Company highlights equipment and tools used, applications and the Leica RTC360
Exact Metrology, a comprehensive 3D metrology service provider and hardware sales company, offers a variety of long range (20 feet to entire facilities) high-definition technologies. The company uses high quality equipment from Leica, a Hexagon Metrology company, and Surphaser®.
The tool of choice for long range scanning is LIDAR (Light Detection and Ranging) scanners. It’s a remote sensing method used to detect objects in 3D space similar to the technology used in autonomous self-driving vehicles. A highly accurate and effective surveying method, it uses light in the form of a pulsated laser to measure variable distances.
Long range scanners are typically set up in multiple locations to collect very large data sets. The data set from each location generates a point cloud and each of the point clouds are stitched together to create a 3D space. The stitched point cloud data is then sent directly to the customer or 3D models of the areas are generated to work in any CAD environment. The ability to implement CAD modeling allows tasks to be completed in a fraction of the time as opposed to manual drafting. It also eliminates the need to revisit the area to get that dreaded forgotten measurement or extra detail.
Generally, the CAD models are used for factory/shop floor layout plans, power plant equipment change outs, proof dimensioning and much more. The same data set can also be reused for multiple purposes. It is ideal for large scale interior or exterior buildings, statues and historic architecture preservation.
In addition to the 3D model, full spherical HDR imagining is attached directly to the point cloud giving a photo realistic effect of the data and allowing for virtual walkthroughs of the areas, shareable markups, geo-referencing and meta-tagging. This data can be shared with an unlimited user base via a freeware software.
The Leica RTC360 3D reality capture solution can be controlled through the Leica Cyclone FIELD 360, app, allowing a real time visual of all the customer’s setups and the ability to optimize links of each individual scan to all the setups.
Known for its unsurpassed accuracy and scan quality, long range scanning is ideal for use in reverse engineering, dimensional control, historical preservation, architecture and forensics.
Exact Metrology is ISO, AS9100 Certified as well as FFL and ITAR Registered.
Exact Metrology, with facilities in Cincinnati, Ohio, Moline, Illinois and Milwaukee, Wisconsin, plus affiliated offices throughout the country, is a comprehensive metrology services provider, offering customers 3D and CT scanning, reverse engineering, quality inspection, product development and 2D drawings. The company also provides turnkey metrology solutions, including equipment sales and lease/rental arrangements.
For more information, please contact:
EXACT METROLOGY, INC.
Dean Solberg
20515 Industry Avenue
Brookfield, WI 53045
Local: 262-533-0800
www.exactmetrology.com
deans@exactmetrology.com
EXACT METROLOGY, INC.
Steve Young
11575 Goldcoast Drive
Cincinnati, OH 45249
Local: 513.831.6620
Toll Free: 866.722.2600
www.exactmetrology.com
stevey@exactmetrology.com
Cast-iron motors meet or exceed NEMA Premium® efficiency standards for oil-and-gas/petrochemical, pulp-and-paper, grain and rock processing, other harsh environments
At this year’s annual EASA Convention and Solutions Expo in Fort Worth, TX, Siemens announces the immediate availability of the SIMOTICS SD200 severe-duty motor in frame size 440 as its latest offering in the low-voltage SIMOTICS motor family.
Providing high productivity and energy-efficient operation in all torque ranges, these new cast-iron NEMA motors are built to power pumps, fans, compressors, hoists, winders and similar equipment in harsh environments. With a three-year warranty, the SD200 motors offer 75-800 hp output and feature 444-5013 cast-iron frames for operation in 460V and 575V ranges. They meet or exceed NEMA Premium® MG1 Table 12-12 efficiencies. A wide selection of options is offered, including IP56 ingress protection, encoders, brakes, and blowers plus others to suit the applications presented.
On these motors, the frame, end-shields, fan guard and easy-access, diagonally split, oversized terminal box are all cast-iron. Complementing this construction are zinc-plated hardware, epoxy paint and stainless-steel nameplates for long life and easy identification in the field. A unique offset rotor bar provides improved efficiency, while larger bars and end rings reduce resistance. Each die-cast aluminum rotor assembly is dynamically balanced for extended bearing life and includes a high-strength C1045 carbon steel shaft for maximum performance. Premium C5-grade steel laminations and copper magnet wire are standard.
For insulation, the Class-H non-hygroscopic system with NEMA Class B temperature rise provides an extra margin of thermal life. The insulation system meets or exceeds NEMA MG1 2014 Part 31, making these motors suitable for variable speed drives in constant torque (4:1) and variable torque (20:1). All windings are tested for Corona Inception Voltage (CIV).
