtual Machine and Run MyVirtual Machine, SINUMERIK ONE is provided with software to create the universal concept of the digital twin, powerful hardware and integrated IT security, making it a forward-looking CNC.
Using Mcenter, the open and modular platform for efficient shopfloors, end-users can seamlessly link all their machine tools and network with company’s IT landscape.
Finally, a fun highlight at this year’s show, Siemens will hold a golf putting contest and raffle two putters twice daily during IMTS 2024. The putter heads will be machined utilizing Siemens CNC hardware automation and digitalization software and feature custom engraving.
For more information about Siemens at IMTS 2024, please visit: https://usa.siemens.com/imts
For more information about the new MACHINUM portfolio, please visit: https://usa.siemens.com/machinum
Siemens Digital Industries (DI) is an innovation leader in automation and digitalization. Closely collaborating with partners and customers, DI drives the digital transformation in the process and discrete industries. With its Digital Enterprise portfolio, DI provides companies of all sizes with an end-to-end set of products, solutions and services to integrate and digitalize the entire value chain. Optimized for the specific needs of each industry, DI’s unique portfolio supports customers to achieve greater productivity and flexibility. DI is constantly adding innovations to its portfolio to integrate cutting-edge future technologies. Siemens Digital Industries has its global headquarters in Nuremberg, Germany, and has around 75,000 employees internationally.
Siemens Corporation is a U.S. subsidiary of Siemens AG, a global powerhouse focusing on the areas of power generation and distribution, intelligent infrastructure for buildings and distributed energy systems, and automation and digitalization in the process and manufacturing industries. Through the separately managed company Siemens Mobility, a leading supplier of smart mobility solutions for rail and road transport, Siemens is shaping the world market for passenger and freight services. Due to its majority stakes in the publicly listed companies Siemens Healthineers AG and Siemens Gamesa Renewable Energy, Siemens is also a world-leading supplier of medical technology and digital healthcare services as well as environmentally friendly solutions for onshore and offshore wind power generation. For more than 160 years, the company has innovated and invented technologies to support American industry spanning manufacturing, energy, healthcare and infrastructure. In fiscal 2018, Siemens USA reported revenue of $23.7 billion, including $5.0 billion in exports, and employs approximately 50,000 people throughout all 50 states and Puerto Rico.
Eight machines plus the newest ANCA Integrated Manufacturing System (AIMS) to be featured in Booth 237406, as the company celebrates its 50th anniversary and the opening of its LA Tech Center
At IMTS 2024, ANCA CNC Machines has much to offer the market and is also celebrating several highpoints in its storied history. In addition to the introduction of an advanced, high-precision tool grinder, the MicroX ULTRA, as well as the next generation of integrated manufacturing technology, AIMS Connect, ANCA will further highlight its commitment to offering the best-in-class solutions for tool grinding production, start to finish, with the celebration of its 50th anniversary in business (1974-2024) and the recent opening of its newest Tech Center in Temecula, California to serve its fast-growing West Coast market base.
ANCA, a global leader in CNC grinding machines and automated manufacturing technologies, celebrates its 50th anniversary, displaying its latest innovations at IMTS. As a mainstay in the precision tool industry, ANCA will showcase its commitment to excellence through new products, cutting-edge technologies and exciting business events, including its popular Tool of the Year and Female Machinist of the Year awards. The anniversary showcase addresses manufacturers’ needs for highest quality and lowest cost tools, plus freeing operators from repetitive and non-value-add tasks to make room for progress and creativity.
Pat Boland, ANCA co-founder, remarks, “For 50 years, ANCA has been on a journey to change the shape of the cutting tool industry. To celebrate our 50th anniversary, we look forward to meeting with our customers and partners at IMTS. As innovation has motivated us throughout our history, new products and developments will be at the center of our celebrations. ANCA’s future is exciting, we are focused on continuing to invent and deliver groundbreaking technology to help take cutting tool production into areas not previously thought possible.”
Edmund Boland, ANCA CNC Machines General Manager, adds, “IMTS is the major global event in this milestone year for our company, so it’s thrilling to showcase our latest products and technologies for high performance cutting tools produced with optimized efficiency and cost. Building on ANCA’s heritage of producing industry-leading software, the latest release of our signature ToolRoom software, RN35, takes cycle time optimization even further, elevating productivity – it’s the future of tool production.”
“ToolRoom and AIMS really pave the way for highly productive, autonomous production. Our investment in AIMS for connected and automated processes is our commitment to solving key challenges such as labor shortages and consistent production processes with smart, future-ready solutions. Our ULTRA technology has made a splash in the market, and now enables micro tool production, regrinding and small batch production with the MicroX and FX7 ULTRA,” notes Edmund.
50 years of innovation and “thinking outside of the box”
ANCA started with a minicomputer and teletype installed at co-founder Pat Boland’s home, followed by a CNC and then the design and manufacture of machine tools with co-founder Pat McCluskey. Throughout the years, ANCA has brought significant advantages to the industry with pioneering innovations like the first touch probe, soft axes and 3D simulation.
Naturally, software and automation are key highlights of ANCA’s anniversary innovation portfolio. The latest version of ANCA’s ToolRoom software, RN35, offers:
Experts will present these and other upgrades to IMTS visitors, plus further exciting news in CIM3D simulation software.
