ANCA machine innovation and software combine for a complete package for producing woodworking tools, reducing set-up times
By Simon Richardson, Product Manager, ANCA
ANCA is well known for offering standard and special custom solutions for their customers. When ANCA designs a custom solution, we give our customers tailored and diverse options with shorter set-up times. In an increasingly challenging market, companies grinding tools are always looking at innovative products and diversifying into different sectors using existing or new machinery.
On the affordable FX grinding machines, ANCA has developed a new product which provides more flexibility and capability for unattended production of wood tools. Special tooling systems for FX5 and FX7 machines offer the ability to easily change automated production between woodworking profile blades, used to form skirting boards and architraves, and solid round shank tools such as routers and drills used in production of furniture and cabinetry. In addition, companies focusing predominantly on engineering tools can consider adding woodworking blade profiles to their product portfolio.
Versatility to cover very different tool types starts with the work holding, where two options are offered: a blade chuck to hold flat profile blades, or a PremierPlus collet chuck for holding round shank tools.
Both systems are actuated with the same pull stud mechanism, so switching between the two systems is done in minutes.
Robot automation, too, has been configured to allow easy change between profile blades and round shank solid carbide tools including spirals, compression routers and drills. All without having to change grippers or re-teach robot positions. Simply change over the pallets to suit the tool type and size, and you are ready to start unattended production! Automated loading of blades up to 80mm wide x 40mm high is possible, while with hand loading, blades up to 120mm x 40mm high can be accommodated.
FX is offered with grinding spindle power options from 12kW up to 19kW, giving the ability to grind solid routers or drills comfortably up to 12mm, and perform heavy stock roughing on thicker profile blades. Flexibility is enhanced with 2 wheel packs as standard, but options for up to 6 are available. This ensures the right wheel pack configuration is ready to use, with zero downtime when changing between tool types. Additionally, separate touch probe solutions are offered to allow fast and accurate measurement of your profile blade datums and round shank tools.
LaserPlus is a recommended option for those making solid routers and compression routers where diameter control is a critical element of your tool quality. Mounted inside the machine, LaserPlus is a non-contact system for automatic measurement and compensation of tool diameter. For compression routers, it will even measure both up and down cut sections to ensure they are consistent.
ANCA completes the package with a suite of flexible and user-friendly software options to cover diverse tool production needs.
ANCA’s wood tool production package for the FX5 and FX7 offers outstanding flexibility for unattended production on ANCA’s most affordable tool grinding machine.
For further information, please contact:
Johanna Boland
Group PR and Communications Manager, ANCA
M: +61 407799779
Johanna.Boland@anca.com
ANCA is a market leading manufacturer of CNC grinding machines. It was founded in 1974 in Melbourne, Australia where the company still has its global headquarters. ANCA has offices in the UK, Germany, China, Thailand, India, Japan, Brazil and the USA as well as a comprehensive network of representatives and agents worldwide.
ANCA CNC grinders are used for manufacturing precision cutting tools and components across a diverse range of competitive industries including cutting tool manufacture, automotive, aerospace, electronics and medical.
Continue reading
Under the theme “Digitalization in Machine Tool Manufacturing — Infinite opportunities from infinite data”, Siemens will demonstrate how the full potential of data can be used for increased productivity during this year’s EMO Milano tradeshow, October 4-9, and during the virtual Siemens Machine Tool Days 2021 event.
The challenges are quite large: the Covid-19 pandemic has significantly accelerated the pace of change in manufacturing markets. Added to this are growing demands of individualization and the urgent need for more sustainability — and these can be achieved with the help of digitalization and automation. Siemens brings together the extremely large volumes of data generated in this process during a continuous cycle between the real and digital worlds. This enables the employees of industrial manufacturers to make the appropriate decisions based upon data and respond more quickly to trends and changes.
