This Grieve oven is a 400°F (204°C) electrically heated shelf oven, currently used for heat treating parts at the customer’s facility. Workspace dimensions of this oven measure 56” W x 30” D x 60” H. 15 KW are installed for heat input, while a 1000 CFM, 1 HP blower provides side-to-side horizontal airflow to the workload.
This Grieve shelf oven features 6” insulated walls, integrally welded construction, channel shelf supports and nickel-plated wire shelves. Additional features include 304 stainless steel interior and Trilite Green enamel painted aluminized steel exterior.
Controls on this Grieve oven include a digital indicating temperature controller, manual reset excess temperature controller and separate heating elements control contactors.
For more information, please contact:
THE GRIEVE CORPORATION
500 Hart Road
Round Lake, Illinois 60073-2835 USA
Phone: (847) 546-8225
Fax: (847) 546-9210
Web: www.grievecorp.com
Email: sales@grievecorp.com
Attention: Frank Calabrese
Tool end-users bank cost and time savings with BSB cutters with exceptional large-radii geometry
Discover new possibilities in machining with the latest Barrel Shape Ballnose (BSB) tooltype in ANCA’s up-to-the-minute ToolRoom software. The latest enhancement also includes revamped Double Corner Radius (DCR) Endmills. These endmills constitute a new tool class for machining excellence. Barrel and lens shapes and taper and oval forms are relative market newcomers and are predominantly used in the die mould, aerospace, general machining and power generation industries.
ANCA Software Product Manager, Thomson Mathew said: “The ability to create endmills with a larger-radius edge, permits greater stepover increments. This enables machining with a larger crossover pitch during pre-finishing and finishing operations – improving productivity.”
Shorter cutting distances mean it’s almost like a two for one coupon for longer tool life and faster cycle times.
Thomson adds: “Replacing conventional ballnose and corner radius applications with the large tangential form radius simulates these applications but the outsized cutting diameter is what saves cycle time and cost; and the resulting surface finish is better as well.”
“Bringing these new endmills together with the expert advantages of ToolRoom such as iView and laser compensation, designer edge ballnose, variable helix and tool balancing sets tool manufacturers up with a complete solution and is unique to ANCA software. In addition, a special fluting operation ensures a constant hook angle all the way along the trajectory of the cutting edge resulting in vibration-free tools, with less wear and tear during machining.”
Innovation and flexibility in ANCA’s software has always been an intrinsic partner to tool machines’ functionality. With a legacy of first-to-market software features, this enhancement continues to advance the sophistication and application diversity of ANCA’s dedicated cutting tool software package. Clever features offer customers the machining capabilities needed for today’s market.
Thomson adds: “ANCA has been leading the industry in terms of new features, cycles, cutting tool geometry and functionality in our cutter grinder software for over two decades and this latest release extends this further.”
The upgrade offers wizard-based design for user-friendly operation
Manufacturing complex, sophisticated endmills is made easy with wizard-based BSB design in ToolRoom, suitable also for catalog production.
BSB and DCR tool types are high performance endmill cutters, mainly used for finishing requiring high accuracies. They may be more familiar to some as circular segment or high feed endmills. In the current market, cutting tool manufacturers may be looking to enter new markets and this software release makes diversification with high-quality specialist tools attainable.
This sought after enhancement retains ANCA’s renowned software user-friendliness and completes the ToolRoom RN34 endmill package.
The features of the new market release encompass compensation and accuracy
Compensation methods are covered as ANCA supports manual, iView and LaserPlus compensation for all geometry, as these tools are highly accurate. Both ball radius and tangential barrel form radius can be maintained within +/-0.002 mm using LaserPlus. This accuracy can also be maintained in batch grinding with automatic in-process compensation for large volume production on machines with LaserPlus.
The wizard-based design also provides the option to scale tools and add various other operations like roughing or chip breakers. Wizard support is available for oval form, taper form and also a custom form for specials. A static view gives parameter inputs for geometry description and there is also a dynamic view available to visualize the geometry as and when parameters are entered.