The Future of Automation in Tool Production IS here today…AIMS
The ANCA Automated Manufacturing System (AIMS) is a highly integrated, advanced automation system that brings together machining, metrology and materials handling plus data management in a leading-edge ecosystem for a lights-out production of tools used in myriad industries.
https://machines.anca.com/Products/Integrated-Manufacturing/AIMS (includes a video demo)
ANCA’s AIMS (ANCA Integrated Manufacturing System) is the smart manufacturing solution for cutting tool production, enabling manufacturers to connect, automate and create like never before. The modular system comprises hardware and software components for automated, closed loop manufacturing. AIMS Server controls production processes and AutoComp, the intelligent compensation module maintains part quality automatically, while the new AIMS Connect function covers job management.
With AIMS Connect, recently debuted at GrindingHub in Germany, visitors can experience firsthand the power of digital production control and modular automation, now available for existing installations. The system has proven in the field that it empowers manufacturers to explore new opportunities, products and features while maximizing productivity and quality.
AIMS is growing in popularity, as it enables shops of all sizes plus huge production departments the flexibility to integrate machining, metrology and materials handling into a unified ecosystem with full data capture and management capabilities.
Machines and technology for highest quality and lowest cost tools
ANCA’s GCX machine and gear tool technology is set to redefine the production of skiving cutters with a turnkey solution package. To address the complexity of gear tool manufacturing, this offering includes features for the design of gear cutting tools, manufacturing and integrated tool measurement, as well as providing the skiving machine setup parameters.
IMTS visitors will witness live how this configuration enables short setup times, simulation and monitoring, plus quality enhancing features like the ANCA Motor Temperature Control (MTC) and integrated balancing (iBalance) for unparalleled longtime grinding profile accuracy within +/-0.0015mm. This turnkey package facilitates easy entry into the gear tools sector while ensuring top-quality results.
ULTRA Technology: the platform for highest precision and micro tool work
Revolutionary ULTRA technology combines nanometer control, servo-controlled algorithms and mechanical stiffness upgrades to achieve unprecedented accuracy. The FX7 ULTRA and MicroX ULTRA demonstrate ANCA’s commitment to precision, enabling continuous batch production down to 0.03mm and setting new standards in tool manufacturing.
The MicroX ULTRA premiered at EMO 2023 and was released to the market at GrindingHub, giving micro tool manufacturers all the advantages of the ULTRA technology and ANCA’s Machine Intelligence in a unit tailored to this application. As the only micro tool grinder with nanometer control, optimized mechanical layout and axes travel, integrated tool measurement and progressive automation, this six-axis grinder is the ideal solution for volume production of tools down to 0.03mm.
Customer-centric solutions enable enhancements
Laser measuring on the EPX-SF
The new EPX-SF stream finishing machine was released to the market at GrindingHub. ANCA’s advanced edge preparation and surface finishing solution addresses productivity targets, delivers superior IP cutting tool performance and succeeds in precision-critical industries – in a design that’s ready to be integrated in automated tool manufacturing systems. With 11-axis automation and smart recipe fine-tuning, the machine is engineered by tool experts to optimize media utilization while providing precise edge control. The machine has the capability to reduce edge roughness to under 100 nm and refine edge radii to mere microns with controllable K-factor, achieving nano-smooth surfaces and micron-honed edges in record time.
The EPX-SF’s cyclic mode with pulse rotation serves as a potent defense against surface burrs and edge imperfections. With adjustable positive and negative angles, the EPX-SF spindle traverses the optimal cutting path, optimizing potential chip flow and reducing the surface roughness of the cutting workpiece. Within ANCA’s automation ecosystem, the EPX-SF seamlessly integrates into production lines, operating autonomously with robotic assistance round the clock for tool loading/unloading.
The CPX blank preparation machine is a prime example of how to include the voice of the customer in product development. Tool manufacturers around the world were asked and given their ideal solution for blanks with high material removal rates, application flexibility and integrated quality control. With features like statistical process control and top surface finishes below 0.2Ra, manufacturers can achieve high productivity at minimal cost with the CPX Linear. Some further application capability will be introduced at IMTS.
ANCA invites visitors to join us at IMTS Booth 237406 to experience firsthand the future of tool manufacturing.
For further information, please contact:
Amanda Bakun
Marketing & Communications Manager – Americas
ANCA MACHINE TOOLS
248-497-1168
amanda.bakun@anca.com
ANCA is a market leading manufacturer of CNC grinding machines. It was founded in 1974 in Melbourne, Australia where the company still has its global headquarters. ANCA has offices in the UK, Germany, China, Thailand, India, Japan, Brazil, Korea, Mexico and the USA as well as a comprehensive network of representatives and agents worldwide.
ANCA CNC grinders are used for manufacturing precision cutting tools and components across a diverse range of competitive industries including cutting tool manufacture, automotive, aerospace, electronics and medical.
Continue readingANCA will showcase the latest products and industry-specific grinding and automation solutions and will announce the Tool of the Year Winner of 2023
CNC grinding technology pioneer ANCA will showcase their latest products and industry-specific grinding and automation solutions at EMO at Booth F52, Hall 6 in Hanover, Germany in September. The eagerly awaited winner of the renowned Tool of the Year competition will be announced live Wednesday, September 20th at 4.30pm (GMT) – and all are welcome to join the celebrations and witness for themselves the ultimate range of cutting tools.
