Ansteel orders system with two cutting heads to process steel and aluminum coils for the automotive industry
Chinese steel maker Ansteel has ordered the first Schuler laser blanking line for Asia.
Canton, Michigan – Ansteel is one of the largest steel producers worldwide and also known as the “cradle of steel industry” in China which contributed significantly to the rapid economic growth of the People’s Republic. Now, the company will also be the first Schuler customer in Asia to install a laser blanking line. This is also the first system worldwide that features two cutting heads for the processing of coil material with a width of up to 1,880 mm (74”).
Laser cutting systems for blanking lines have proven their reliability and high output in the series production of outer body parts already in Europe – another one will be delivered to the U.S – and are particularly suitable for production processes with frequent product changes, since no dies are needed. Schuler’s innovative DynamicFlow Technology enables a highly dynamic cutting process and high strip speeds for the coil material which is continuously moving forward. This process leads to an increased output and higher system availability, while also ensuring gentle transport of sensitive materials such as aluminum.
The new Laser Blanking Line 2.18 has two powerful cutting heads and can be used to produce blanks for various components made of coil material with a width up to 1,880 mm (74”). It is a cost-optimized alternative to the Laser Blanking Line 3.21 with three cutting heads, which is particularly suitable for the efficient production of outer skin blanks with a coil width of up to 2,150 mm (84”). It provides a wide range of options to optimally adapt the system to customer needs and has been successfully in production for several years now.
For more information, please visit:
www.schulergroup.com/laserblanking
For further information on Schuler Inc., North America, please contact:
Jeferson Valerio, Director of Sales
Schuler Incorporated
7145 Commerce Blvd.
Canton, MI 48187 USA
734-207-7200
info@schulerinc.com
www.schulergroup.com
About the Schuler Group – www.schulergroup.com
Schuler is the technology and global market leader in the field of forming technology. The company provides presses, automation solutions, dies, process expertise and service for the entire metalworking industry and for lightweight automobile construction. Its customers include automobile manufacturers and automotive suppliers, as well as companies from the forging, household appliance, packaging, energy and electronics industries. Schuler is a leader in coin minting presses and implements system solutions for various high-tech industries. The company generated 1.233 billion euros in sales in the 2017 fiscal year and has a presence in roughly 40 countries with approx. 6,600 employees. Schuler is majority-owned by the Austrian ANDRITZ Group.
About Ansteel Group Corporation Limited – http://en.ansteel.cn
Ansteel is a state-owned steel producer headquartered in Anshan, Liaoning. The company originated from a merger and reorganization of Anshan Iron and Steel Group Corporation, which was the first large-sized steel maker of the New China, and Pangang Group Co., Ltd., the largest vanadium manufacturer in the world. Ansteel has seven production bases in China as well as in Karara, Australia. The production capability amounts to 39 million tons of raw steel, 3,000 steel grades and more than 60,000 specifications of high-tech products which are sold to dozens of industries such as automotive, machinery, home appliances and so on in over 60 countries and regions.
Continue readingLongtime tooling authority Preben Hansen to lead new company
Heimatec Inc., a market leader in live tooling for the North American machine tool industry, announced today that it will become part of a new corporation, Platinum Tooling Technologies, Inc. The announcement was made by the longtime president of Heimatec, Inc., Preben Hansen, who will lead the new company as its president and COO, holding a majority stake in its ownership. Mr. Hansen is a 30-year veteran and recognized authority in the machine tool industry for tooling and its applications.
“I’d been pondering this move for some time and, after considerable discussions with Heimatec GmbH, Tecnicrafts Industries, Henninger GmbH, and other principals we represent, it seemed time to make this decision and move forward with the new company,” said Hansen, speaking from the Heimatec North American headquarters in Prospect Heights, Illinois, just outside Chicago.
Hansen continues, “The new company will enable us to serve our existing and new market opportunities in a more pro-active fashion.” He cited the recent expansion of the Chicagoland facility, with added office and warehouse space, allowing more staff to be hired and greater inventories to be carried on all lines to be represented by the new company. The Heimatec products will continue to be our main focus but we are fully committed to the growth and success of Tecnicrafts and our other product lines.