The Siemens Product Manager for Low-Voltage NEMA Motors, Oscar Palafox, explains, “One of the features of the SD200 is its flexibility in the field, as the motor can be switched from F1 to F2 and F3 orientation with ease. Plus, the safety features on this new line are unmatched by competition. Full H-Class conformity provides winding protection, while the swivel hooks are a significant improvement over eyehooks for handling of these heavy units. In addition, the unique Siemens composite insulation on the SD200 is a cost-saver over the ceramic bearing alternative with ten times the resistance of other solutions in the market. Finally, the NEMA Premium® efficiency is a guarantee of long performance life with very tight deviation of losses. Shaft current remains more consistent for better uptime.” Palafox further notes this new line affords users Division II, Class 1 (gas) and Class 2 (dust) protection.
For more information regarding SIMOTICS SD200 motors, please visit: http://usa.siemens.com/simotics-sd200
Siemens Digital Industries (DI) is an innovation leader in automation and digitalization. Closely collaborating with partners and customers, DI drives the digital transformation in the process and discrete industries. With its Digital Enterprise portfolio, DI provides companies of all sizes with an end-to-end set of products, solutions and services to integrate and digitalize the entire value chain. Optimized for the specific needs of each industry, DI’s unique portfolio supports customers to achieve greater productivity and flexibility. DI is constantly adding innovations to its portfolio to integrate cutting-edge future technologies. Siemens Digital Industries has its global headquarters in Nuremberg, Germany, and has around 75,000 employees internationally.
Siemens Corporation is a U.S. subsidiary of Siemens AG, a global powerhouse focusing on the areas of power generation and distribution, intelligent infrastructure for buildings and distributed energy systems, and automation and digitalization in the process and manufacturing industries. Through the separately managed company Siemens Mobility, a leading supplier of smart mobility solutions for rail and road transport, Siemens is shaping the world market for passenger and freight services. Due to its majority stakes in the publicly listed companies Siemens Healthineers AG and Siemens Gamesa Renewable Energy, Siemens is also a world-leading supplier of medical technology and digital healthcare services as well as environmentally friendly solutions for onshore and offshore wind power generation. For more than 160 years, the company has innovated and invented technologies to support American industry spanning manufacturing, energy, healthcare and infrastructure. In fiscal 2018, Siemens USA reported revenue of $23.7 billion, including $5.0 billion in exports, and employs approximately 50,000 people throughout all 50 states and Puerto Rico.
Continue reading
#ANCATooloftheYear2021 offers thousands in prize money and global recognition; celebrating the magic of the cutting tool and the experts who create them
ANCA’s industry-first competition is back with the 2021 winners to be announced live at EMO, Milano; a major global trade fair that recognizes the magic world of metalworking. Last year the industry welcomed the opportunity to show off their skills with almost 30 entries received from across the world being seen by over 80,000 fans generating over 200,000 engagement on social media.
Patrick Boland, Co-Founder at ANCA comments: “Our industry thrives thanks to grinders’ expertise. Much of what people use and enjoy in everyday life is due to the hard work and ever increasing technical acumen of these cutting tool makers and as a result we are seeing the complexity of cutting tools increase, improving productivity, tool life and functionality.”
“Now in its fourth year, ANCA Tool of the Year has gained significant coverage – raising the profile of cutting tools and those companies who make them. I encourage all cutting tool makers to enter our competition and be recognized on a global stage for your craftmanship and contributions to our industry,” he concluded.
Ivan Cuscov, Plant Director at Cerin SpA and first time Judge said: “Continuous developments in tool technology have shown us that standard products have become easier and easier to make and the challenge is to create something new, putting creativity into the grinding process. Grinding technology can still be surprising for expert people who work in the field every day given turning new ideas into reality is enhanced by an open, flexible software such as ANCA’s iGrind.” Cerin SpA began operating in 1971 and is one of the most reputable Italian manufacturers of carbide precision tools.
ANCA will also showcase the much anticipated AutoMarkX for the first time at EMO. AutoMarkX is an automatic stand-alone laser marking station replacing manual and labor-intensive processes. Find out more about what is at ANCA’s stand on our EMO page.
ANCA Tool of the Year 2021 – Complexity through simplicity: ANCA makes it simple to design and grind complex tools
To find the Tool of the Year customers can submit their favorite tool with the winners being judged and announced live at EMO. There will be two competition categories to recognize both the functionality and creativity of cutting tool manufacturers.