Edmund Boland, ANCA CNC Machines General Manager said, “We are excited to bring not one but several world premieres to EMO, promising premium value, higher productivity and extended capabilities. Visitors can see firsthand ANCA’s latest technology that spans tool precision, integrated manufacturing systems, industry focus applications and optimization across the process chain.”
Martin Winterstein, General Manager of ANCA Europe said, “EMO is the global leading manufacturing technology show, it is where the current market trends and innovations are on display. Our setup in Hanover really shows hands-on opportunities for tool manufacturers, with new application and automation solutions tailored to industries’ needs. I am excited to show visitors our enhanced portfolio to include micro tools with the FX ULTRA, according to the high demand from this growing segment. Experts from ANCA and our partners will be on-site to show and discuss individual requirements at the booth.”
ULTRA value
Never ceasing in their commitment to creating the highest quality product, years of continuous refinements at ANCA have made the ULTRA technology possible. ANCA’s unique vertical integration is key to its success – where machines, controls, drives and precision components are all designed and manufactured in-house. Successfully introduced to the industry last year on the MX machine platform, it boasts the highest accuracy and quality cutting tools in the world. The MX7 ULTRA achieves one nanometre axis resolution, and can maintain better than +/- 0.002mm line form accuracy of any profile which includes ballnose and corner radius endmills.
At EMO, visitors will find out how ANCA spreads the ULTRA advantages to further fields of application, including smaller batches, regrinding and tools with small diameters.
Launching the FX7 ULTRA, the latest game-changing innovation that revolutionizes precision grinding for small tools down to 0.1mm
The FX7 ULTRA introduces cutting-edge technologies, including ANCA’s unique nanometer control, that revolutionizes precision grinding for small and micro tools down to 0.1mm diameter. This significant technology breakthrough is already redefining the standards for tool and component grinding with the highest levels of accuracy and surface finishes.
New software, hardware and design features significantly improve surface finish, accuracy, and controlled runout, ensuring batch consistency from the first ground tool to the last. These advancements ensure that the FX7 ULTRA is the go-to solution for precision grinding in industries that rely on small tools, including electronics, telecommunications, medical devices, aerospace, automotive, diemold, and general machining.
The ultimate value – ANCA’s premium one stop shop for peel and geometry combined with blanket grinding
From blank to a finished high-quality tool, all on one machine – ANCA’s ultimate single setup solution for complete machining of cutting tools will be demonstrated on the MX7 ULTRA at EMO. Following a legacy of machine efficiency, this latest solution combines peel grinding and tool grinding on the one platform, enhanced with additional power to extend capability. The MX7 ULTRA’s remarkable spindle power of 26kW can handle demanding tools like larger taper ballnose endmills, step drills, and aerospace components ranging from 0.1 to 25.4 mm. This leads to reduced cycle times and increased productivity. Short setup times, optional collet change and proven blanket grinding processes round out the capabilities.
By utilizing the latest innovations in peel grinding technology, ANCA guarantees exceptional stability, accuracy and value, all achieved on a single machine. Manufacturers can now produce high-quality tools with confidence, knowing that the MX7 ULTRA delivers outstanding results.
Smart automation enables unattended cutting tool production
ANCA has further developed its AIMS system for automated tool production. At EMO, visitors can see examples from the field, with systems operating completely unattended over extended period, manufacturing tools.
The AIMS automation package is a modular and growing system, spanning across the tool production process. ANCA is set to include additional operations like blank preparation or laser marking in the automated process. The system’s intelligent design allows for progressive steps of automation, including an automated laser marking station AutoMarkX. The versatile laser marking station is tailored to meet the needs of tool manufacturers. It provides reliable and high-quality marking, ensuring traceability, identification, and branding of tools, while eliminating repetitive tasks to free up time for skilled staff.
The AutoMarkX’s new, retrofittable rotary workholding system allows for unlimited index marking around the tool, with automatic Z-axis focus and compatibility with tool shanks from 3 to 32mm. Moreover, the AIMS Autoline Basic, the standard interface for easy loading at the AutoMarkX enables customers to experience smoother material transfer between machines. By utilizing a manual trolley system, combined with AIMS pallet carriers, Autoline Basic streamlines the transfer of heavy tool pallets between machines, reducing labor-intensive processes.
From blanks with a surface finish better than 0.2Ra, to ANCA’s GCX Linear which has set the new benchmark for skiving cutter grinding
ANCA’s expertise in grinding solutions extends to blank grinding and integrated complete machining of gear tools, including in-process measuring and compensation. The CPX blank preparation machine will feature productivity-enhancing features in Hannover, including automated loading of tools up to 32mm, a flip station for grinding from both ends, tailstock, and extensive probing enabling statistic process control. The machine has been designed to give users high material removal rates and save time and money with unattended production.
The rising demand of gear cutting tools has led ANCA to enhance its product program with the GCX, the turnkey solution for manufacturing and resharpening gear cutting tools. The Integrated Gear Tool Measurement (IGTM) and ANCA’s expertise in grinding wheel dressing gives customers the benefit of full control over the high precision skiving cutter grinding process. First skiving cutter in tolerance, is the motto. ANCA’s widely spread area of grinding applications, can be covered with the versatile GCX and its numerous optional accessories like the LaserUltra for profile tools.