SINUMERIK ONE is core element of highlight case with two technologies
During EMO in Milan and the Siemens Machine Tool Days virtual event, Siemens will demonstrate how to react quickly to trends with the new SINUMERIK ONE CNC, which was introduced in the North American market as a digital-native control. To demonstrate this, the focus of the real and virtual Siemens booth is a production line that shows two machines controlled with SINUMERIK ONE — a 5-axis milling center and a robotic-based additive manufacturing machine.
With these two machines, for example, the gears of large gearboxes can be repaired instead of replacing them. Such large gearboxes are used in industries such as wind energy, where they are subject to natural wear-and-tear due to the enormous frictional forces and must be replaced at certain time intervals. Siemens will demonstrate how the gears are initially milled flat in the milling center. Next, a robot is used to rebuild the teeth in an additive manufacturing process. And the final precision grinding takes place at the end again on the 5-axis milling center.
Instead of new production, the repair not only saves material resources, but also approximately 60 percent of energy. SINUMERIK ONE, the first digital-native CNC, represents the core element for the digital transformation of the machine tool industry. Thanks to the Digital Twin known as Create MyVirtual Machine, both machines could be developed, tested and functionally approved simultaneously, long before the real machine was put into operation. This gives machine tool builders the advantage by getting to a better machine faster, while machine tool users can get to the right workpiece even faster.
With the Digital Enterprise portfolio, Siemens supports manufacturers exactly where the current challenges lie. With the help of Digital Twins, such as SINUMERIK ONE, the use of future technologies such as artificial intelligence or industrial edge computing, and the Siemens digitalization portfolio, machine builders and machine users can collect, analyze and understand the data generated and use it in a productive way. This allows them to react quickly and flexibly to challenges, adapt their products and manufacturing processes to new requirements and save resources.
Greater flexibility and innovative technology for machine operation
SINUMERIK ONE offers new functions and technology updates that further increase manufacturing performance, flexibility and modularity. Visitors to the Siemens booth during EMO in Milan, as well as the visitors attending the virtual Siemens Machine Tool Days event, will have the opportunity to see new SINUMERIK ONE Machine Control Panels (MCP) in action.
With the new SINUMERIK ONE MCPs, Siemens brings intuitive machine tool operation to CNC users including more comfort, increased efficiency and greater flexibility. The new ergonomic metal design can be integrated into existing operating concepts and fits 19-inch to 24-inch panels. The new MCPs can even be configured individually for customer-specific requirements.
New functionalities make machine operation even easier. Powerride combines the override switch with the NC start button for easy and efficient machine setup. With the integrated LED scale in Powerride, ACTUAL values can now be visualized. With Powerride, the feed is automatically reset after the end of the set, which makes operation effective and easy. In addition, Powerride provides haptic feedback through short vibration as soon as a defined limit value is exceeded. This increases the perception of these values and supports the blind operation of the panel.
The QWERTY keyboard is provided as standard for the MCPs for the 22-inch and 24-inch variants, so users no longer need an additional keyboard. An integrated RGB LED in the QWERTY keyboard enables customizable color concepts for simplified work. The SINUMERIK ONE MCP can be used in harsh industrial environments thanks to its IP65 protection class rating.
Siemens Industrial Edge — extensions for machine tools
With Industrial Edge, Siemens offers a concept in which both machine tool builders and machine users can flexibly use the advantages of data processing using Edge or Cloud computing as required. Siemens is also expanding its Edge computing portfolio for machine tools that will enable real-time analysis of data on-site during production. During EMO and Siemens Machine Tool Days, the scalability of Edge hardware will be presented with new Industrial PCs IPC 127E and IPC 427E hardware variants.