Other developments in the works, Hansen states, include additional lines of machine tool accessories and related machine components. Heimatec Inc. has been adding various other brand names to its roster over the years, most recently the very successful guide bushing and collet line from the global supplier Tecnicrafts Industries. Tecnicrafts manufacture products made specifically for the Swiss machine tool market. Platinum Tooling will make a further investment to this line with extensive inventory and the purchase and installation of a grinding machine. Bringing this process “in house” will improve delivery times and strengthen market position.
Additional personnel and sales representative firms are being sought to augment the existing team, Hansen notes. “Nothing will change in our interaction with current customers, reps and distributors. We’ll be enhancing our capabilities, however, with more application engineering, service technicians and staff dedicated to the specific tooling lines we represent. In that way, our value proposition and overall service package to the industry will rise to new heights.”
A new website has been developed for Platinum Tooling Technologies, Inc., as well, www.platinumtooling.com.
For more information on all these developments, please contact:
Preben Hansen, President
Platinum Tooling Technologies, Inc.
16 East Piper Lane, Suite 128
Prospect Heights, IL 60070
847-749-0633
www.platinumtooling.com
phansen@platinumtooling.com
Exact Metrology will exhibit at this year’s Power-Gen International held in Orlando, Florida. Celebrating 30 years, Power-Gen focuses on all forms of power generation and brings together key suppliers and service providers with influential decision makers in the international power generation sector.
At this show, Exact Metrology’s objective is to connect with companies that produce parts or assemble them. These can be part manufacturers such as: pumps, housing turbines, etc. Likewise, they can be the facilities that assemble these complex parts. Exact’s target personnel includes manufacturing engineers, quality control, quality assurance, design engineers and project managers.
Exact Metrology offers the technology that users need in the power generation market. Some of the typical equipment used includes laser trackers, LIDAR scanners (Leica scan station, Surphaser), white light scanners and blue light scanners. Additional featured equipment are Romer arms and CT scanners.
The power generation market has many applications. Some of these are part qualification, part inspection, reverse engineering, part fit-up and facility scanning. Others include facility modeling, BIM modeling, color map inspections, as-built modeling and design intent modeling.
Exact Metrology will be at booth 4211 at Power-Gen between December 4 and December 6, 2018.
For more information, please contact:
Dean Solberg
Exact Metrology, Inc.
20515 Industry Avenue
Brookfield, WI 53045
Phone: 262-533-0800
Local: 866-722-2600
www.exactmetrology.com
deans@exactmetrology.com
or
Steve Young
Exact Metrology, Inc.
11575 Goldcost Drive
Cincinnati, OH 45249
Phone: 614-264-8587
Local: 513-831-6620
www.exactmetrology.com
stevey@exactmetrology.com
Exact Metrology, with facilities in Cincinnati and Milwaukee and affiliated offices throughout the Midwest, is a comprehensive metrology services provider, offering customers 3D and CT scanning, reverse engineering, quality inspection, product development and 2D drawings. The company also provides turnkey metrology solutions, including equipment sales and lease/rental arrangements.
Continue readingIn addition to the five euro coins with a polymer ring, machines from the Schuler Group will now also be used to produce similar ten euro coins
Canton, Michigan – Today marks the start of production for a new ten euro collector’s coin featuring a colorless polymer ring at the Karlsruhe Mint of the State Mints of Baden-Wuerttemberg in Germany. The first coins were officially struck in a ceremony attended by Baden-Wuerttemberg’s Finance Minister, Edith Sitzmann. These “tri-material” coins are produced on a joining machine, which connects the polymer ring to the metallic core and outer metallic ring, and on minting presses from the Schuler Group.
The front face shows a paraglider set in a mountainous landscape, while the back face includes an eagle, an inscription reading “Bundesrepublik Deutschland” (Federal Republic of Germany), and the twelve stars of Europe. The 9.7-gram coin is the first issue of what is to be a three-part series entitled “Air Moves.” It will be available in the two mint qualities “uncirculated” and “proof” starting in the spring of 2019.