The Premier Cutting Tool Award
One of the most eagerly awaited events at ANCA’s booth will be the winner announcement of the Tool of the Year 2023 competition. This prestigious competition brings together tool manufacturers from around the globe, who compete for the title of the best real and virtual tools. The judging process, overseen by a panel of ANCA and external experts, evaluates precision, surface roughness, creativity, and practical use. The award ceremony promises to be a highlight of the exhibition, recognizing the industry’s most innovative and exceptional tools.
EMO 2023 offers an exclusive opportunity for industry professionals to explore ANCA’s latest advancements in grinding technology, witness revolutionary world premieres, and engage with experts from the field. Visitors will also experience exclusive product launches to be revealed at the show. ANCA invites all attendees to visit their booth in Hall 6, F52, where they can experience firsthand the cutting-edge solutions and industry-specific grinding innovations that are shaping the future of manufacturing.
Strategic Partnerships with Industry leaders
ANCA’s commitment to excellence is further emphasized through strategic partnerships with industry leaders. At EMO 2023, ANCA will collaborate with Mitsubishi, presenting their EDM machine at the booth, and GDS clamping technology, presenting a cohesive ecosystem of solutions that streamline processes across the process chain.
For further information, please contact:
Amanda Bakun
Marketing & Communications Manager – Americas
248-497-1168
amanda.bakun@anca.com
ANCA is a market leading manufacturer of CNC grinding machines. It was founded in 1974 in Melbourne, Australia where the company still has its global headquarters. ANCA has offices in the UK, Germany, China, Thailand, India, Japan, Brazil and the USA as well as a comprehensive network of representatives and agents worldwide.
ANCA CNC grinders are used for manufacturing precision cutting tools and components across a diverse range of competitive industries including cutting tool manufacture, automotive, aerospace, electronics and medical.
Besides showcasing the ATOS Q and Absolute Arm, the company will present the new T-SCAN hawk 2
Exact Metrology: A Division of In-Place Machining Company and a comprehensive 3D metrology service provider and hardware sales company, will be exhibiting at the MetalCasting Congress and present innovative solutions from ZEISS, GOM and Hexagon in booth 815.
Produced by the American Foundry Society, this unique event is taking place between April 25-27 at the Huntington Convention Center in Cleveland, Ohio. The program offers exhibits, interactive demonstrations, and a direct connection with metalcasters, top suppliers and service providers. Present at the Exact Metrology booth will be Dean Solberg, Vice President of Metrology Sales and Services, Darin Sherry, Regional Sales Manager and David Nichols, Applications Engineer. The advanced metrology instruments that will be demonstrated in the Exact Metrology booth are the T-Scan hawk 2 from ZEISS, the GOM ATOS Q, and the Absolute Arm from Hexagon Manufacturing Intelligence.
The ZEISS T-SCAN hawk 2 is the next generation lightweight portable 3D scanner with metrology-grade precision and ease of use. Working distance can be controlled with a new projection mode. Furthermore, the satellite mode can scan up to multiple meters, eliminating the need for classical built-in photogrammetry with coded markers. The T-SCAN hawk 2 features four buttons to start and navigate the workflow directly. Seamless adjustments for resolution and field of view are applied for fine details, large objects, deep pockets, confined spaces, or hard-to-reach areas. This scanner supports scanning on a wide range of materials and surfaces, delivering precise 3D data.
GOM ATOS Q is a flexible 3D scanner for complex measurement and inspection tasks in different industries. The scanner delivers fully traceable measurement results, especially in harsh conditions. It captures quality information quickly and with a high degree of detail, providing a reliable basis to easily interpret the information. ScanCobot, a mobile automated 3D scanning system, easily integrates with ATOS Q.
The Absolute Arm from Hexagon Manufacturing Intelligence has an IP54 protection rating, a market first for portable measuring arms. It features an environment-related improvement that sees the system’s maximum operating temperature increased to 45°C. There are also improvements to the functionality of the Absolute Arm wrist display, now upgraded to a touchscreen, and the RDS software that drives it.
Besides the mentioned products, Exact Metrology also offers dimensional metrology services, including post processing options of reverse engineering and inspection. With First Article Inspection, which is a design verification process, measurements for each manufactured feature of a part are generated. Thus, a manufacturer can ensure all specifications are to design specifications before manufacturing a part.
Visit Exact Metrology in booth 815 during MetalCasting Congress.
In-Place Machining Company: On-Site Machining Solutions In-Place, Any Place in the World.
In-Place Machining Company, with facilities in Wisconsin, Washington, Virginia, Ohio, and Ontario, Canada, is the premier provider of high-precision engineered on-site machining, metrology, and large scale cutting & drilling services for a wide range of renewable energy, aerospace, industrial, and military customers throughout the world.
Exact Metrology: A Division of In-Place Machining Company, is ISO9001, AS9100 Certified as well as ITAR Registered.
Exact Metrology: A Division of In-Place Machining Company, with facilities in Cincinnati, Ohio, Moline, Illinois and Milwaukee, Wisconsin, plus affiliated offices throughout the country, is a comprehensive metrology services provider, offering customers 3D and CT scanning, reverse engineering, quality inspection, product development and 2D drawings. The company also provides turnkey metrology solutions, including equipment sales and lease/rental arrangements.