For specific product information and inquiries, send an e-mail to: cnc.marketing.us@siemens.com
Contact for journalists:
Siemens
John Meyer
(847) 952-4158
john.meyer@siemens.com
Siemens Digital Industries (DI) is an innovation leader in automation and digitalization. Closely collaborating with partners and customers, DI drives the digital transformation in the process and discrete industries. With its Digital Enterprise portfolio, DI provides companies of all sizes with an end-to-end set of products, solutions and services to integrate and digitalize the entire value chain. Optimized for the specific needs of each industry, DI’s unique portfolio supports customers to achieve greater productivity and flexibility. DI is constantly adding innovations to its portfolio to integrate cutting-edge future technologies. Siemens Digital Industries has its global headquarters in Nuremberg, Germany, and has around 75,000 employees internationally.
Siemens Corporation is a U.S. subsidiary of Siemens AG, a global powerhouse focusing on the areas of power generation and distribution, intelligent infrastructure for buildings and distributed energy systems, and automation and digitalization in the process and manufacturing industries. Through the separately managed company Siemens Mobility, a leading supplier of smart mobility solutions for rail and road transport, Siemens is shaping the world market for passenger and freight services. Due to its majority stakes in the publicly listed companies Siemens Healthineers AG and Siemens Gamesa Renewable Energy, Siemens is also a world-leading supplier of medical technology and digital healthcare services as well as environmentally friendly solutions for onshore and offshore wind power generation. For more than 160 years, the company has innovated and invented technologies to support American industry spanning manufacturing, energy, healthcare and infrastructure. In fiscal 2018, Siemens USA reported revenue of $23.7 billion, including $5.0 billion in exports, and employs approximately 50,000 people throughout all 50 states and Puerto Rico.
Continue readingThe company offers an expanded line of live and static tools for Swiss-Type CNC Automatic Lathes
Visit Us at EASTEC at Booth 5146
Platinum Tooling Technologies, Inc., the exclusive importer of Heimatec live tools, angle heads, and multi-spindle heads, is excited to announce their extended product offering to the current Citizen tool program. In addition to the standard live and static tools, they will offer 1:4 speed increasers for the most current Citizen machine models. Designed to optimize the machine’s parameters, these precision tools are efficient and cost effective.
Originally developed for the manufacture of precision parts in the watch industry, Swiss-type CNC Automatic Lathes are now widely used throughout the industry to produce automotive components, screws and pins for the medical industry, and precision parts for electrical engineering.
Platinum Tooling and Heimatec’s goal during the development of this line was to construct a series of tools that would offer the greatest possible processing quality and longest service life, while additionally enhancing the machine’s capabilities with the use of speed increasers. To achieve this, Heimatec incorporates the highest quality bearings, ground gear components, spindles, and housings to produce superior tools with maximum rigidity.
In addition to Citizen, Platinum Tooling is constantly striving to expand their tooling programs to include superior quality products to enhance machining operations, increase productivity, and create cost savings opportunities.
For more information and literature, please contact:
Preben Hansen, President
PLATINUM TOOLING TECHNOLOGIES, INC.
16 E. Piper Lane
Suite 128
Prospect Heights, IL 60070
Phone: 847-749-0633
Platinum Tooling Technologies, Inc. in Prospect Heights, IL, near Chicago, serves its growing North American customer base with an extensive inventory of machine tool accessories. Its experienced staff is dedicated to providing the most innovative tooling and technology. Platinum Tooling Technologies, Inc. serves the auto, aero, medical, woodworking, composites and other industries, as well as an ever-increasing number of machine tool OEMs worldwide, through its network of manufacturers’ representatives. Platinum Tooling is the importer of Heimatec, Henninger, Tecnicrafts, and AMF Tooling for North America.
Continue reading
Göppingen/Halle, 07/27/2021 – At the beginning of June, Porsche and Schuler began the operation of a fully-connected press shop in East German Halle (Saale). In addition to a servo press line with an output of up to 20 strokes per minute, the Smart Press Shop also features a state-of-the-art blanking line; a Laser Blanking Line 2.18 equipped with two cutting heads for processing strip material with a width of up to 1,880 mm.
