No. 814 is a 500ºF (260ºC), electrically-heated cabinet oven from Grieve, currently used for various plastic and metal part heat treating operations at the customer’s facility. Workspace dimensions of this oven measure 22” W x 21” D x 85” H. 18 kW are installed in Nichrome wire tubular elements to heat the oven chamber, while a 750 CFM, 3/4-HP recirculating blower provides a vertical downward airflow to the workload.
This Grieve cabinet oven features 4” insulated walls, aluminized steel exterior and interior, three integral metal shelves, plus all safety equipment required by NFPA Standard 86 for handling flammable solvents, including a powered forced exhauster, airflow safety switch and purge timer.
Other controls on No. 814 include a fused disconnect switch, digital temperature controller and manual reset excess temperature controller.
For more information, please contact:
THE GRIEVE CORPORATION
500 Hart Road
Round Lake, IL 60073-2898
Phone: (847) 546-8225
Fax: (847) 546-9210
Web: www.grievecorp.com
Email: sales@grievecorp.com
Attention: Frank Calabrese, VP
Press conference at IMTS 2014
Ann Arbor, Michigan – GMTA (German Machine Tools of America) represents various top-quality German metalworking machine builders, including Wera Profilator, Pittler, Praewema and WMZ, as well as Arnold lasers and Rosink parts washers. These machines are sold to the North American market exclusively by GMTA, primarily for gear and spline production, as well as other power transmission and various metalworking applications. The company’s target markets include automotive, off-highway, energy and other heavy equipment manufacturing. Machines are provided for gear honing, gear grinding, the patented Scudding® process for gearmaking, polygon milling, turning, gear tooth pointing and multi-task machining operations. This newsletter is provided to our friends in the media to keep you and your readers updated on News of Note at GMTA.
In the news…
-GMTA had an extremely successful IMTS, running a media event, highlighted by the introduction of the Moduline® machining center. This unique machine, built for high-production runs of various end products, offers customers an unmatched flexibility in their manufacturing. In single work envelope, a wide variety of machining operations can be performed on a workpiece in single setup. Of greatest significance is the fact those machining operations can be adapted, changed out, re-sequenced and completely reconfigured, all on the same machine. The result is highly flexible production in a small footprint, with a single CNC controlling the overall machine and individual PLC’s running each optimized machine function per part.
Alfredo Contreras, manager of new GMTA office in Queretaro, Mexico
-During the IMTS press event, presentations were given by GMTA President Walter Friedrich, VP of Sales Scott Knoy, GMTA Product Manager for lathe technology Stefan Kloos and, visiting the show from Germany, DVS group VP for Sales & Marketing Bernd Rothenberger. Highlighting the presentation was the announcement of the new GMTA facility in Queretaro, Mexico, recently opened by Regional Sales Manager Alfredo Contreras, who will be responsible for company sales and service in the fast-growing Mexican market for the company. See VIDEO of the press event here and an interview during IMTS with Walter and Scott, here.
-GMTA now represents K + G tooling in North America, including the company’s complete line of products for inside grooving, turning, milling, profiling, bit production, facemilling, gear tooth milling, chamfering, back angling and more.
-A definitive explanation on the trademarked Profilator Scudding® process for advanced gearmaking is now available from GMTA. Please contact Scott Knoy at GMTA (below) for details.
-GMTA recently sponsored Eastern Michigan University’s German American Day, held for the 10th year at EMU’s Student Center for the dual purpose of cultural heritage celebration and business recruitment. This year’s event happened on October 6. GMTA has an ongoing relationship with EMU, supporting various degree programs in the graduate and business schools to help prepare students enter careers with enhanced technical and language skills.
For more information on this announcement, please contact:
GMTA (German Machine Tools of America)
4630 Freedom Drive
Ann Arbor, MI 48108
Phone: 734-973-7800
Fax: 734-973-3053
Web: www.gmtamerica.com
Email: scott@gmtamerica.com
Attention: Scott Knoy, VP
Connect with GMTA online:
No. 806 is a 500ºF (260ºC), electrically-heated walk-in oven from Grieve, currently used for paint baking operations at the customer’s facility. Workspace dimensions of this oven measure 72” W x 96” D x 78” H. 100 kW are installed in Incoloy-sheathed tubular elements to heat the oven chamber, while a 10,000 CFM, 7-1/2-HP recirculating blower provides combination airflow to the workload.
This Grieve walk-in oven features 4” insulated walls, aluminized steel exterior and interior, removable top-mounted heating chamber and a fully insulated floor. The oven is built with all safety equipment required by NFPA Standard 86 for flammable solvents, including a powered forced exhauster, airflow safety switch and purge timer.
Other controls on No. 806 include a fused disconnect switch, digital temperature controller and manual reset excess temperature controller.