There are multiple practical advantages of ToolRoom software for cutting tool manufactures
For further information, please contact:
Sepideh Zandieh
PR and Communications Manager, ANCA
M: +61 439 316 131
Sepideh.Zandieh@anca.com
ANCA is a market leading manufacturer of CNC grinding machines. It was founded in 1974 in Melbourne, Australia where the company still has its global headquarters. ANCA has offices in the UK, Germany, China, Thailand, India, Japan, Brazil and the USA as well as a comprehensive network of representatives and agents worldwide.
ANCA CNC grinders are used for manufacturing precision cutting tools and components across a diverse range of competitive industries including cutting tool manufacture, automotive, aerospace, electronics and medical.
Continue reading
Exact Metrology, a comprehensive 3D metrology service provider and hardware sales company, recently celebrated the opening of their newest location in Moline, Illinois with a ribbon cutting ceremony. On September 29, 2020, members of the Quad Cities Chamber joined Exact Metrology for the ceremony to officially welcome the company at their new location.
The Quad Cities Chamber is a diverse group of influential business leaders in Western Illinois and Eastern Iowa that work to advance local businesses through advocacy, business connections, financial assistance, business intelligence, promotions, regional marketing, placemaking and leadership development.
Present at the event were Larry Makoben, Jan Mohr, Tushar Patel, Brian Williams, Scott Naumann, Amanda Hess, Ron Crouch, Mark Carlson and Terri Smith. Also present was the mayor of Moline, Stephanie Acri. The team at Exact Metrology included co-president Dean Solberg, general manager Joe Wright and applications engineers Patrick Wigans and Kris Bowers. Besides attending the ribbon cutting ceremony, the guests received a tour of the facility and witnessed product demonstrations.
Dean, Joe, Patrick and Kris scanned a sample part using the Hexagon Absolute Arm 8525 and the Leica Absolute Tracker AT960. The Hexagon Absolute Arm 7-axis delivers tactile probing and laser scanning in a uniquely ergonomic package. It is ideal for high-end portable measurement applications. The articulating arm offers ease of movement and ease of measurement. The Leica Absolute Tracker AT960 is a robust, all-in-one laser tracker that fits in a single flight case and offers high-speed dynamic measurement as standard. Besides offering six degrees of freedom (6DoF), the tracker offers probing, scanning, automated inspection and reflector measurement. The AT960 laser tracker can be easily transported, unpacked quickly and powered up in minutes to deliver high-performance measurement almost anywhere. Dynamic features and flexible functionality give users absolute speed, accuracy and portability.
Speaking about this event, Dean Solberg said, “We were pleased to have members of Quad Cities Chamber visit us at our new location and we’re happy to be part of the local business community. Our hope is to develop a strong collaboration within this community.”
Exact Metrology is ISO, AS9100 Certified as well as FFL and ITAR Registered.
Exact Metrology, with facilities in Cincinnati, Ohio, Moline, Illinois and Milwaukee, Wisconsin, plus affiliated offices throughout the country, is a comprehensive metrology services provider, offering customers 3D and CT scanning, reverse engineering, quality inspection, product development and 2D drawings. The company also provides turnkey metrology solutions, including equipment sales and lease/rental arrangements.
For information, please contact:
EXACT METROLOGY, INC.
Dean Solberg
20515 Industry Avenue
Brookfield, WI 53045
Local: 262-533-0800
www.exactmetrology.com
deans@exactmetrology.com
Tool end-users bank cost and time savings with BSB cutters with exceptional large-radii geometry
October 2020: Discover new possibilities in machining with the latest Barrel Shape Ballnose (BSB) tooltype in ANCA’s up-to-the-minute ToolRoom software. The latest enhancement also includes revamped Double Corner Radius (DCR) Endmills. These endmills constitute a new tool class for machining excellence. Barrel and lens shapes and taper and oval forms are relative market newcomers and are predominantly used in the die mould, aerospace, general machining and power generation industries.