GOM GmbH
GOM, a company of the ZEISS Group, specializes in industrial 3D coordinate measuring technology, 3D computed tomography and 3D testing. From product development to production and worldwide distribution, GOM offers machines and systems for manual and automated 3D digitizing, evaluation software, training and professional support from a single source. In industries such as automotive, aerospace, energy and consumer goods, more than 17,000 GOM system installations are in use internationally. At more than 60 locations and with more than 1,200 metrology specialists, GOM guarantees profound advice and first-class service. Since mid-2019, GOM has been a part of the ZEISS Group and has formed the Center of Excellence for optical metrology. With more than 31,000 employees in 50 countries and annual revenue totaling more than 6.4 billion euros, ZEISS is an internationally leading technology enterprise operating in the fields of optics and optoelectronics.
Exact Metrology: A Division of In-Place Machining Company and a comprehensive 3D metrology service provider and hardware sales company, exhibited at POWERGEN International together with In-Place Machining Company (IPM), Oasis Alignment Services: A Division of In-Place Machining Company and East Coast Metrology: A Division of In-Place Machining Company in booth 3014. Representatives were on hand to offer solutions for the thermal, hydro, nuclear, wind and diesel industries.
Leica RTC360 used in plants
The show was recently held at the Orange County Convention Center in Orlando, Florida. POWERGEN is the largest networking and business hub for generators and solution providers engaged in power generation. Power producers, utilities, EPCs, consultants, OEMs and large-scale energy users gather to discover unparalleled education, peer-to-peer networking and solutions from top providers.
Exact Metrology displayed its Leica RTC360. Manufactured by Leica Geosystems, these portable coordinate measuring machines are designed to measure large-scale objects. The RTC360 3D Reality capture scanner is ideal for professionals managing project complexities with accurate and reliable 3D representations. This scanner effectively combines a high-performance 3D laser scanner with Leica Cyclone Field 360, a mobile device app for edge computing that automatically registers scans in real time and Leica Cyclone REGISTER 360, an office software that integrates the 3D model into the workflow. Additional features include capturing scans, including enriching HDR imagery, in less than two minutes, automatically recording moves from station to station and augmenting data capture with information tags.
Dean Solberg (left), Rob Ellington (middle) and Noel Brekas (far right)
Measurement services displayed by OASIS Alignment Services included 26 power plant (hydro, steam and gas) jobs performed in 2020. Most jobs involved metrology support, with two including mechanical work. In 2021, the total number was 37, most of which were metrology supported, with six jobs including mechanical work. Last year, 29 power plant jobs were performed, two including mechanical work. To date in 2023, 10 jobs have been accomplished, three involving mechanical work. Examples of mechanical jobs in the power industry typically include cooling tower fan alignment, pump alignment, replacement of turbine bearings, generator alignment, new coupling installment, gearbox alignment, circular pump alignment, repair of broken shaft and solar generator alignment. Some metrology alignment jobs comprised inspection of turbine components, monitoring of components during a rebuild, structural movement studies, flatness inspections and others.
Present at the event were Dean Solberg, Vice President of Metrology Sales and Services at Exact Metrology, IPM Sales Managers Noel Brekas, Ronnie Onofry and Rob Ellington, Paul Parry, Director of Sales-Field Machining and Ulises Uscanga, Head of Industrial Plant Solutions at Leica Geosystems.
Dean Solberg highlighted the importance of having East Coast Metrology at the show. “The recent acquisition of East Coast Metrology allows IPM Measurement Group to provide nationwide coverage with metrology services to complement its field machining capabilities. We are excited to continue serving our customers’ needs as their one-stop shop.”
IPM discussed its recent acquisition of East Coast Metrology, which now afford the company nationwide coverage with metrology services to complement its field machining capabilities.
In-Place Machining Company: On-Site Machining Solutions In-Place, Any Place in the World.
In-Place Machining Company, with facilities in Wisconsin, Washington, Virginia, Ohio, and Ontario, Canada, is the premier provider of high-precision engineered on-site machining, metrology, and large scale cutting & drilling services for a wide range of renewable energy, aerospace, industrial, and military customers throughout the world.
Exact Metrology: A Division of In-Place Machining Company, is ISO9001, AS9100 Certified as well as ITAR Registered.
Exact Metrology: A Division of In-Place Machining Company, with facilities in Cincinnati, Ohio, Moline, Illinois and Milwaukee, Wisconsin, plus affiliated offices throughout the country, is a comprehensive metrology services provider, offering customers 3D and CT scanning, reverse engineering, quality inspection, product development and 2D drawings. The company also provides turnkey metrology solutions, including equipment sales and lease/rental arrangements.