The winner of #MadeonANCA receives $10,000 AUD worth of ANCA innovations for parts, accessories or software that fit your grinding needs and the winner of the most innovative virtual tool will receive the full CIM software package.
Submissions open from 15th June – 15th August.
2020’s #MadeonANCA competition winner, ARCH Cutting Tools’ entry demonstrated excellent use of multiple iGrind operations with several complex profiles. Jeff Cederstrom, President of ARCH Cutting Tools said: “It is a humbling experience to be involved in a friendly competition with some of the world’s most innovative and technically advanced cutting tool manufacturers. We will use the recognition to further motivate us to push the limits of cutting tool design to meet our ultimate goal of meeting our customers’ needs and the challenges they have in their applications every day.”
Patrick Boland continued: “For the winners of Virtual Tool Category, JG Group from Poland took a creative approach using an Australian theme of the Sydney Opera House reproduced in a profile tool, looking as impressive as a tool as it does in real life. (Joint virtual winner) Turcar’s tool amazed me in how they achieved their tool design. I had no idea our software could produce something as beautiful and as well executed as their entry.”
The competition will be based on the passion and the craft of tool making and celebrate our highly skilled tool grinding community.
At EMO the top five finalist tools will be judged on the following criteria:
For further information, please contact:
Johanna Boland
Group Strategy and Communications Manager, ANCA
M: +61 407799779
Johanna.Boland@anca.com
ANCA is a market leading manufacturer of CNC grinding machines. It was founded in 1974 in Melbourne, Australia where the company still has its global headquarters. ANCA has offices in the UK, Germany, China, Thailand, India, Japan, Brazil and the USA as well as a comprehensive network of representatives and agents worldwide.
ANCA CNC grinders are used for manufacturing precision cutting tools and components across a diverse range of competitive industries including cutting tool manufacture, automotive, aerospace, electronics and medical.
Continue reading
Strohwig Industries is a large, family-owned tool and die, injection mold and custom machining shop that helps turn the ideas of engineers into reality. The company was founded in 1978 by Mr. Wolfgang Strohwig and his brother-in-law Larry Glass in Polk, Wisconsin. The initial location had only 600 square feet of space and a single Lucas Boring Bar. Located today in Richfield, Wisconsin, Strohwig Industries has 180 employees with a 225,000 square foot facility. With 56 horizontal and vertical CNC machines and the ability to handle over 100 tons, Strohwig is well equipped to handle large machining.
Brad Bucholtz, the company Quality Technician, explained Strohwig’s mission as, “The design, manufacture and repair of medium to large forging dies, plastic injection molds and metal die casts, as well as the manufacture of custom contract parts and/or components.” They machine a variety of steel (H-13, stainless steel, castings, forgings) and aluminum components. The company serves various markets including aerospace, automotive, mining, defense, building assembly, oil and gas, energy, marine, etc. This is why they decided to use Exact Metrology equipment for their inspection needs.
Brad said they’ve worked with Exact Metrology for over ten years. Initially, the company provided metrology services. He added that before 2010, there was no need for metrology as company employees manually inspected jobs that needed it. Working with Exact Metrology, Strohwig bought a Hexagon Romer Arm in 2016 and Leica Tracker in 2019. When the Romer RS6 scanner was released Exact Metrology offered a trade in on the older Romer arm. The productivity increase was so great it was easy to justify the investment of the new arm/scanner. This equipment came in handy when Strohwig received a request from a major Midwestern forge that has a long-standing relationship with them.
This metal forging company in Illinois has a 126-year history and specializes in open die forging and rolled ring forging. The company was using Coordinate Measuring Machines (CMM) but needed to upgrade their equipment. A new job required precise measurability of a large forged part with complex geometry. Dean Solberg, Exact Metrology co-president suggested that they invest in scanning technology. Thus, the company purchased a Leica tracker, as well as PolyWorks software. Leica Absolute Tracker AT960 features an all-in-one integrated design, single-box probing system and smart connectivity. Additional features include continuous measurement, entry-level probing with T-probe and 2 Handheld laser scanners. One is an 8” line scan and another is a 24” line scan to capture huge amounts of data quickly. The System is IP54 Certified for protection against dust and other contaminants. PolyWorks|Inspector™ was used to verify the quality of the part through the use of high-density point clouds and contact-probe datasets. The scan was performed in a working environment, not a traditional lab, which meant that personnel were doing this while forging occurred. In the past, Strohwig machined various parts for them. Now, this forge had Strohwig test for compliance vs. non-compliance in one of their forged parts.