ANCA Software Product Manager, Thomson Mathew said: “The ability to create endmills with a larger-radius edge, permits greater stepover increments. This enables machining with a larger crossover pitch during pre-finishing and finishing operations – improving productivity.”
Shorter cutting distances mean it’s almost like a two for one coupon for longer tool life and faster cycle times.
Thomson adds: “Replacing conventional ballnose and corner radius applications with the large tangential form radius simulates these applications but the outsized cutting diameter is what saves cycle time and cost; and the resulting surface finish is better as well.”
“Bringing these new endmills together with the expert advantages of ToolRoom such as iView and laser compensation, designer edge ballnose, variable helix and tool balancing sets tool manufacturers up with a complete solution and is unique to ANCA software. In addition, a special fluting operation ensures a constant hook angle all the way along the trajectory of the cutting edge resulting in vibration-free tools, with less wear and tear during machining.”
Innovation and flexibility in ANCA’s software has always been an intrinsic partner to tool machines’ functionality. With a legacy of first-to-market software features, this enhancement continues to advance the sophistication and application diversity of ANCA’s dedicated cutting tool software package. Clever features offer customers the machining capabilities needed for today’s market.
Thomson adds: “ANCA has been leading the industry in terms of new features, cycles, cutting tool geometry and functionality in our cutter grinder software for over two decades and this latest release extends this further.”
The upgrade offers wizard-based design for user-friendly operation
Manufacturing complex, sophisticated endmills is made easy with wizard-based BSB design in ToolRoom, suitable also for catalog production.
BSB and DCR tool types are high performance endmill cutters, mainly used for finishing requiring high accuracies. They may be more familiar to some as circular segment or high feed endmills. In the current market, cutting tool manufacturers may be looking to enter new markets and this software release makes diversification with high-quality specialist tools attainable.
This sought after enhancement retains ANCA’s renowned software user-friendliness and completes the ToolRoom RN34 endmill package.
The features of the new market release encompass compensation and accuracy
Compensation methods are covered as ANCA supports manual, iView and LaserPlus compensation for all geometry, as these tools are highly accurate. Both ball radius and tangential barrel form radius can be maintained within +/-0.002 mm using LaserPlus. This accuracy can also be maintained in batch grinding with automatic in-process compensation for large volume production on machines with LaserPlus.
The wizard-based design also provides the option to scale tools and add various other operations like roughing or chip breakers. Wizard support is available for oval form, taper form and also a custom form for specials. A static view gives parameter inputs for geometry description and there is also a dynamic view available to visualize the geometry as and when parameters are entered.
There are multiple practical advantages of ToolRoom software for cutting tool manufactures
For further information, please contact:
Sepideh Zandieh
PR and Communications Manager, ANCA
M: +61 439 316 131
Sepideh.Zandieh@anca.com
ANCA is a market leading manufacturer of CNC grinding machines. It was founded in 1974 in Melbourne, Australia where the company still has its global headquarters. ANCA has offices in the UK, Germany, China, Thailand, India, Japan, Brazil and the USA as well as a comprehensive network of representatives and agents worldwide.
ANCA CNC grinders are used for manufacturing precision cutting tools and components across a diverse range of competitive industries including cutting tool manufacture, automotive, aerospace, electronics and medical.
Continue reading
Exact Metrology, a comprehensive 3D metrology service provider and hardware sales company, performed a recent inspection on molded caps to showcase the power and capability of multi-part inspections at its Brookfield, Wisconsin office.
Computed tomography (CT) scanning is an x-ray methodology yielding 3D results by placing an object on a rotational stage between an x-ray tube and an x-ray detector, rotating the object 360 degrees and capturing images at specific intervals. Furthermore, CT scanners can easily scan multiple parts at the same time. To render the 3D x-ray model of the object or part, the series of images is reconstructed. CT visualization software can slice in any direction to produce optimal views and images required for the analysis of internal configuration and instant CAD comparison. This software can segment multiple scanned parts, creating individual files for each component. These can be analyzed independently, and all statistics can be evaluated.