Blanking lines with lasers do not require expensive and heavy blanking dies, which is why they are particularly suitable for the production of new parts or small batch sizes with frequent product changes. The continuously moving coil material is processed into blanks at high cutting speeds. Thanks to tooling-free scrap separation, a high output is also achieved. A gentle transport of sensitive materials, such as aluminum, is ensured, too.
The Laser Blanking Line is the ideal solution for the “Smart Press Shop” in Halle, which focuses on the production of aluminum outer skin parts in small batch sizes. By recording various measured values of the system as well as the coil material and by smart marking of the blank, the line which supplies the blanks for the servo press line forms the point of departure for a “Track and Trace” system.
For further information on Schuler Inc., North America, please contact:
Kevin McAllister, President, North America
Schuler Incorporated
7145 Commerce Blvd.
Canton, MI 48187 USA
734-207-7200
Kevin.McAllister@schulergroup.com
About the Schuler Group – www.schulergroup.com
Schuler offers customized first-rate technology in all areas of forming – from the networked press to press shop planning. In addition to press, our product includes automation and software solutions, dies, process know-how and service for the entire metalworking industry. Our customers include automotive manufacturers and suppliers, as well as companies in the forging, household appliance and electronics industries. Press from the Schuler Group mint coins for more than 180 countries. When it comes to the digital transformation of the forming technology, we support our customers worldwide as a supplier of innovative system solutions. Founded in 1839 with headquarters in Göppingen, Germany, Schuler AG has about 5,000 employees at production sites in Europe, China and America, as well as service companies in more than 40 countries. The company is part of the international technology group ANDRITZ.
Continue reading
Siemens to present and demonstrate its SINUMERIK CNC family of CNCs and machine tool digitalization solutions at EASTEC 2021
By combining the real world with the digital world, Siemens will demonstrate how the full potential of data enables machine builders and end-users to be flexible and sustainable in their manufacturing.
On display in the Siemens booth will be the SINUMERIK family of controls that includes SINUMERIK 828D, SINUMERIK 840D and the new SINUMERIK ONE, the first-ever digital-native CNC.
SINUMERIK 828D is a compact and advanced CNC designed to enable machine tool manufacturers to leverage the full productivity potential of the digital factory in a mid-range control. With its panel-based design, the 828D can control up to 10 axes and spindles plus two auxiliary axes making it the perfect CNC system for job shop production.
SINUMERIK 840D sl is the control of choice for modular machine tools used in serial production, 5-axis and multi-tasking machines. The drive-based 840D can control up to 31 axes and spindles, any number of PLC axes and up to 10 machining channels. It works equally well in a job shop, mid-sized or large production facility.
Developed from the ground up, the NEW SINUMERIK ONE is the first CNC system to master the challenges of digital transformation in the machine tool industry. Real-world machining processes and machine tool behavior can now be simulated in the digital world thanks to the Digital Twin.
Using Create MyVirtual Machine, machine tool builders can speed up their development and commissioning times to new levels of quality and efficiency. Machine users can also benefit from a “digital first” strategy for their central processes during production when they use Run MyVirtual Machine. Programming, production planning and process optimization can be simulated instead of performing them directly at the machine and non-productive times are eliminated.
In addition to the SINUMERIK family of controls, we will present our machine tool digitalization portfolio of software apps that increase the manufacturing productivity and accelerate the business of both machine tool builders and machine users. These include Manage MyMachines, Analyze MyMachine, Analyze MyPerformance, Analyze MyWorkpiece, Adaptive Control and Monitoring, and more.
Siemens technical experts will be in the booth for demonstrations and to answer all questions. Editors are welcome to stop by.
For specific product information and inquiries, send an e-mail to: cnc.marketing.us@siemens.com
Siemens Digital Industries (DI) is an innovation leader in automation and digitalization. Closely collaborating with partners and customers, DI drives the digital transformation in the process and discrete industries. With its Digital Enterprise portfolio, DI provides companies of all sizes with an end-to-end set of products, solutions and services to integrate and digitalize the entire value chain. Optimized for the specific needs of each industry, DI’s unique portfolio supports customers to achieve greater productivity and flexibility. DI is constantly adding innovations to its portfolio to integrate cutting-edge future technologies. Siemens Digital Industries has its global headquarters in Nuremberg, Germany, and has around 75,000 employees internationally.