Autumn of the coming year will then see the arrival of the next edition of the five euro collector’s coin. This issue, which will feature a green polymer ring, will also be produced using Schuler technology. The front face will depict a European hare representing the temperate latitudes in the “Climate Zones of the Earth” series. The coins are extremely popular among collectors and non-collectors alike.
Additional information will be available at the Technical Forum held on January 31, 2019 in Berlin before the official opening of the World Money Fair.
For more information, please visit:
www.schulergroup.com/minting
www.worldmoneyfair.de
For further information on Schuler Inc., North America, please contact:
Jeferson Valerio, Director of Sales
Schuler Incorporated
7145 Commerce Blvd.
Canton MI 48187 USA
734-207-7200
info@schulerinc.com
www.schulergroup.com
About the Schuler Group – www.schulergroup.com
Schuler is the technology and global market leader in the field of forming technology. The company provides presses, automation solutions, dies, process expertise and service for the entire metalworking industry and for lightweight automobile construction. Its customers include automobile manufacturers and automotive suppliers, as well as companies from the forging, household appliance, packaging, energy and electronics industries. Schuler is a leader in coin minting presses and implements system solutions for various high-tech industries. The company generated 1.233 billion euros in sales in the 2017 fiscal year and has a presence in roughly 40 countries with approx. 6,600 employees. Schuler is majority-owned by the Austrian ANDRITZ Group.
Continue readingThe future of mobility requires sustainability and comfort. Gehring presented its advanced technology solutions for reducing CO2 emissions at a recent technical forum in Querétaro, Mexico.
Farmington Hills, Michigan. The future development impetus of the internal combustion engine will focus on the reduction of emissions. This is dependent on fuel consumption, which in turn is determined by the internal engine friction. The goal of form honing is a form optimized cylinder bore under operating conditions.
Abraham Pizano, Managing Director Gehring-Mexico, presented Gehring’s CO2 emissions reducing technology solutions at a recent technical forum CO2 in Mexico to an audience of leading technical and business professionals, from a wide variety of industries, including automotive, aerospace and industrial.
The conference is one of the region’s top technical events for manufacturing, featuring the latest in global manufacturing trends, including processes, applications, materials and advanced techniques.
Gehring developed a surface finishing process for ICE’s which does not target a cylindrical bore shape. The bore shape is based on the distortions of the geometry under operating conditions of the engine. Through the means of form honing the reverse shape will be produced so that in running conditions, a cylindrical shape exists. The deformation in the operating condition depends on static assembly distortions and thermal cylinder distortions.
This technology can be subdivided into two process variations, form honing light and form honing professional. Form honing light simulates thermal distortion by creating different tapered shapes. The thermal expansion due to the higher taper in the top dead center leads to a cylinder bore which has to be honed to a smaller size at the top and a larger size at the bottom. Thus, the piston shirt has less contact with the bore. This results in significantly less friction.
The conical shape is generated by feedback controlled stroke displacement with higher stock removal in the lower bore section due to increased contact time of the abrasives.
The dynamic electro-mechanical feeding changes the radial expansion position of the honing stones during the stroke movement according to the form and improves herewith the previous conical shape.
These process components assure the reliable process of round non-cylindrical tapered bores within the known cycle times. Form honing has been already integrated globally into mass production scenarios. Application of form honing light technology has shown that significant improvements in emissions reductions are possible.
Form honing professional not only optimizes the local piston clearance, but also compensates for cylinder deviations from static and thermal distortions. That means that in running conditions round and straight bores can be achieved. Ring tension is reduced which results in adaptive friction and C02 reductions.
The non-cylindrical shape deviations can be defined through CAE assessments or torque plate bracing and tempering. In order to be able to implement form honing professional, innovative processing hardware like special honing tools with independent actuated abrasives, a piezo feeding system, a shape adaptive control and a spring loaded finish honing tool, is necessary.
The shape data for the cylindrical deviations will be converted for every single cylinder of the engine using the form honing control. This dynamic process interaction between the feeding system, shape and the form honing tooling creates an optimal result.