The GOM CT scanner used by Exact enables the inspection of complex parts based on volume. It produces the finest details visible throughout the component, simplifying initial sampling, tool correction and inspection tasks during production. It captures complex components including the “inner workings” in a single scanning process, so that the user receives a complete image of the test specimen for form and position analysis or nominal/actual comparisons.
This scanner features a 225 kV X-ray source and a high-contrast 3k X-ray detector that generates a very fine pixel grid (3008 x 2512 pixels), laying the foundation for high-precision detection of the measured components. 5-axis kinematics with an integrated centering table make it easier for the user to position the component optimally in the measuring volume, so that the measurement is always performed with the best possible resolution. Additional features include temperature balancing for metrology applications, an I/O port and photogrammetric calibration. Within the measuring volume (diameter: 240 mm, height: 400 mm) several objects can be measured simultaneously in one scan, further reducing processing times. Thanks to the proven GOM technology, the CT ensures high precision and repeatable measurement results. As with all GOM metrology systems, the control of the device, data acquisition and evaluation are combined in a single software package. This means no additional software is required; the chain from recording the raw data to creating the measurement report is greatly simplified.
Using both the scanner and the software, 30 individual inspection reports were generated on these injection molded caps. Statistical results compared all measurements. Sean Plastine, an Exact Metrology Application Engineer and Greg Groth, Division Manager, were involved in this process. They believe it is significant for the company because it reduces the amount of time needed to get results for customers, thus eliminating the need for measuring 30 parts individually with conventional methods such as CMM, laser or structured light.
Exact Metrology is ISO9001, AS9100 Certified as well as FFL and ITAR Registered.
Exact Metrology, with facilities in Cincinnati, Ohio, Moline, Illinois and Milwaukee, Wisconsin, plus affiliated offices throughout the country, is a comprehensive metrology services provider, offering customers 3D and CT scanning, reverse engineering, quality inspection, product development and 2D drawings. The company also provides turnkey metrology solutions, including equipment sales and lease/rental arrangements.
GOM GmbH
GOM develops, produces and distributes software, machines and systems for 3D coordinate measuring technology, 3D computed tomography and 3D testing based on latest research results and innovative technologies. With more than 60 sites globally and more than 1,000 metrology specialists, GOM guarantees professional advice as well as support and service. More than 14,000 system installations improve the product quality and manufacturing processes in the automotive, aerospace and consumer goods industries.
For information, please contact:
EXACT METROLOGY, INC.
Dean Solberg
20515 Industry Avenue
Brookfield, WI 53045
Local: 262-533-0800
www.exactmetrology.com
deans@exactmetrology.com
Kodlin Motorcycle customizes motorcycles based upon bikes from the legendary American brand Harley-Davidson. Sophisticated technology and an easy-to-use control system are essential—which is why the company chose the Sinumerik 828D CNC from Siemens.
There is no denying it: the Kodlin family has motorcycles in its blood. Master blacksmith Fred Kodlin gave his son Len his first motocross bike for his fifth birthday. There was never really any question about what Len would do when he grew up. Today, the father-and-son team runs the Fred Kodlin Motorcycle workshop, founded by Fred Kodlin back in 1984, in the small town of Borken in the German state of Hessen.
The company is highly specialized: together, father, son and 10 employees customize Harley-Davidson motorcycles. Up to 50 motorcycles leave their shopfloor each year, to the great excitement of their new owners. Many customers simply want to have their series-produced bikes adjusted to suit them better, or to look more individual. Other customers come to the company looking for bigger modifications, such as the installation of a big front wheel, which has a very striking effect and is popular among Harley-Davidson fans.