Siemens Corporation is a U.S. subsidiary of Siemens AG, a global powerhouse focusing on the areas of power generation and distribution, intelligent infrastructure for buildings and distributed energy systems, and automation and digitalization in the process and manufacturing industries. Through the separately managed company Siemens Mobility, a leading supplier of smart mobility solutions for rail and road transport, Siemens is shaping the world market for passenger and freight services. Due to its majority stakes in the publicly listed companies Siemens Healthineers AG and Siemens Gamesa Renewable Energy, Siemens is also a world-leading supplier of medical technology and digital healthcare services as well as environmentally friendly solutions for onshore and offshore wind power generation. For more than 160 years, the company has innovated and invented technologies to support American industry spanning manufacturing, energy, healthcare and infrastructure. In fiscal 2018, Siemens USA reported revenue of $23.7 billion, including $5.0 billion in exports, and employs approximately 50,000 people throughout all 50 states and Puerto Rico.
Continue reading
German Machine Tools of America (GMTA) in Ann Arbor, Michigan, will showcase several of its machine tools and metal fabricating equipment at the Motion + Power Technology Expo. The show will take place September 14-16, 2021 in St. Louis, Missouri and is produced by AGMA. It connects top manufacturers, suppliers, buyers and experts in the mechanical and gear power, electric power and fluid industries.
The company represents several high quality, high performance lines including Arnold, BvL, K+G, Profilator, Rasoma, Samag and its latest addition, Stiefelmayer. Arnold laser technology provides a complete line of laser welding machines for the automotive, aerospace and other markets. BvL offers parts washing systems, equally suited as a one-off station for large castings/forged products or as a continuous washing and drying line. K+G are high-tech machine tools for internal or external grooving, turning and milling.
Profilator is a world-renowned brand of machines for gear pointing, cutting, rounding, deburring, polygon slot facing and the SCUDDING® process. Rasoma is a builder of vertical turning centers and inverted spindle turning machines for milling, drilling and special machining. Samag machining centers and deep hole drilling machines are used in the automotive, off-highway and moldmaking industries. Stiefelmayer lasers cut products such as motor laminations, as well as laser hardening, fiber and diode types. Lastly, GMTA offers its own line of baskets, trolleys and lift tables.
Visit GMTA at booth 3513, co-located with STAR SU
For more information, please contact
GERMAN MACHINE TOOLS OF AMERICA (GMTA)
4630 Freedom Drive
Ann Arbor, MI 48108
Phone: 734-973-7800
Fax: 734-973-3053
Web: www.gmtamerica.com
Email: sales@gmtamerica.com
Attention: Walter Friedrich, President
In-Place Machining Company, LLC (“IPM”), a globally recognized high acuity field machining company focused on providing highly technical, precision on-site machining, diamond wire cutting and measurement services to customers, announced today that it has acquired Exact Metrology as of July 2, 2021. As part of the In-Place Machining Company long term growth strategy, this acquisition will expand In-Place Machining Company’s service offerings to include 3D scanning, Industrial CT scanning, metrology equipment sales, and software solutions. This exciting addition provides In-Place Machining Company a strategic resource to bolster their growing measurement and alignment business. When talking about the benefits of acquiring Exact Metrology, President and CEO of IPM, Dean Flint said, “In-Place Machining could not be more excited about the strategic potential resulting from the combination of these two great organizations. Both have been built on solving their customer’s most challenging technical problems.”