Form honing professional has been implemented by customers for small production batch scenarios. The process produces cylinder deviations and surface finish profiles with high reproducibility and economical processing times. The process delivers free shapes and surface profiles with high reproducibility to conditions that still conform to cycle times.
The advantages of form honing have been recognized by engine manufacturers and have been implemented in numerous production lines on Gehring honing machines worldwide. Further series applications are in preparation.
About Gehring
For more than 90 years, Gehring has been the leader in the domain of honing technology, supplying cutting-edge surface finish technology solutions for internal combustion engines, gears and numerous other industrial applications. As a global technology leader, the company is represented internationally in key markets in the automotive and supplier industries, hydraulics and pneumatics, as well as aerospace sector.
The Gehring product portfolio ranges from individual honing stones to honing tools as well as gauging and automation solutions right up to integrated honing systems. Digital applications, services and innovative technologies in the areas of honing, laser structuring, roughening and coating complete the portfolio.
With standalone made-to-measure solutions for stator prototype development and small-scale series production, as well as fully automated new system solutions for electric motor production lines, copperING‘s product portfolio complements that of its new partner Gehring. The Gehring group therefore offers the full gamut of technologies for vehicle drives – from conventional solutions to hybrid technologies and even integral electrification.
The Gehring Group with approx. 800 employees, is headquartered in Ostfildern, Germany, and has additional locations in Naumburg and Wernigerode, Germany, as well as in the USA, China, India, Italy, UK, France, Brazil and Mexico.
For additional information and image material:
Jaqueline Fette (Director of Marketing)
Tel: +1 248 427-3943
Cell: +1 248 954 8383
E-Mail: jaqueline.fette@gehring-group.com
Gehring L.P.
24800 Drake Road
Farmington Hills, Michigan 48335
www.gehring-group.com
Suhner has teamed up with Velocity Products to maintain the SU-matic line at the highest level of quality and functionality
Suhner has just announced their partnership with Velocity Products on the repair and maintenance of SU-matic tooling. Velocity is the premier distributor of Tooling for Okuma, as well as innovative machine tools throughout North America. Velocity/SU-matic tooling is designed and manufactured by SU-matic, a worldwide leader in tooling technology. SU-matic works closely with engineers from Okuma when designing new tools. The collaboration ensures flawless tooling performance on lathes, multi-tasking machines and machine tools.
Velocity has experienced staff who can maintain tools at the highest standard required by OEM clients. Walter Scheppe has over 30 years of experience in maintaining and repairing tools. He has fixed lathe tooling, angle heads, multi-spindle heads and specialty tooling. The Velocity/SU-matic Preventive Maintenance Program uses the expertise of Walter and his team to keep the SU-matic tools running smoothly.
The Preventive Maintenance Program offers 72 hour inspection turnaround, inspection of radial and axial play and a six month guarantee on repairs. In addition, Velocity/SU-matic tooling is guaranteed for two years; at the end of the two years, you can send your tools to the Velocity/SU-matic repair center for inspection, and if needed, return your tools to original factory specifications. The repair center is in Suhner’s new location, at 43 Anderson Road, Rome, GA 30161.
Commenting on the partnership, Bob Bauer, the Vice President of Velocity Products, said, “I’m proud for the partnership we have formed with Suhner, as this allows us to provide a timely and high-quality service to Okuma.”
For more information, please contact:
SUHNER Industrial Products Corp.
Lee Coleman, National Sales Manager-Machining Division
43 Anderson Road SW
Rome, GA 30161 USA
Direct: 706-314-2927
Mobile: 706-409-1876
Fax: 706-235-8045
lee.coleman@suhner.com
www.suhner.com
Company moving HQ to Kodak, Tennessee, near Knoxville; plans to retain Chicago area facility for sales and service of its molding machinery
REP Corporation (Bartlett, Illinois), the market leader in rubber molding machinery, today announces plans to relocate their corporate headquarters to Kodak, Tennessee, near Knoxville. The new facility is currently under construction and will be open in early 2019, according to company President Tim Graham. From the new location, REP Corporation will conduct sales, service, engineering and machine demonstrations, plus parts warehousing, for customers in North America. REP Corporation is a subsidiary of the REP International, based in Lyon, France.