The most passionate bikers, however, want their bikes to be completely personalized. “These unique bikes cannot be beaten in terms of exclusivity. When it comes to design and technology, we make the virtually impossible possible,” explains junior manager Len Kodlin. In some of these models, the only thing that’s left is the engine, with its unmistakable Harley-Davidson sound: the rest of the bike is made up of components that have been developed and produced entirely by Kodlin. Customers’ budgets are the only thing limiting their imagination. Enthusiasts pay up to $130,000 for these unique cycles. And then, of course, there are also the technical approval restrictions (TÜV, for example).
Avoiding imitations
When fulfilling a customer’s dream of owning a personalized motorcycle, the customizers at Kodlin Motorcycle not only adapt parts, they also manufacture many individual parts themselves. Various styles of footboards, footpegs, turn-signal trim, air filters, engine covers, hand grips and mirror brackets are manufactured individually or in very small series. Outsourcing production could be cheaper in many cases, but for Kodlin, this is not an option. Len Kodlin explains the reasoning behind the decision. “Unique pieces are the basis of our whole company. The risk of copies appearing is simply too great. Our customers pay for something unique and that’s what we give them. This is why we do everything ourselves, from sheet-metal work and welding to milling, turning, painting and assembly,” Kodlin says.
Kodlin has an extremely large range of manufacturing capabilities to prevent imitations and rival products, thus safeguarding its competitive edge. The company invests heavily in production expertise and machinery. Kodlin even has a world manufacturer identifier. This official designation signals that Kodlin is officially a manufacturer that can build and approve motorcycles.
An integrated process from the design to the machine
Anyone who wants to survive the competition as a small, independent customizer needs top-quality CNC machines. That’s why the core of Kodlin’s production process is a PreMill VL 1000 CNC machining center from MMD Werkzeugmaschinen with a Sinumerik 828D CNC system. Len Kodlin, a trained precision mechanic himself, explains what matters to him and his father, “MMD was extremely cooperative and, with the PreMill VL 1000, gave us a machine that meets our needs perfectly. The price/performance ratio was good and with the Sinumerik 828D control—including the intuitive Sinumerik Operate graphical user interface—our core requirement, namely ease-of-operation, was met to our utmost satisfaction.”
The demands on the machine tool and control system are high and diverse. Many simple parts are programmed directly on the machine. For this type of application, it is important for the shopfloor programming to be as simple as it is reliable and efficient. Jan Rosenkranz, a mechanic on the Kodlin team, gets straight to the point, “The ShopMill menu-based navigation makes everything really quick and easy.” He also appreciates the convenient setup functions.
The production of custom parts, which often involves extremely complex contouring, is entirely different. The junior manager creates the programs for these parts separately at an external CAD/CAM workstation and then transfers them to the machine, using a USB stick. This means the machine can remain in operation while the junior manager can design parts for his spectacular creations, far away from production noise, in peace and quiet. Once the blank is in place, the entire machining process itself goes very quickly. With the help of various Sinumerik CNC cycles, the workpiece and the tool are set up quickly and machining on the PreMill VL 1000 can begin.
Len Kodlin specifically mentions the clearly organized folder structure in Sinumerik Operate, which is designed in a similar way to that found on a traditional PC. Meaningful names—such as “Handlebar1-Customer3”—with up to 28 characters can be assigned to the programs. This improves the ability to maintain an overview and products that have already been made can be clearly identified and accessed again at a later date.
The entire production spectrum covered
In terms of production technology, the PreMill VL 1000 offers everything needed for bike parts. The machine gets extra points for its framework construction, which makes it very stable and easily accessible. The majority of the components are less than 500 mm long. However, there are exceptions, such as long fork tubes. With travel paths of X = 1020 mm, Y = 510 mm, and Z = 560 mm, plus a 1200 x 500 mm clamping table, the machine comprehensively covers the spectrum. The 10-kW milling spindle provides the power needed to quickly and precisely machine the parts, which are usually made of aluminum or steel. The changer can be equipped with up to 30 tools and the linear guides on all three axes ensure utmost precision. According to Jens Bubenheim, a sales consultant at MMD, the PreMill VL 1000 achieves a repeat accuracy of ± 3 µm and a positioning accuracy of ± 5 µm, which means that the desired quality is always guaranteed.