To do this, Strohwig used the Hexagon Romer Arm and the Leica Absolute Tracker. The portable measuring arms allowed company personnel the flexibility to measure on the machine shop or the floor. It featured no honing procedures, simplicity of operation and reliable 3D measurements. The Absolute Arm 7-axis delivers tactile probing and laser scanning in a uniquely ergonomic package. Once this was completed, they used PolyWorks|Inspector™ to verify the quality of the part by using a color map. In the future, the company is looking to purchase additional Exact Metrology products.
Strohwig was able to coordinate with the company as they use common platforms to communicate and shared daily emails and PowerPoint presentations with their results. Brad Bucholtz used data mergers to combine the Romer and Leica data sets into one report.
Since using Exact Metrology, Brad said, “We are able to provide detailed reports to our customers. Also, we’re able to perform in-process inspections to validate specific processes.” He further commented that Exact Metrology allowed them to supply a superior product and their deliverable to the customer has greatly improved.
When referring to the benefits of working with Exact Metrology, Brad noted, “Training only goes so far. After initial training, there are many stumbles and Exact is always there to make sure we get the knowledge we need. Onsite or offsite, they go above and beyond the call to make sure we can provide our customers with the data they need.”
Exact Metrology is ISO, AS9100 Certified as well as FFL and ITAR Registered.
Exact Metrology, with facilities in Cincinnati, Ohio, Moline, Illinois and Milwaukee, Wisconsin, plus affiliated offices throughout the country, is a comprehensive metrology services provider, offering customers 3D and CT scanning, reverse engineering, quality inspection, product development and 2D drawings. The company also provides turnkey metrology solutions, including equipment sales and lease/rental arrangements.
For technical information regarding these companies, please contact:
Strohwig Industries
Brad Bucholoz
Quality Technician
3285 Industrial Rd.
Richfield, WI 53076
Phone: 262-628-4477
www.strohwig.com
bbucholz@strohwig.com
EXACT METROLOGY, INC.
Dean Solberg
20515 Industry Avenue
Brookfield, WI 53045
Local: 262-533-0800
www.exactmetrology.com
deans@exactmetrology.com
SIDEBAR: In a short video, Brad Bucholoz, Strohwig Quality Technician, describes Strohwig as company in business for 43 years that specializes in plastics and die cast molds and large contract machining parts. Tasked to test for compliance vs. non-compliance of a forged part by a Midwestern metal forging customer, Bucholoz highlighted that Strohwig uses the same hardware and software as their customer to communicate more accurately with them. This included the use of PolyWorks|Inspector™ Leica Absolute Tracker AT960MR and the Hexagon Romer Arm. The Absolute Tracker was used in conjunction with the Leica Absolute Scanner LAS-XL and T-probe. Bucholoz mentioned that Exact President, Dean Solberg and the Exact team have always been to help and that he sees this relationship continuing into the foreseeable future.
Continue reading
Established in 1986 Mictu’s core business is the eyewear industry. As the company has grown they expanded into aerospace, automotive, dental, and mechanical. Boasting a team of 15 people and producing more than 200,000 tools per year, Mictu exports tools to China, Hong Kong, North and South America, Switzerland and Germany, as well as servicing their local Italian market.
Andrea Colavo, the son of the founder of Mictu said, “There has been significant growth in our company since its beginning. We have a big body of knowledge as the eyewear industry gave us the opportunity to test our tools in many different materials giving experience in working with many kinds of plastics and metals.”
Servicing the changeable eyewear industry
The eyewear industry is different from other kinds of industries, mostly because it’s fashion. Eyewear trends are constantly changing and customers require different tools to machine different shapes.
The industry also uses very small tools and Mictu have produced tools with a 0.2 millimeter diameter mill. For example, a hinge requires very tight tolerance — in fact drawings often specify plus or minus one hundredth of a millimeter.
Understanding different materials is fundamental
Andrea continues, “We are a curious team who understand the value of trying new approaches and materials. If a customer is asking to use a material we have no experience in, we ask them how this material reacts to machining and describe the chips of this material. This helps us build a picture of how the material reacts to cutting. We make a sample tool and analyze its performance — is the tool working correctly or does it require adjustments? In the ANCA 3D simulator we can make these adjustments to produce a second batch and try again at the customers.”
Mictu has developed many different tools for many different materials. The most common plastics are nylon or polycarbonate and metals are titanium, stainless steel or cast iron.
Designing the best tool takes trial and error
“I think that anyone can make a tool, especially now that we have more intuitive software. However experience is still key. Cutting tool makers should consider the dynamics of the grinding wheels and need to know the right speed that will not cook your material as otherwise it will break like glass.”