REP Corporation management shown with Mayor Larry Waters of Sevier County, Tennessee, upon completion of the agreement to relocate the corporate headquarters. Shown left to right: Brian Boyle, Regional Sales Manager Jeff Tanner, Regional Sales Manager Josh Beachum, Technical Director James Wirtz II, Aftersales Director Larry Waters, Mayor Sevier County Timothy Graham, President REP Corporation Derek Williams, National Sales Director Anna Seel, Accounting Director
Plans include the employment of approximately 20 people for administration, engineering, sales and field service. REP Corporation currently maintains an install base of more than 3000 machines and has been selling in the North American market since 1970.
The current facility in Bartlett, Illinois near Chicago, will be maintained as a sales and service office for the company.
Aftersales Director Jim Wirtz explains, “We began our search about two years ago, recognizing the migration of the rubber industry to the South, as it follows the primary automotive OEM. We were impressed by the efforts of Sevier County in Tennessee, especially Sevier County Mayor Larry Waters plus Allen Newton and his team at the Economic Development Council. This is a major step for REP, as we’ve occupied essentially the same location in Chicagoland since we began here in 1970. We look forward to broadening our presence in the country and becoming part of this vibrant new industrial community in Kodak.”
Technical Director at REP, Josh Beachum, adds, “One of the strong factors in our decision was the talent pool of young engineers in this area, combined with the technical training options available to us. The rubber molding business has a very unique set of chemistries and manufacturing technologies that require ongoing training and mastery.”
Anna Seel, the Accounting Director at REP Corporation, notes, “We will provide very competitive wages and benefit package to our new employees, most of whom will come from the local community. This second location will help us provide support to our customers more effectively.”
National Sales Director Derek Williams further states, “This move represents an opportunity to support our transplanted existing customers who have followed the auto industry to the South, plus the newly emerging markets here.”
Tim Graham, concludes, “We’ve received a very enthusiastic welcome from the local business community here, making this decision to relocate from our longtime Chicago headquarters an easier move.” He added the company plans to relocate immediately upon completion of the new facility, located in the Smith-Thomas Technology Park in Kodak.
REP provides the North America rubber industry with a full range of injection and compression presses, plus laser mold cleaning and other ancillary equipment, as well as REP Pack 4.0, its proprietary software suite for the management of all press parameters and machine kinematics, providing manageable data for the digital factory and Industry 4.0, the rapidly advancing standard for rubber factory operations.
For more information on this announcement, please contact:
REP Corporation
8N740 Tameling Court
Bartlett, IL 60103-8146
Phone: 847-697-7210
www.repinjection.com
Attention: Tim Graham or Jim Wirtz
Automated extrusion process drastically changes the extruded profile
Guill Tool, a global manufacturer of extrusion tooling, has released its new reciprocating head. The traditional tip and die assembly is replaced with a linear reciprocating assembly that changes the tube’s profile within a given length. This process is repeated throughout a single extrusion run without interruptions. Cutting capability, in association with the extrusion speed, cuts the finished product to length.
While cost and value stream activities are reduced, quality is improved. Only one extrusion run is needed to produce a finished product, as opposed to multiple extrusion runs with tooling changes along with a manual assembly operation to connect different tubing shapes. Guill’s new reciprocating head eliminates an assembly operation. It also eliminates in-process inventory. Thus, there is no need for storage of various tubing shapes and connectors needed for assembly, fulfillment of orders and replenishment of finished goods.
Furthermore, the reciprocating head eliminates a connecting piece, allows JIT production and products made-to-order. Lastly, it reduces total run time from receiving the order to shipping.
For more information, please contact:
Bill Conley, Sales Manager
Guill Tool & Engineering
10 Pike Street
West Warwick, RI 02893
USA
Telephone: 401-828-7600
www.guill.com
bconley@guill.com
The full line of WEMA grinding machines includes internal, universal, external, roller bearing, and customized solutions.