OASIS Alignment Services: A Division of In-Place Machining Company
OASIS Alignment Services: A Division of In-Place Machining Company, provides 3-Dimensional Metrology Services, Precision Alignment Inspections and Diagnostics and Mechanical Services across a wide range of industries including aerospace, automotive, power generation, shipbuilding, pulp and paper, converting, printing, plastics, textiles and more. OASIS has completed thousands of successful projects since its inception in 1982 and continues to set industry standards in alignment procedures, specialized tooling and reporting techniques. OASIS operates service centers in New Hampshire, North Carolina, Florida, Ohio, Wisconsin, California, Washington, and Ontario and Québec, Canada. For more visit www.oasisalignment.com
East Coast Metrology: A Division of In-Place Machining Company
East Coast Metrology is a globally recognized full-service contract measurement company specializing in 3D scanning and modeling, reverse engineering & design, training and certification, instrument calibrations, equipment rentals, integration & alignment services. Headquartered in Topsfield, Massachusetts, ECM hosts an ISO/IEC 17025 Accredited Laboratory where they perform instrument calibrations, repairs, and CMM part inspection and programming. For more visit www.eastcoastmetrology.com
For information, please contact:
EXACT METROLOGY, INC.
Dean Solberg
20515 Industry Avenue
Brookfield, WI 53045
Local: 262-533-0800
www.exactmetrology.com
deans@exactmetrology.com
EXACT METROLOGY, INC.
Steve Young
11575 Goldcoast Drive
Cincinnati, OH 45249
Local: 513.831.6620
Toll Free: 866.722.2600
www.exactmetrology.com
stevey@exactmetrology.com
ANCA Americas (Wixom, MI), long time EASTEC exhibitor and a market leading manufacturer of CNC grinding machines, has announced that it will be returning to EASTEC in West Springfield, MA from May 16 – 18, 2023 in booth 1118.
“We’re excited to be participating in EASTEC. ANCA has a very strong and extremely loyal customer base in the Northeast, and we love introducing them to our latest innovations. We feel our MX7 Ultra will make a big impact on the market in the East, a customer base that requires an extremely high level of accuracy, and we’re excited to showcase it live at EASTEC,” says Russell Riddiford, President of ANCA Inc. Not only will ANCA be showcasing the new MX7 Ultra at EASTEC, but the company will also have an AutoMarkX the automatic laser marking system, on display at the show.
MX7 Ultra ANCA’s Premium Machine Producing the Highest Accuracy and Quality Cutting Tools in the World
The new MX7 ULTRA can manufacture large volumes of endmills and other cutting tools of the highest accuracy and quality. The size of a micron is smaller than what the human eye can see, but in becoming even more precise and moving from micrometers to nanometers, ANCA will offer the highest accuracy and quality in a cutting tool in the market. New software, hardware and design features are combined to make significant advances in surface finish, accuracy, and controlled runout, to deliver batch consistency from the first ground tool to the thousandth.
To learn more about the MX7 Ultra, visit ANCA’s website https://machines.anca.com/MX7-ULTRA-launch or check out the ULTRA tool report: https://machines.anca.com/MX7-Ultra-tool-report.
AutoMarkX: Save Time and Money with ANCA’s Automatic Laser Marking Machine
The AutoMarkX is an automatic stand-alone laser marking station replacing manual and labor-intensive processes. The operator simply loads up to two full pallets of tools and the robot performs the laser marking operations, freeing up staff to take care of other tasks in the factory. The unit can accommodate a wide range of tool sizes, making it a versatile proposition for many manufacturers.
For more information about the AutoMarkX, visit ANCA’s website: https://machines.anca.com/AutoMarkX
Visit ANCA at booth 1118 during EASTEC 2023!
ANCA has the grinding solutions you’re looking for to improve your production of precision tools. If you’re attending EASTEC, stop by booth 1118 to visit ANCA and explore the most innovative grinding solutions on the market to improve the efficiency of your production and the quality of your tools.
ANCA is a market leading manufacturer of CNC grinding machines. It was founded in 1974 in Melbourne, Australia where the company still has its global headquarters. ANCA has offices in the UK, Germany, China, Thailand, India, Japan, Brazil, Mexico, and the USA as well as a comprehensive network of representatives and agents worldwide.
For further information, please contact:
Amanda Bakun
Marketing & Communications Manager – Americas
248-497-1168
amanda.bakun@anca.com
ANCA is a market leading manufacturer of CNC grinding machines. It was founded in 1974 in Melbourne, Australia where the company still has its global headquarters. ANCA has offices in the UK, Germany, China, Thailand, India, Japan, Brazil and the USA as well as a comprehensive network of representatives and agents worldwide.
ANCA CNC grinders are used for manufacturing precision cutting tools and components across a diverse range of competitive industries including cutting tool manufacture, automotive, aerospace, electronics and medical.
ANCA Americas (Wixom, MI), a market leading manufacturer of CNC grinding machines, has announced its participation at PMTS in Cleveland, OH from April 18 – 20, 2023 in booth 4077.
PMTS, focused on precision machined parts, is the perfect place to show off ANCA’s grinding technology – and for its first show, ANCA is hitting it out of the park, showcasing two machines – the FX Linear and AutoMarkX (AMX). “We’re excited to take part in our first PMTS! The precision tool industry is a big market for us. With the range and flexibility of our machines we can provide the industry with the right machine for every application. We’re excited to showcase the FX5 Linear and AutoMarkX technology to the precision tool market,” says Russell Riddiford, President of ANCA Inc.
FX5 Linear: Increased Productivity and Range
The FX5 Linear offers automation and the versatility of more options, to meet the needs of increased productivity. The FX5 Linear has a wheel spindle power of 12 kW and an automatic two station wheel changer for an increased range of wheels and tool types. With the optional automatic headstock clamping, it can provide unmanned operation and the flexibility to handle small volumes and mixed batches of tools.