For more information, please contact:
THE GRIEVE CORPORATION
500 Hart Road
Round Lake, IL 60073-2898
Phone: (847) 546-8225
Fax: (847) 546-9210
Web: www.grievecorp.com
Email: sales@grievecorp.com
Attention: Frank Calabrese, VP
Siemens has added new applications to its “Sinumerik Integrate for production” software
suite for networking machine tools with production-level IT systems.
Siemens has added new applications to its “Sinumerik Integrate for production” software suite for networking machine tools with production-level IT systems. The new release now includes Manage MyMaintenance (MMM), an effective maintenance-tasks management system, and Access MyData (AMD), a set of open interfaces that now allows direct access to machine and process data.
Access MyData offers an interface to access machine and process data of machine tools controlled by the Sinumerik 840D sl CNC. To allow data communication, the machine tool is directly connected to the Sinumerik Integrate server at the customer’s site.
AMD Basic is available free-of-charge and enables the direct reading and writing of NC and PLC data from the Integrate application server. Purchasing extensions to AMD Basic allows machine tool data to be processed and NC part programs transferred via a file transfer interface.
Manage MyMaintenance enables small and medium-sized companies to enter the world of maintenance management without any additional investment. MMM automatically instructs the user, as soon as a new maintenance date is scheduled for a machine. The time and tasks to be performed are presented in a clearly laid out list.
Self-explanatory color-coding indicates which measure is overdue and which has
not yet reached its deadline. A number of maintenance tasks can be defined and intervals specified. The software is easily installed via the Sinumerik Operate graphical user interface without any programming effort.
Background information:
The Sinumerik Integrate for production software suite includes applications for simple management of machine tools and part programs, transparent recording of machine states and production data, as well as the remote maintenance of machines installed
all over the world.
—
For specific product information and inquiries, call (800) 879-8079 ext. Marketing Communications or send an e-mail to: SiemensMTBUMarCom.industry@siemens.com.
Follow us on Social Media:
Twitter: www.twitter.com/siemens_cnc_us
Facebook: www.facebook.com/SiemensCNC
The Siemens Industry Sector is the world’s leading supplier of innovative and environmentally friendly automation and drive technology, industrial software and technology-based services. The Sector’s comprehensive portfolio covers the entire industrial value chain, from product design, engineering and production to services. Siemens enhances its customers’ productivity, efficiency, and flexibility in a wide variety of different industries. With a global workforce of more than 100,000 employees, the Industry Sector comprises the Divisions Industry Automation, Drive Technologies and Customer Services as well as the Business Unit Metals Technologies.
Continue reading
The Sinumerik blackline panels from the Siemens are a new generation of operator panels
for the Sinumerik 840D sl CNC system and offer new options for machine tool operation.
The Sinumerik blackline panels OP 015 black and OP 019 black are a new generation of operator panels for the Sinumerik 840D sl CNC system and offer new options for machine operation. The inductive sensor technology enables rapid interaction with the user interface even when the operator is wearing gloves. Similarly, it prevents incorrect entries, for example caused by the heel of the operator‘s hand.
The 19-inch display of the OP 019 black can show all the entries made in widescreen format at a glance. The OP 015 black also features an alphanumerical keypad on the right that can be operated via touch control. This feature means that the 15-inch display is not restricted by the superimposed keypad during data entry, which ensures clear and efficient operation. Both blackline panels also have an integrated glass panel on the front side and are designed with IP65 (OP 019 black) and IP66 (OP 015 black) degrees of protection. They are resistant to liquids and dust and can be operated even under harsh industrial conditions. An integrated key lock helps safeguard against operating errors. The operator panel can provide a basic machine display, with three or four channels showing up to 13 axes.
The blackline panels also feature durable LED background lighting, providing 40 percent energy-savings compared to conventional neon lamps.
In combination with the Sinumerik 840D sl control, for use on high-end milling, turning, grinding and laser cutting machine tools, the blackline panels can be used as an operating and programming station for aerospace composite machining, power generation and medical part manufacturing, in addition to tool- and mold-making, rotary indexing machines and in shopfloor manufacturing.
For specific product information and inquiries, call (800) 879-8079
ext. Marketing Communications or send an e-mail to: SiemensMTBUMarCom.industry@siemens.com
Follow us on Social Media:
Twitter: www.twitter.com/siemens_cnc_us
Facebook: www.facebook.com/SiemensCNC
The Siemens Industry Sector is the world’s leading supplier of innovative and environmentally friendly automation and drive technology, industrial software and technology-based services. The Sector’s comprehensive portfolio covers the entire industrial value chain, from product design, engineering and production to services. Siemens enhances its customers’ productivity, efficiency, and flexibility in a wide variety of different industries. With a global workforce of more than 100,000 employees, the Industry Sector comprises the Divisions Industry Automation, Drive Technologies and Customer Services as well as the Business Unit Metals Technologies.