Commenting on this new partnership, Dean Solberg, Vice President of Metrology Sales/Services, states “This opportunity to join forces with In-Place Machining Company is exactly what we were looking for. The ability to combine our metrology expertise and IPM’s expertise with on-site machining will push barriers in every industry. We look forward to combining our collective synergy as one team and taking on high-precision projects together, anywhere in the world.”
With Exact Metrology holding offices throughout the Midwest in states including Ohio, Illinois and Wisconsin, In-Place Machining company will expand their reach and provide the best possible service, sales and technical support across the country.
Dean Flint noted, “We look forward to our company’s customers, employees and their families, and stakeholders all enjoying the benefit of the bright future resulting from this strategic partnership.”
In-Place Machining Company: On-Site Machining Solutions In-Place, Any Place in the World.
In-Place Machining Company, with facilities in Wisconsin, Washington, Virginia, Ohio, and Ontario, Canada, is the premier provider of high-precision engineered on-site machining, metrology, and large scale cutting & drilling services for a wide range of renewable energy, aerospace, industrial, and military customers throughout the world.
Exact Metrology: A Division of In-Place Machining Company, is ISO9001, AS9100 Certified as well as ITAR Registered.
Exact Metrology: A Division of In-Place Machining Company, with facilities in Cincinnati, Ohio, Moline, Illinois and Milwaukee, Wisconsin, plus affiliated offices throughout the country, is a comprehensive metrology services provider, offering customers 3D and CT scanning, reverse engineering, quality inspection, product development and 2D drawings. The company also provides turnkey metrology solutions, including equipment sales and lease/rental arrangements.
For more information, please contact:
In-Place Machining Company
Dean Flint
3811 N. Holton St.
Milwaukee, WI 53212
Local: 414-562-2000
Toll Free: 800-833-3575
www.inplace.com
DFlint@inplace.com
Exact Metrology: A Division of In-Place Machining Company
Dean Solberg
20515 Industry Avenue
Brookfield, WI 53045
Local: 262-533-0800
www.exactmetrology.com
deans@exactmetrology.com
Exact Metrology: A Division of In-Place Machining Company
Steve Young
11575 Goldcoast Drive
Cincinnati, OH 45249
Local: 513-831-6620
Toll Free: 866-722-2600
www.exactmetrology.com
stevey@exactmetrology.com
Exact Metrology, a comprehensive 3D metrology service provider and hardware sales company, is excited to announce that a large scale Coordinate Measuring Machine (CMM) has been installed at their office location in Moline, Illinois.
This machine is a high-accuracy CNC coordinate measuring machine that guarantees a maximum permissible error of E0, MPE = (2.5+3L/1000)μm. With this machine, measurement uncertainty remains within one-fifth of the dimension tolerance up to 30.2” (766mm). The higher accuracy specification therefore gives it more than double the effective measuring range in terms of accuracy-guarantee capability.
In addition, the room the machine sits in is temperature controlled. From sensors installed on each axis scale and working in conjunction with sensors placed on the workpiece, temperatures are obtained before outputting the measurement result to the controller. The combined axis scale/workpiece temperature compensation design used gives superior results compared to systems with sensors only on the axis scales.
This CMM offers a maximum drive speed of 693 mm/s and a maximum drive acceleration of 1,732 mm/s2 resulting in an increase of drive distance in one second. Combining high speed and high acceleration, this machine reduces measuring time. As the number of measuring points increases, measuring costs per point are reduced.
It will be used by Exact Metrology for precision machined parts and has a measuring volume of 47 inches by 78 inches. Components, parts and finished durable products that are designed to maintain extreme tight tolerance margins, as well as a high degree of durability are essential and common drivers for the use of precision machining. Precision machined parts typically have intricate features and need precise specifications and measurements. Additionally, many of these parts have holes, grooves, tapers, and/or textures that require an exact fit into other components. Precision machining is used in numerous applications such as: aerospace, medical device components, electronics, oil and gas, etc. CMMs don’t need the “old school” method of calipers, measuring tapes, and/or rulers.