The FX5 Linear machine is ideal for everything from light manufacturing to regrinding and full production. Every part on the machine – from the positioning of the grinding wheel on the C-axis center line to reduce thermal influence, to the ANCA linear motors – have been designed to enhance accuracy, increase productivity and ease of machining for the operators.
For more information about the FX5 Linear, visit ANCA’s website: https://machines.anca.com/Products/Machines/FX-Linear/FX5
AutoMarkX: Save Time and Money with ANCA’s Automatic Laser Marking Machine
The AutoMarkX is an automatic stand-alone laser marking station replacing manual and labor-intensive processes. The operator simply loads up to two full pallets of tools and the robot performs the laser marking operations, freeing up staff to take care of other tasks in the factory. The unit can accommodate a wide range of tool sizes, making it a versatile proposition for many manufacturers.
For more information about the AutoMarkX, visit ANCA’s website: https://machines.anca.com/AutoMarkX
Visit ANCA at booth 4077 during PMTS 2023!
ANCA has the grinding solutions you’re looking for to improve your production of precision tools. If you’re attending PMTS, stop by booth 4077 to visit ANCA and explore the most innovative grinding solutions on the market to improve the efficiency of your production and the quality of your tools.
ANCA is a market leading manufacturer of CNC grinding machines. It was founded in 1974 in Melbourne, Australia where the company still has its global headquarters. ANCA has offices in the UK, Germany, China, Thailand, India, Japan, Brazil, Mexico, and the USA as well as a comprehensive network of representatives and agents worldwide.
For further information, please contact:
Amanda Bakun
Marketing & Communications Manager – Americas
248-497-1168
amanda.bakun@anca.com
ANCA is a market leading manufacturer of CNC grinding machines. It was founded in 1974 in Melbourne, Australia where the company still has its global headquarters. ANCA has offices in the UK, Germany, China, Thailand, India, Japan, Brazil and the USA as well as a comprehensive network of representatives and agents worldwide.
ANCA CNC grinders are used for manufacturing precision cutting tools and components across a diverse range of competitive industries including cutting tool manufacture, automotive, aerospace, electronics and medical.
Leader in 3D Scanning Joins Master Metrology Users at this Unique Event
Exact Metrology: A Division of In-Place Machining Company and a comprehensive 3D metrology service provider and hardware sales company, will be exhibiting at the Coordinate Metrology Society Conference (CMSC) with their sister division, OASIS Alignment Services: A Division of In-Place Machining Company.
Held between July 25th and July 29th at the Renaissance Orlando SeaWorld this practical, user-driven metrology conference provides attendees with the opportunity to try the latest innovative coordinate metrology equipment and educate themselves in metrology principles. In addition, attendees can receive certification and have the ability to implement their newfound knowledge directly into the workplace. Face-to-face interaction is available with over 400 master end users of metrology solutions, including developers, decision makers, and equipment vendors and service providers. The CMSC includes numerous technical presentations from industry experts, hands-on workshops providing training opportunities on metrology hardware and software solutions, and a one of a kind networking event.
All of the major players, including the metrology equipment manufacturers that Exact Metrology resells for, will be exhibiting and attending. According to Dean Solberg, Vice President of Metrology at Exact Metrology: A Division of In-Place Machining Company, “Our main focus for this show is to share who we are now as the two precision measurement companies that currently make up the Measurement Services Group of In-Place Machining Company. We look forward to discussing our joint metrology services with show attendees. These include 3D Scanning, Dimensional Inspection, Long Range Scanning (GEOSPATIAL), Reverse Engineering, Industrial CT Scanning, Precision Machine Alignment and Training on Polyworks and Geomagic.”
In attendance in booth 219 will be Mr. Solberg and Myron Smith, Director of Training and Development at OASIS Alignment Services: A Division of In-Place Machining.
Reflecting on the importance of the show, Mr. Solberg believes it’s the ideal place “…to get a first-hand look at new developments in precision measurement systems and software.” Mr. Smith added “The CMSC provides us with the chance to explore best-in-class 3D metrology options, as well as share the benefits of our services with the members of this unique society.”
In-Place Machining Company: On-Site Machining Solutions In-Place, Any Place in the World.
In-Place Machining Company, with facilities in Wisconsin, Washington, Virginia, Ohio, and Ontario, Canada, is the premier provider of high-precision engineered on-site machining, metrology, and large scale cutting & drilling services for a wide range of renewable energy, aerospace, industrial, and military customers throughout the world.
Exact Metrology: A Division of In-Place Machining Company, is ISO9001, AS9100 Certified as well as ITAR Registered.
Exact Metrology: A Division of In-Place Machining Company, with facilities in Cincinnati, Ohio, Moline, Illinois and Milwaukee, Wisconsin, plus affiliated offices throughout the country, is a comprehensive metrology services provider, offering customers 3D and CT scanning, reverse engineering, quality inspection, product development and 2D drawings. The company also provides turnkey metrology solutions, including equipment sales and lease/rental arrangements.