A special feature on the Sinumerik 828D CNC scores additional points for high quality, namely the Sinumerik MDynamics technology package with integrated Advanced Surface motion control. The program sequence can be set or adjusted at any time, ensuring that the machine generates an optimal ratio of speed, accuracy and surface quality. Take the turn signal trim, for example. In this case, production accuracy is of less significance. Corresponding settings in MDynamics and the activated Advanced Surface therefore ensure that the machine works with a focus on both surface quality and speed of production.
Contact for journalists and product information:
John Meyer
Marketing Communications Manager
Siemens Industry, Inc.
390 Kent Avenue
Elk Grove Village, IL 60007
T: +1 847 640 1595
E: john.meyer@siemens.com
Website: usa.siemens.com/cnc
Suhner Industrial Products Corp. (Rome, Georgia) is proud to introduce machining units with special guards that protect mechanical and electrical components against contamination from fiberglass dust and fibers, as well as dust from composite and 3D printed products. Suhner offers automated drilling, boring, tapping, threading and other tools for high-production environments on these products throughout North America.
When drilling high quality holes into sheet metal composites and dissimilar material stacks of resin bonded fibers or 3D printed polymer substrates, for example, these dust-protected machining units are an ideal solution. They are universal and can be positioned everywhere alongside the workpiece for precision, automatic machining. Regardless of the complexity of the workpiece or the number of operations that need to be performed, all machining units work at the same time and only the longest operation defines the total cycle time, when the units are used in multiple setups.
Any number of Suhner machining units can be applied from different directions and perform all necessary operations at the same time. Additionally, more operations in a smaller footprint lead to greater time savings, while standard and customized solutions are offered through an optimized modular component system from Suhner. These robust machining units have myriad applications in the automotive, RV, building, appliance, aerospace and electrical industries.
For more information, please contact:
Suhner Industrial Products Corp.
Machining Division
25 Anderson Road SW
Rome, GA 30161 USA
Phone: 706-235-8046
Fax: 706-235-8045
machining.us@suhner.com
Exact Metrology, a comprehensive metrology service provider, recently released the Hexagon RS6 laser scanner, designed for high-speed and accuracy scanning. It scans up to 1.2 million points/sec with a scan rate of 300 Hz. The RS6 also has a wider laser stripe of 150 mm at mid-range and a visual guide that provides real time feedback for stand-off distance.
Built using SHINE technology (Systematic High-Intelligence Noise Elimination), the RS6 laser scanner always delivers full scanning performance, even on the most challenging surfaces. Whether it’s a glossy black plastic automotive body part or a molded carbon-fiber component, this scanner scans without any reduction in quality or productivity. Furthermore, SHINE allows users to scan 99% of parts without touching the scanner exposure. With repeatable mounting (using the Absolute Arm 7 Axis), the scanner can be removed if necessary and replaced without need for calibration. The Hexagon RS6 laser scanner is certified ISO 10360 8on all 7 axis RA8 Absolute Arms.
When compared to other scanners, the RS6 has 3x faster frame rate, 30% wider laser stripe and excellent scanning performance on difficult surfaces with SHINE. With the arm mounted scanner, it is easier to measure due to less preparation, less set up, less settings and scans with full frame, with full line width, all the time.
Exact Metrology is an ISO 9001:2008 and AS9100 Certified Company
Exact Metrology, with facilities in Cincinnati, OH, Moline, IL and Milwaukee, WI and affiliated offices throughout the country, is a comprehensive metrology services provider, offering customers 3D and CT scanning, reverse engineering, quality inspection, product development and 2D drawings. The company also provides turnkey metrology solutions, including equipment sales and lease/rental arrangements.