Commenting on this new arrival, Exact Metrology co-President, Dean Solberg, said, “We’re very happy to install this machine and we’ve even heightened our ceilings and reinforced our floors to make sure it fits inside our facility. We look forward to using this CMM to further our customer service reach.”
Exact Metrology is ISO, AS9100 Certified as well as FFL and ITAR Registered.
Exact Metrology, with facilities in Cincinnati, Ohio, Moline, Illinois and Milwaukee, Wisconsin, plus affiliated offices throughout the country, is a comprehensive metrology services provider, offering customers 3D and CT scanning, reverse engineering, quality inspection, product development and 2D drawings. The company also provides turnkey metrology solutions, including equipment sales and lease/rental arrangements.
For information, please contact:
EXACT METROLOGY, INC.
Dean Solberg
20515 Industry Avenue
Brookfield, WI 53045
Local: 262-533-0800
www.exactmetrology.com
deans@exactmetrology.com
Winner of ANCA Tool of the Year revealed live at EMO and see a tailored skiving cutter machine GCX to service the booming Electric Vehicle market
As the cutting tool industry moves towards more complex geometries and away from standard tools, manufacturers are needing to find new solutions. Often referenced as special tools, ANCA will showcase the technology, software and automation at EMO Milano 2021 that enables customers to design and grind multiple tool types in one batch, making special tools a more profitable strategy.
Patrick Boland, ANCA Co-Founder said: “Customers are after more productivity, higher accuracy, and increased process stability. There is great interest in automation, Industry 4.0, and technologies that can digitally connect all aspects of production. What’s new at ANCA is what we call AIMS, or the “ANCA Integrated Manufacturing System.” It’s the overarching platform under which we’ll be releasing software and hardware though the coming years. At the top is a suite of management software, and underneath is all the hardware necessary to grind, measure, and process complex cutting tools.”
“We are proud to have our new AutoMarkX laser marking system on the stand at EMO, a machine that further simplifies tool manufacturing process by achieving greater efficiencies and reductions in simple manual tasks. Compatible with ANCA’s flexible software suite, AutoMarkX automatically loads tools directly from grinding machine pallets to be laser marked. ANCA’s own technology is designed for integration with AIMS (ANCA Integrated Manufacturing System), to automatically receive and dispatch pallets using an AMR (Autonomous Mobile Robot) while connectivity to the AIMS Server provides the data to be marked on the tools,” Patrick concluded.
Electric Vehicles
From a CNC tool and cutter supplier’s point of view, Electric Vehicles (EV’s) growth in the market is a challenge as well as a revolutionary opportunity. In 2017, 11.8 percent of cutting tool consumption was for automotive manufacturing. However, the rise of EVs and the associated manufacturing changes will significantly impact this. The machining time required for pure EVs will reduce by 50–75 percent compared with traditional internal combustion engines (ICEs). This will result in a decline in overall cutting tool consumption as ICE vehicles’ production declines.
Xiaoyu Wang, ANCA GCX Product Manager said: “Declining demand for cutting tools is an existential challenge, especially for our customers who serve the automotive industry. However, entering the supply chain of EV manufacture provides many untapped opportunities. The new skiving cutters required for manufacturing the internal gears used in EV transmission is a significant one. About 45 percent of all gear production is for vehicle transmission. The growth in EVs has drastically changed the requirements for the gear cutting and production industries. For example, the high engine speed of up to 20,000 RPM means a higher gear ratio is required to reduce the speed for efficient use in automobiles. Additionally, the complex planetary gear systems are more prevalent in the new electric transmission design.”
Driven by EV’s unparallel 28%~36% growth rate, the skiving cutters used in the high-speed skiving processes are in high demand. Due to their complex geometries, producing solid carbide skiving cutters requires a series of technology and process developments that enable their consistent and repeatable production. ANCA will bring its GCX Linear machine to EMO so customers can understand how it provides a complete solution for manufacturing DIN AA quality solid carbide skiving cutters – the highest in the industry.