“Generally we start from a drawing of the finished part and ask our customer how he wants to machine their component. Next we use our ANCA 3D simulator software program to simulate the tool to evaluate the best performing shape for that tool.”
“We start using 3D simulation with an ANCA MGX that we bought in 2002. The 3D simulator has changed the way we make tools, mostly because using this software means we are making less errors.”
“The characteristics that make a tool perform best is choosing the right material.
“A cutting edge must be appropriate for the material you have to machine for example, sometimes a very sharp cutting edge is not the best choice. Very sharp edges are weaker than a rounded edge and can vibrate more. So for soft materials you need a very sharp edge, but for hard to cut materials, you need a stronger cutting edge. “
“I have found it is important to make mistakes. This means you can learn what is not working and that helps you next time you are designing a tool.”
Technology matters – ANCA’s MGX has produced more than 350,000 pieces and is still running
Mictu invested in an MGX in 2002. Andrea recalls, “It’s our first ANCA and is still performing with more than 350,000 pieces manufactured over the years. We found the MGX is a very good machine for producing small to medium batches of very small tools.”
“More recently we purchased two new FX7 Linears because of their flexibility. They are excellent machines for producing tool batches of varied sizes. So far, we have been running them all week, overnight and on the weekend with big batches. During the day we use them to produce smaller batches. On the FX7 we mainly produce drills, step drills and mills and sometimes even end mills with a profile.”
“The FX7 can produce very different tools in the same batch making the machines extremely efficient. Another big advantage of these machines is that we can measure the tool without looking at it. The machine has a laser that measures, and if necessary, corrects during the grinding process. Even if no one is looking at the machine, we know the machine is automatically taking care of the tolerance of our tools and that the end quality will be high. I sleep much better because I know the laser is doing its job checking the diameter of every mill you are producing.”
“We use the iBalance to ensure our wheel packs are balanced, reducing the vibration on our tools. This is fundamental when you’re making very small tools. If you have even a very small vibration, your cutting edge will be hammered and cheap. If you have it balanced well, it will work much more smoothly and have a nicer cutting edge.”
“Personally I also liked the appearance of the machine, I would even say it is good looking! With the new Linear models, we expect a longer machine lifespan and improved surface finish. The small footprint is welcome and its many features help with the repeatability of our tools. In summary, we choose the ANCA FX7 Linear because it is a complete package with a wheel changer, large loader, laser measurement technology and has 3D Simulator software.”
Professional facilities build trust with customers
Mictu recently moved to a new facility and are reaping the benefits of investing in custom design. Andrea continues “The biggest benefits we’ve seen moving to a new facility was starting from a blank sheet. We decided to put all the pipes needed for the oil for the grinders underground to make a clear surface with less stuff that can leak on the floor. The measuring machines have been installed in a separate environment to keep them on a steady temperature. Since moving we have seen improved production, better quality control and overall we are more efficient and have a better environment for our people because it’s clean and fresh.”
“I think it’s really important for a customer to visit your facility so they can assess the working environment. Fortunately, customers are very impressed which helps us build trust in our products and services. Customers choose to work with us because we are very lean and listen to their needs. We have a skilled and experienced team who are able to solve problems.”
For further information, please contact:
Johanna Boland
Group PR and Communications Manager, ANCA
M: +61 407799779
Johanna.Boland@anca.com
ANCA is a market leading manufacturer of CNC grinding machines. It was founded in 1974 in Melbourne, Australia where the company still has its global headquarters. ANCA has offices in the UK, Germany, China, Thailand, India, Japan, Brazil and the USA as well as a comprehensive network of representatives and agents worldwide.
ANCA CNC grinders are used for manufacturing precision cutting tools and components across a diverse range of competitive industries including cutting tool manufacture, automotive, aerospace, electronics and medical.
Continue reading
Exact Metrology, a comprehensive 3D metrology service provider and hardware sales company, has recently installed a ZEISS METROTOM 6 scout, formally known as a GOM CT, scanner at their facility in Brookfield, Wisconsin.
Considered the powerhouse of resolution for CT inspection and metrology, the METROTOM 6 scout digitizes complex parts including the internal geometries at the finest level of detail. Users obtain a complete 3D image for GD&T analysis or nominal-actual comparisons. The metrology CT excels in digitizing small plastic parts.
The combination of a 3k detector and 225 kV X-ray enables ZEISS METROTOM 6 scout to provide high contrast, high-resolution measurement results and exceptional sharpness of detail. As a result, even the smallest defects in the part become visible and can be analyzed to the last detail.