Continue reading
Siemens has put together a scalable package of coordinated automation and drive components specifically for tapping centers. It consists of the Sinumerik 828D compact CNC with new panel processing units PPU2xx.3 of various performance classes as control hardware and the new variant of the Sinamics S120 Combi drive with triple overload capability. The package is completed with the new Simotics M-1PH8 Premium Performance main motor, which can achieve high speeds.
The productivity of tapping centers can be increased considerably due to the specially coordinated components, the powerful control system hardware, the converter with enhanced overload resilience and the high-speed main motor from Siemens. For example, the spindle can be started up from 0 to 24,000 revolutions per minute in less than one second. This saves considerable time, particularly with tapping center applications featuring frequent tool changes.
The Siemens range is also especially suitable for the increasing number of applications with freeform surfaces and high surface quality, for example cell phone components, which are manufactured with small high-speed cutting (HSC) tools and have short machining times. The tapping center’s maximum machine dynamics can be utilized to the fullest extent with the scalable performance spectrum, for example the different control hardware variants PPU 260.3 or 280.3 for the Sinumerik 828D compact CNC.
Background information
Tapping centers are designed as machine tools with small work spaces for milling, drilling and thread machining, and are frequently used to manufacture hard disk and mobile phone housings, for example. These are made out of lightweight materials using small tools and at high speeds.
—
For specific product information and inquiries, call (800) 879-8079 ext. Marketing Communications or send an e-mail to: SiemensMTBUMarCom.industry@siemens.com.
Follow us on Social Media:
Twitter: www.twitter.com/siemens_cnc_us
Facebook: www.facebook.com/SiemensCNC
The Siemens Industry Sector is the world’s leading supplier of innovative and environmentally friendly automation and drive technology, industrial software and technology-based services. The Sector’s comprehensive portfolio covers the entire industrial value chain, from product design, engineering and production to services. Siemens enhances its customers’ productivity, efficiency, and flexibility in a wide variety of different industries. With a global workforce of more than 100,000 employees, the Industry Sector comprises the Divisions Industry Automation, Drive Technologies and Customer Services as well as the Business Unit Metals Technologies.
Continue reading
Three new functions for the Sinumerik Operate operator interface simplify the operation of turning and milling machinesSiemens has added three new functions to the Sinumerik Operate graphical user interface making it easier to operate turning and milling machines. A new program management system, plain text reading in the high-speed setting cycle, and the new retraction function support operators during standardized turning and milling operations using the Sinumerik 828D compact CNC — or in high-end applications using the modular Sinumerik 840D sl CNC.
The Sinumerik Operate program manager has been supplemented with a new program management system providing direct access to all connected drives. Users can now work simultaneously on all connected drives and their file structures. In addition, a larger number of different file formats can be displayed than before.
In the powerful cycle package of Sinumerik Operate, the high-speed setting cycle has been simplified by plain text reading for a host of machining methods. This high-speed setting cycle supports machine tool operators in all tool- and mold-making applications by transferring the machining tolerance.
In the new version, machining methods such as roughing, pre-finishing or finishing can be output as plain text, and the orientation tolerance can also be entered. Users only have to specify a few parameters for this purpose.
The new retraction function in Sinumerik Operate now supports users when retracting a tool following an interruption caused, for example, by power failure or NC reset.
In JOG mode and in the swiveled machine state with Cycle800 or Traori five-axis transformation, machining can now be continued from the point of interruption following manual recovery.
—
For specific product information and inquiries, call (800) 879-8079 ext. Marketing Communications or send an e-mail to: SiemensMTBUMarCom.industry@siemens.com.
Follow us on Social Media:
Twitter: www.twitter.com/siemens_cnc_us
Facebook: www.facebook.com/SiemensCNC
The Siemens Industry Sector is the world’s leading supplier of innovative and environmentally friendly automation and drive technology, industrial software and technology-based services. The Sector’s comprehensive portfolio covers the entire industrial value chain, from product design, engineering and production to services. Siemens enhances its customers’ productivity, efficiency, and flexibility in a wide variety of different industries. With a global workforce of more than 100,000 employees, the Industry Sector comprises the Divisions Industry Automation, Drive Technologies and Customer Services as well as the Business Unit Metals Technologies.
Continue reading
Siemens has developed new control hardware with greater computing power for its panel-based Sinumerik 828D and Sinumerik 828D Basic compact CNCs for turning and milling applications.
Siemens has developed new control hardware with greater computing power for its panel-based Sinumerik 828D and Sinumerik 828D Basic compact CNCs for turning and milling. The new PPU2xx.3 panel processing units replace the previous PPU2xx.2 generation and are available for all six versions of the Siemens compact CNC.