Exact Metrology offers a complete line of portable scanning and measurement technologies as well as contract measurement for 3D laser scanning services, reverse engineering services, non-contact inspection, metrology services, and 3D digitizing. The company’s newest equipment includes a CT Scanner, the first in America being used for metrology rather than medical testing. Exact sells and rents metrology equipment solutions, in addition to providing testing as a service and application software training.
For information, please contact:
EXACT METROLOGY, INC.
Dean Solberg
20515 Industry Avenue
Brookfield, WI 53045
Local: 262-533-0800
www.exactmetrology.com
deans@exactmetrology.com
EXACT METROLOGY, INC.
Steve Young
11575 Goldcoast Drive
Cincinnati, OH 45249
Local: 513.831.6620
Toll Free: 866.722.2600
www.exactmetrology.com
stevey@exactmetrology.com
Pomona, CA – NOARK Electric is proud to announce the release of the new Ex9CA Safety Contactor. The NOARK Ex9CA Safety Contactor is designed for use in safety function applications. It offers unique features that allow the design of safety control circuits with current ratings up to 38A. The Normally Closed (NC) Auxiliary contact is a mirror contact to the main contacts and is mechanically linked to the Normally Open (NO) Auxiliary contacts. This allows for optimal design selections in SRP/CS*. Applications for the Ex9CA include: E-stops, light curtains, safety gates and safety interlocks.
The NOARK Electric Ex9CA is equipped with a permanent transparent cover that prevents manual operation and provides easy identification of the device status. They are available with either AC or DC operating coils. DC coil models are equipped with integrated surge suppression. Each unit is clearly identified by the prominent red front cover marked with a mechanically linked contact symbol. They install easily on 35mm DIN rail or on panels. Like all NOARK Electric products, the Ex9CA is back by a 5-year limited warranty.
NOARK Electric is a global manufacturer of low-voltage electrical components for industrial manufacturing applications. We specialize in motor controls and protection for original equipment manufacturers. Our mission is to provide customers with the highest quality products at an exceptional value and back them with world-class service and support. Every NOARK product is tested and certified to the highest standards and covered by our exclusive five-year limited warranty.
Source:
NOARK Electric
2188 Pomona Blvd.
Pomona, CA 91768
626.330.7007
na.noark-electric.com
For more information, please contact:
Mark Mathews, Marcom Manager
Phone: 626.330.7007 x. 103 • Email: mark.mathews@noark-electric.com
This Grieve oven is a 1250°F (667°C) inert atmosphere oven, currently used for heat treating firearms components at the customer’s facility. Workspace dimensions of this oven measure 48” W x 48” D x 36” H. 30 KW are installed in Incoloy sheathed tubular heating elements, while a 1400 CFM, 1-1/2 HP recirculating blower provides horizontal airflow to the workload. Inert atmosphere ovens protect parts from oxidation using any non-flammable gas such as nitrogen, argon or carbon dioxide.
This Grieve inert atmosphere oven features 12” insulated walls, all interior seams welded gas-tight, an air jacket on the inner oven for cooling, 16” high integral oven stand, 16-gauge 304 stainless steel interior and enamel-painted aluminized steel exterior. The oven is reinforced for 2000 lb. loads, allowing the customer’s part rack to sit on the oven work space floor.
The oven meets all requirements for inert atmosphere construction, including those in NFPA 86, FM and OSHA standards.
Controls on this Grieve oven include a programmable temperature controller with data logging, capability, 975 CFM cooling blower with air flow safety switch and automatic purge solenoid. An inert atmosphere inlet (1/2” NPT) with pressure regulator maintains positive pressure within the oven.
For more information, please contact:
THE GRIEVE CORPORATION
500 Hart Road
Round Lake, Illinois 60073-2835
Phone: (847) 546-8225
Fax: (847) 546-9210
Web: www.grievecorp.com
Email: sales@grievecorp.com
Attention: Frank Calabrese.