To showcase the ability of Exact Metrology’s CT scanning services, powered by the METROTOM 6 scout, a scan was done on a medical stent. This medical stent, with a diameter of only 1 millimeter, was measured within a 5 Micron resolution. Thus, Exact Metrology inspectors were able to evaluate critical features with amazing precision.
CT scanning provides several benefits including being the only way to get 3D views inside a part and the only way to obtain accurate dimensional data without cutting up and destroying an object. In addition, CT scanning requires very little time to capture data and troubleshoot parts and also offers multiple uses with one scan (void analysis, inspection, volume, porosity, reverse engineering, etc.). In contrast to conventional tactile coordinate measurement techniques, a CT acquires all surface points simultaneously —on even the most complex objects. This includes all hidden features like undercuts which are not accessible using other non-destructive measurement methods.
Due to its ability to see data layer by layer, CT scanning permitted Exact Metrology inspectors the ability to see any possible defects/details on the stent. This is crucial for any medical device, especially something as small and essential as a stent that goes into the human body.
Exact Metrology is ISO, AS9100 Certified as well as FFL and ITAR Registered.
Exact Metrology, with facilities in Cincinnati, Ohio, Moline, Illinois and Milwaukee, Wisconsin, plus affiliated offices throughout the country, is a comprehensive metrology services provider, offering customers 3D and CT scanning, reverse engineering, quality inspection, product development and 2D drawings. The company also provides turnkey metrology solutions, including equipment sales and lease/rental arrangements.
For more information, please contact:
EXACT METROLOGY, INC.
Dean Solberg
20515 Industry Avenue
Brookfield, WI 53045
Local: 262-533-0800
www.exactmetrology.com
deans@exactmetrology.com
To see optimized part positioning with ZEISS Metrology, please visit https://www.youtube.com/watch?v=Ch3JuozfqYU&list=PLvaO705pqbydFVDs_K_f0qrZgm1tQ8F9b
Continue reading
Maintenance tips and assembly procedures on automated tools explained by Division Manager Lee Coleman
Suhner Machining recently filmed a series of maintenance tip and unit assembly videos at the company’s North American Service Center, housed on the campus of corporate headquarters in Rome, Georgia. The presentation of the procedures was done by Division Manager and longtime Suhner team leader, Lee Coleman. These “hands on” demonstrations would interest any customer or maintenance personnel currently using or planning to employ Suhner automated tools in their shop or production facility. According to Coleman, “We made these videos as the first in a series. Our goal is to help customers and trainers impart the proper procedures for maintenance and assembly of our automated drills, taps and other tools, which are used extensively in automotive and other high-volume production facilities, contract job shops and elsewhere.”
The company is planning a number of videos to assist operators and especially maintenance personnel in the proper care and handling of these high-precision automated tools, many of which typically perform thousands of operations in a single shift on the production line.
These first four new videos cover the following topics on the SPINDLEmaster Max 100:
Proximity Switch Adjustment
Spring Adjustment
General Maintenance
Flag Nut Adjustment
For more information, please contact:
Lee Coleman, Division Manager-Machining
Suhner Industrial Products Corp.
25 Anderson Road SW
Rome, GA 30161 USA
Phone: 706-235-8046
Fax: 706-235-8045
machining.us@suhner.com
All the features and reliability of Suhner technology at an affordable price,
For the OEM or end user…MADE IN AMERICA
Suhner introduces the ECONOmaster® line of drilling units, affordably priced at under $3000 for the basic unit, in stock for immediate delivery or customizable to suit the particular operation. This economical solution is ideal for multiple materials such as light metal, wood, composite, plastic and foam. Because these units are entirely produced at the Suhner factory in Rome, Georgia, response times for delivery and customized construction are minimal, according to Division Manager Lee Coleman. “We recognized the need to bring our global technology to a local level, here in America, and the ECONOmaster® is a key step in that process.” Suhner is based in Brugg, Switzerland, with plants and distribution centers worldwide.
The ECONOmaster® drilling unit features low power and air consumption, adjustable motor housing, adjustable total stroke up to 4”, hydraulic feed control cylinder, J33 taper spindle end, 0-1/2” drill chuck, electric front & rear position limit switches, belt tensioner and chrome-plated quill. Basic unit weight is 45 lbs.
Other key features include adjustable feed stroke of ½-3”, 400 lb. thrust at 85 psi, operating pressures to 110 psi, TEFC/IP56 protection, standard 230V/460V, concentricity of .002” TIR, speed ranges to 9600 RPM and an air connection retract/advance of ¼” to 27 NPT.