OASIS Alignment Services: A Division of In-Place Machining Company
OASIS Alignment Services: A Division of In-Place Machining Company, provides 3-Dimensional Metrology Services, Precision Alignment Inspections and Diagnostics and Mechanical Services across a wide range of industries including aerospace, automotive, power generation, shipbuilding, pulp and paper, converting, printing, plastics, textiles and more. OASIS has completed thousands of successful projects since its inception in 1982 and continues to set industry standards in alignment procedures, specialized tooling and reporting techniques. OASIS operates service centers in New Hampshire, North Carolina, Florida, Ohio, Wisconsin, California, Washington, and Ontario and Québec, Canada. For more visit www.oasisalignment.com
For more information, please contact:
EXACT METROLOGY, INC.
Dean Solberg
20515 Industry Avenue
Brookfield, WI 53045
Local: 262-533-0800
www.exactmetrology.com
deans@exactmetrology.com
Exact Metrology: A Division of In-Place Machining Company and a comprehensive 3D metrology service provider and hardware sales company, was at POWERGEN International with In-Place Machining Company (IPM) and Oasis Alignment Services: A Division of In-Place Machining Company in booth 5508. Representatives from each company were on hand to offer solutions for the thermal, hydro, nuclear, wind and diesel industries.
Located at the Kay Bailey Hutchinson Convention Center in Dallas, Texas, the show ran from May 23 to May 25. POWERGEN is the largest network and business hub for electricity generators and solution providers engaged in power generation. Power producers, utilities, EPCs, consultants, OEMs and large-scale energy users gather to experience unparalleled education, peer-to-peer networking and solutions from top providers.
Exact Metrology displayed the Hexagon 825 and the Leica AT960 Tracker. Also known as the ROMER Absolute Arm 7-axis, it delivers tactile probing and laser scanning in a uniquely ergonomic package. With usability central to its design, the articulating measuring arm offers ease of movement and ease of measurement. Built-in versatility is part of a uniquely modular wrist design that features configurable grip shapes and sizes. Additional features include an on-wrist display that puts control and results in the hands of the user and a wide range of accessories from probe tips to laser scanners to complete measurement systems. This leads to a productive arm delivering high-accuracy measurement results easier and faster than before.
The Leica AT960 is a robust, all-in-one laser tracker that fits in a single flight case. Offering high-speed dynamic measurement as standard, it is a complete solution for six degrees of freedom (6DoF) probing, scanning and automated inspection as well as reflector measurement. Featuring wireless communication and a battery operation option, the integrated-technology design of the AT960 reduces setup time drastically. The Leica Absolute Interferometer (AIFM) enables accurate high-speed measurement of a moving target, while the innovative PowerLock function ensures an interrupted beam is instantly re-established without user intervention, reducing operator workload and training requirements. Intuitive touch-screen controls minimize the potential for user error, thus saving time, effort and money.
Dean Solberg, Vice President of Metrology Sales and Services at Exact Metrology and Karan Singh, Sales Engineer were at the show. In-Place Machining Company personnel in attendance included Noel Brekas, Northeast Regional Sales Manager, Paul Parry, Outside Sales Manager and Bart Rierson, Field Engineer. Bruce Littlefield, Key Account Manager from OASIS Alignment Services was also in the booth.
Dean Solberg expressed his excitement at having IPM and OASIS Alignment Services join Exact at POWERGEN. “With the recent acquisitions of Exact Metrology and OASIS Alignment Services, the IPM Measurement Group now provides expanded 3D scanning solutions, contract metrology services, and precision machine alignment capabilities. With 18 locations across the U.S. and Canada and over 120 field engineers and technicians that travel worldwide, we are truly your one source for on-site excellence.”
In-Place Machining Company: On-Site Machining Solutions In-Place, Any Place in the World.
In-Place Machining Company, with facilities in Wisconsin, Washington, Virginia, Ohio, and Ontario, Canada, is the premier provider of high-precision engineered on-site machining, metrology, and large scale cutting & drilling services for a wide range of renewable energy, aerospace, industrial, and military customers throughout the world.
Exact Metrology: A Division of In-Place Machining Company, is ISO9001, AS9100 Certified as well as ITAR Registered.
Exact Metrology: A Division of In-Place Machining Company, with facilities in Cincinnati, Ohio, Moline, Illinois and Milwaukee, Wisconsin, plus affiliated offices throughout the country, is a comprehensive metrology services provider, offering customers 3D and CT scanning, reverse engineering, quality inspection, product development and 2D drawings. The company also provides turnkey metrology solutions, including equipment sales and lease/rental arrangements.
OASIS Alignment Services: A Division of In-Place Machining Company
OASIS Alignment Services: A Division of In-Place Machining Company, provides 3-Dimensional Metrology Services, Precision Alignment Inspections and Diagnostics and Mechanical Services across a wide range of industries including aerospace, automotive, power generation, shipbuilding, pulp and paper, converting, printing, plastics, textiles and more. OASIS has completed thousands of successful projects since its inception in 1982 and continues to set industry standards in alignment procedures, specialized tooling and reporting techniques. OASIS operates service centers in New Hampshire, North Carolina, Florida, Ohio, Wisconsin, California, Washington, and Ontario and Québec, Canada. For more visit www.oasisalignment.com
For more information, please contact:
Exact Metrology: A Division of In-Place Machining Company
Kelly Baldasare
11575 Goldcoast Drive
Cincinnati, OH 45249
Local: 513-831-6620
Toll Free: 866-722-2600
www.exactmetrology.com
kellyb@exactmetrology.com