German Machine Tools of America is now the North American distributor of WEMA Glauchau GmbH. These high precision grinding machines will be shown by GMTA at IMTS 2018.
WEMA 6SU Universal Grinding Machine
WEMA’s internal grinding machines maximize operating times with more efficient and integrated procedures. A repeatedly allocable tool and workpiece headstock are guided on up to six axes with an accuracy of 0.1 μm. WEMA SI is scalable and is adapted to the clients’ needs through specific mounting for the greatest machining efficiency. Powerful drives ensure quick availability with additional work and peripheral modules reducing costly non-productive times. Available in 4 different series (S2I, S3I, S6I and S10I), it offers machining of chuck and shaft-shaped parts. In addition, the internal grinding machines are equipped with internal cylinder/ cone, internal polygons, internal screw threads, up to 4 applicable grinding tools and high rigidity through the use of cast beds/hydropol beds.
With WEMA SU, universal grinding machines are available for the complex task of three-way machining of all major workpiece sizes. The machines are equipped with external and internal grinding units. Clamping operations provide decisive efficiency and precision benefits. WEMA’s technology enables machines to perform highly complex operations, while peripheral modules permit greater flexibility. These machines’ features include up to 3 swivel axes, machining of 4 sides in one clamping operation, machining of chuck and shaft-shaped parts and external grinding wheels with a maximum diameter of 600 mm. WEMA SU also offers additional features such as: 4 insertable internal grinding tools, 4 external grinding tools and cones, polygons, etc.
The company’s external grinding machines can machine parts up to 1,500 kg with external lengths of Ø 600 mm and 2,700 mm. Grinding wheels are available in Ø 500, 600, and 750 mm. Typical workpieces include railway axles, rollers, pipes and shafts.
Assemblies of the roller bearing grinding machines feature a strict modular structure used for various operations. One is for sequential internal, external and rim machining operations. Another is for simultaneous internal and external machining operations. Other modular structures are used for external machining operations, internal machining operations and rim machining operations. Machining jobs can be carried out on single or multi-row outer rings (OR) and inner rings (IR) of diverse bearing types. Notable features on these WEMA machines include three different types of milling centers (SW3, SW6, SW10), grounding of borings and tracks of inner rings, as well as tracks and outer diameters of outer rings. Outside rings have a diameter of approximately 300 mm to 900 mm. Shoulders, rims, etc can also be ground and different grinding operations can be performed in sequential or simultaneous grinding procedures.
Although the company’s grinding machines cover a wide range of possible applications, they also build and design grinding machines to order ranging from more or less customized adaptations to complete designs of the machine.
For more information, please contact:
Scott Knoy
Vice President
German Machine Tools of America (GMTA)
Ann Arbor, Michigan
Office: 734-973-7800
Fax: 734-973-3053
Email: scott@gmtamerica.com
www.gmtamerica.com
Schütte (Jackson, Michigan) now sells SCX, its new multi-spindle automatic lathe.
In today’s industrial production, more complex workpieces are being produced in smaller batch sizes and shorter life cycles. To remain competitive, manufacturers have to react quickly and flexibly to market requirements.
These conditions have been met with the creation of Schütte’s multi-spindle automatic lathes. Everything that is not directly related to the production of workpieces has been eliminated from the machining area. There are no drives, cables, slides, lubrication lines or cooling lines within the tooling area. The clean and freely accessible machining area provides clients with the greatest possible configuration flexibility and the simplest retooling and tool retrofitting.
The SCX from Schütte offers several benefits. Some of these are free speed selection and free falling chips. Furthermore, extended machining options are available on the second workpiece side through exact transfer and three additional spindles. Expansion of the machining range is achieved through extended rear-side machining including C-and Y-axis. Lastly, multi-spindle production provides clients with a wide variety of workpiece geometries.
For further information, please contact:
Brittany Oulch
SCHUTTE USA, LLC
4055 Morrill Road
Jackson, MI 49201
Phone: 517-782-3600 ex.10
www.schutteusa.com
boulch@schutteusa.com