ECONOmaster® drilling units can be supplied with an adjustable stand, inline vertical configuration and multiple spindle heads for medium-duty production drilling, with many other spindle options and toolholders available. Please consult the factory in Rome, Georgia.
For more information, please contact:
Lee Coleman, Division Manager-Machining
Suhner Industrial Products Corp.
25 Anderson Road SW
Rome, GA 30161 USA
Direct: 706-314-2927
Mobile: 706-409-1876
Fax: 706-235-8045
lee.coleman@suhner.com
Fast flexibility for custom tooling, easy access through cloud technology and automation are driving tool production processes
ANCA North American President Russell Riddiford recently participated in an award ceremony at ARCH Cutting Tools in Latrobe, Pennsylvania to celebrate the company’s win in the 2020 ANCA Tool of the Year competition. During this time, Russell sat down with ARCH Cutting Tools President Jeff Cederstrom to discuss the successful collaboration between both companies, as well as future trends that they see on the horizon; and how best to maximize the opportunities of these trends.
Offline and in-process solutions help to deliver speedy custom profiles and get the “first tool right”
Jeff identified the growing trend towards custom tooling. While he described ARCH as a “full-service, one-stop shop with a broad portfolio of standard tools,” he acknowledged that the company sets itself apart in the market, thanks to the breadth of their custom tooling capabilities. Many customers work with ARCH Cutting Tools, looking for custom solutions to reduce their manufacturing costs. This leads to combination tools with complex geometries. Jeff said the combination of skilled machinists, designers and technology that ANCA provides enables the process to flourish.
Recognizing the market need for adaptability to produce custom tools Russell highlighted the range of processes offered by ANCA that are targeted to increasing the “speed to get to the grinding point.” ANCA’s 3D simulation software generates a special profile offline, while the machine is still running and completing the previous jobs. The program is then downloaded to the machine, allowing ARCH to obtain better production of the first tool. ANCA offers ARCH the option to inspect their tool on the machine, using the LaserPlus System. The system measures the profile tool, automatically compensating the machine to correct any errors in geometry. Another option is to take the tool to a ZOLLER presetter, as ZOLLER is integrated with the ANCA machines on the floor. A full contour scan is performed using the ZOLLER »genius3« to identify any imperfections in the tool.
Russell sees the importance of having the “first tool right” as a critical point for production. After the pre-grind process through simulation to perfect the tool before it even gets to the machine, ANCA as the only company with a full linear motor product line, offers customers maximum accuracy, surface finish and stability throughout the grinding process. Another new technology is spindle temperature control, a software function that maintains consistent spindle temperature. Providing this stability again allows the first tool in production to be right.
ARCH Cutting Tool’s winning tool offers five separate functions demonstrating the kind of complexity that is in demand. Jeff commented that custom tooling is becoming more challenging and ANCA’s solutions offer significant benefits. Jeff noted: “Having the software so that it is user-friendly, and we can adapt to a request quickly and having not only the software but the machining technology to support it … is critical to us.”
Jeff’s company recently launched a program called “Hot Shop” to showcase their speed from production to delivery. If a customer needs a custom tool quickly, ARCH can produce any geometry of a solid carbide round tool and have it delivered within one week. Jeff explained: “Having equipment that is nimble and fast on the floor enables (this speed)”.
Connected machines and integrated automation
ARCH has developed a web portal called “ARCH Specials.” Customers can download drawings, a DFX file or use pulldown menus on the company website, or talk to engineers to generate a fast RFQ for application specific custom tools.
Online capabilities and cloud technology are a growing trend. ANCA can network all machines through their Management Suite software, allowing users to replicate and download files from anywhere in the country, such as across ARCH’s multiple facilities. Additionally, users can monitor real-time performance of their machines to schedule and maintain the machines, as well as predict maintenance requirements to minimize downtime.
Both Cederstrom and Riddiford identified automation as another rising trend. From customers looking for more output, better quality and more productivity, to the social distancing requirements of COVID, to the gap in skilled labor; increased automation provides a solution to these challenges. To this end ANCA has developed AIMS (ANCA Integrated Manufacturing System). Russell explains: “This is the ability to bring a stock piece of carbide at the front end and at the back end have a finished tool…without manual or operator input throughout the process. This allows end-to-end grinding.” Adding to ANCA’s product range is automated laser etching with the AutoMarkX, which fits with AIMS to complete the process. Russell added: “Some people might think of it as the future, but AIMS is here today.”