The greater computing power has significantly accelerated the operating speed of the Sinumerik Operate graphical user interface during commissioning, programming and operation. For example, when changing operating areas, the screen forms are loaded almost twice as fast as before.
The new PPU2xx.3 hardware for Sinumerik 828D and Sinumerik 828D Basic has a more rugged design than the previous version so that it can be used in harsh industrial environments, and it is also better protected against wiring errors during installation in a control cabinet. Additionally, the Sinumerik 828D Basic can now also be used for turning and milling on one piece of hardware. This reduces costs, especially in regards to spare parts.
PPU2xx.3 has the same dimensions and connectors and is fully compatible with version PPU2xx.2. This ensures trouble-free conversion to the new hardware, which requires Sinumerik 828D V4.5 SP3 software or higher.
For more information about Siemens CNC solutions for the machine tool industry, visit our website: www.usa.siemens.com/cnc.
For specific product information and inquiries, call (800) 879-8079 ext. Marketing Communications or send an e-mail to: SiemensMTBUMarCom.industry@siemens.com.
Follow us on Social Media:
Twitter: www.twitter.com/siemens_cnc_us
Facebook: www.facebook.com/SiemensCNC
—
The Siemens Industry Sector is the world’s leading supplier of innovative and environmentally friendly automation and drive technology, industrial software and technology-based services. The Sector’s comprehensive portfolio covers the entire industrial value chain, from product design, engineering and production to services. Siemens enhances its customers’ productivity, efficiency, and flexibility in a wide variety of different industries. With a global workforce of more than 100,000 employees, the Industry Sector comprises the Divisions Industry Automation, Drive Technologies and Customer Services as well as the Business Unit Metals Technologies.
Continue readingSUHNER introduces a new and re-designed version of its BEX15 machining unit, capable of a spindle speed increase from 18,000 rpm to 23,000 rpm
Chip producing machining operations with modern tools today demand progressively higher cutting speeds, specifically for metals with high cutting speed rates or small diameter hole drilling applications. The SUHNER machining unit type BEX15, proven in thousands of installations, now provides new speed options, reliably up to the maximum speed limit. With an increase of 25% up to a permissible maximum spindle speed of 23,000rpm, operations requiring higher spindle speeds can be accomplished more easily.
This improvement is the result of a complete redesign of drive and spindle bearing components. A new style timing belt drive multiplies the motor speed up to 13,050rpm spindle speed. An AC-inverter drive is used to increase the spindle speed up to 23,000rpm at 87Hz.
The machining unit BEX15 can be applied in axial and radial orientation, directly mounted to a SUHNER slide assembly type UA15-PH or UA15-CNC. In this combination, numerous machining operations such as milling or demanding drilling cycles, including jump or peck feed, can be accomplished very easily.
Four optional tool holder systems (Collet ER25, ISO30, HSK50 and Weldon) , standard air purge connections for spindle and belt housing including a number of additional options (for example: coolant through the spindle or automated tool change features), make this machining unit type BEX15 highly adaptable and an optimal choice for demanding and specific machining requirements.
SUHNER INDUSTRIAL PRODUCTS, CORP.
Hwy 411 S./Suhner Drive
P.O. Box 1234
Rome, GA 30162
Phone: 706-235-8046
Fax: 706-235-8045
Attention: Lee Coleman, Automation Division
www.suhner.com
automation.usa@suhner.com
Text and pictures files can be found and down loaded at:
www.suhner-press.com
Jim Wirtz Service Manager
Bartlett, IL (Chicago) – REP Corporation, longtime leader in injection and other molding presses for rubber and TPE, announces the appointment of Jim Wirtz as Service Manager for the company, effective immediately. The announcement was made at company headquarters by REP Corporation President Tim Graham.
Wirtz brings nearly a lifetime of experience in the rubber molding industry to REP, as his family owns and operates Wirtz Manufacturing, likewise a longtime leader in injection molding, based in Michigan, where Jim learned the business from all aspects of mold design and contract production. When the family business redirected itself into battery manufacturing in the mid-1990’s, Jim’s passion for the rubber molding industry continued, as he helped design and construct various manufacturing facilities across the United States, in the rubber industry. “My entire working life has been centered around the rubber injection and extrusion business. It is an honor to be part of REP Corporation and the REP International global network, staying in the industry where my grandfather, father and I have all spent our careers. It’s where I belong,” Jim notes.
Jim will be responsible for the service department and field technician network of REP, a leading supplier of injection, compression, transfer molding, plus tiremaking and devulcanization machinery.
For more information, please contact:
REP CORPORATION
8N750 Tameling Court
Bartlett, IL 60104
Phone: 847-697-7210
Web: www.repinjection.com
Attention: Tim Graham, President