To see the discussion between Russell and Jeff, please see the video below:
For further information, please contact:
Johanna Boland
Group PR and Communications Manager, ANCA
M: +61 407799779
Johanna.Boland@anca.com
ANCA is a market leading manufacturer of CNC grinding machines. It was founded in 1974 in Melbourne, Australia where the company still has its global headquarters. ANCA has offices in the UK, Germany, China, Thailand, India, Japan, Brazil and the USA as well as a comprehensive network of representatives and agents worldwide.
ANCA CNC grinders are used for manufacturing precision cutting tools and components across a diverse range of competitive industries including cutting tool manufacture, automotive, aerospace, electronics and medical.
Continue reading
Comprised of the drive, motor and gear box, this new distributed drive system is available as a complete solution for motor-mounted and wall-mounted horizontal motion control conveyor applications.
With its new Sinamics G115D, Siemens is introducing a new, compact and powerful drive system specifically designed for horizontal conveyor applications. The drive system comprises the motor, drive and gearbox in one unit and is offered in two versions — wall-mounted and motor-mounted.
The Sinamics G115D drive system is characterized by a robust design with a high IP protection class (up to IP66 / UL Type 4X) and is suitable for use in harsh environments. Thanks to its compact dimensions, the Sinamics G115D can be easily installed in confined areas. The drive system can also be operated reliably over a wide temperature range of -30 to 55 degrees Celsius (-22 to 131 degrees Fahrenheit), enabling operation in deep freezing applications.
Sinamics G115D is suitable for applications in intra-logistics and airports, as well as in the automotive and food and beverage industries. Its power ranges from 0.37 to 7.5 kilowatts
(1/2 to 10 hp) for wall-mount applications and 0.37 to 4 kilowatts (1/2 to 5 hp) for motor-mounted applications. The drive system can be put into operation quickly and easily with comprehensive integration into the Totally Integrated Automation (TIA) portal including Startdrive commissioning software or the Sinamics Smart Access Module (SAM) web-server for Wi-Fi setup and diagnostics.
To be prepared for digital transformation and to enable cloud-based analysis, Sinamics G115D is integrated into the entire MindConnect portfolio and is compatible with MindSphere applications such as Analyze MyDrives.
Thanks to Profisafe, the Sinamics G115D has Safety Integrated in the form of STO (Safe Torque Off) SIL2, which standardizes and facilitates the certification process. For flexibility in terms of installation, service and maintenance, the solution is equipped with a plug-in connector and flexible connection possibilities. The device is particularly suitable for interaction with Simatic controllers such as the Simatic S7-1200 or Simatic ET200 for motion control.
Siemens offers warranty extensions for Sinamics G115D through its Service Protect package. As part of this service package, an additional one or two-year warranty extension may be purchased for failure coverage. The package offers simplified processing under normal warranty conditions for the extended period.
For more information regarding Sinamics G115D, please visit:
usa.siemens.com/sinamics-g115d
For specific product information and inquiries, send an e-mail to: mc.us@siemens.com
Siemens Digital Industries (DI) is an innovation leader in automation and digitalization. Closely collaborating with partners and customers, DI drives the digital transformation in the process and discrete industries. With its Digital Enterprise portfolio, DI provides companies of all sizes with an end-to-end set of products, solutions and services to integrate and digitalize the entire value chain. Optimized for the specific needs of each industry, DI’s unique portfolio supports customers to achieve greater productivity and flexibility. DI is constantly adding innovations to its portfolio to integrate cutting-edge future technologies. Siemens Digital Industries has its global headquarters in Nuremberg, Germany, and has around 75,000 employees internationally.
Siemens Corporation is a U.S. subsidiary of Siemens AG, a global powerhouse focusing on the areas of power generation and distribution, intelligent infrastructure for buildings and distributed energy systems, and automation and digitalization in the process and manufacturing industries. Through the separately managed company Siemens Mobility, a leading supplier of smart mobility solutions for rail and road transport, Siemens is shaping the world market for passenger and freight services. Due to its majority stakes in the publicly listed companies Siemens Healthineers AG and Siemens Gamesa Renewable Energy, Siemens is also a world-leading supplier of medical technology and digital healthcare services as well as environmentally friendly solutions for onshore and offshore wind power generation. For more than 160 years, the company has innovated and invented technologies to support American industry spanning manufacturing, energy, healthcare and infrastructure. In fiscal 2018, Siemens USA reported revenue of $23.7 billion, including $5.0 billion in exports, and employs approximately 50,000 people throughout all 50 states and Puerto Rico.