Visit ANCA at Stand F10 G09, Hall 2 to get a demo.
ANCA Tool of the Year
ANCA’s industry first competition is back with the 2021 winner to be announced live at EMO. Last year the industry welcomed the opportunity to show off their skills with almost 30 entries received from across the globe being seen by over 80,000 fans generating over 200,000 engagements on social media.
The competition offers global recognition and generous prizes; celebrating the magic of the cutting tool and the experts who create them.
AutoMarkX
AutoMarkX is an automatic stand-alone laser marking station replacing manual and labor-intensive process. It is AIMS compatible which means it can work in a fully automatic mode without a need for human intervention, if required. The operator can load pallets full of tools and walk away to take care of more productive and value adding tasks. The unit can accommodate a wide range of tool sizes, making it a versatile proposition for many manufacturers. The attractive return on investment (ROI) makes it a logical choice for your tool making businesses.
GCX Linear
The GCX Linear sets the new benchmark for skiving cutter production. Adapted from ANCA’s proven top-of-the-range CNC grinder platform, the GCX Linear adds tailored features to finish all operations for skiving cutters and shaper cutters in a single setup. With industry-first in-process profile measurement and direct path compensation, ANCA provides a practical closed-loop production solution.
CPX Linear
Capable of achieving a surface finish better than 0.2 µm (0.000008 in) RA with run-out of less than 2 microns, this four axis grinder for creating tool blanks complements ANCA’s full machine range. The CPX Linear has a large working envelope and powerful grinding spindles, achieving the highest precision and productivity for blank preparation in the market today. Using the PinchPeel method of grinding it offers the same strength, rigidity and thermal stability expected from an ANCA tool grinder.
FX7 Linear
For customers that require increased flexibility or more spindle power, or the increased automation capacity that a robot can provide, the FX7 Linear offers these. The FX7 Linear offers a wide range of options for those looking to increase productivity and accuracy. Available is an optional 6-station wheel changer for automatic loading of wheel packs and coolant manifolds, and also robot loader options with capacity to load up to 840 tools.
For further information, please contact:
Johanna Boland
Group Strategy and Communications Manager, ANCA
M: +61 407799779
Johanna.Boland@anca.com
ANCA is a market leading manufacturer of CNC grinding machines. It was founded in 1974 in Melbourne, Australia where the company still has its global headquarters. ANCA has offices in the UK, Germany, China, Thailand, India, Japan, Brazil and the USA as well as a comprehensive network of representatives and agents worldwide. ANCA CNC grinders are used for manufacturing.
ANCA CNC grinders are used for manufacturing precision cutting tools and components across a diverse range of competitive industries including cutting tool manufacture, automotive, aerospace, electronics and medical.
Continue reading
Get set and go with automated laser marking for streamlined production
Traceability is a fast-emerging trend in the manufacturing industry. It is defined as the ability to retrieve the full history or location of an item or product by means of recorded identification. In the tool making industry, the requirement to trace an individual tool and the ability to determine its usage and/or re-grinding history has become an industry standard, allowing end users to maintain the highest tool quality and productivity.
In the tool making production process, tool laser marking is a necessary step that not only serves the purpose of providing basic tool geometry information, but also includes information pertaining to tool provenance and regrinding history. A basic requirement of laser marking is to have identification that is clear, and easy to read and understand.
Laser is the technology of choice for tool marking for several reasons. Firstly, laser produces an indelible mark which is crucial for easy identification throughout the lifetime of the tool. The quality is consistently excellent with high contrast and minimal surface disturbance – both of which are important for cutting tool performance. Secondly, laser technology is very mature which ensures consistent high reliability over many years.
A challenge with using standard manual laser marking stations is that it is among the most labor-intensive activities of any company. Automating the laser marking task is a direct solution to address this, with multiple benefits. Automation saves on labor cost, eliminates human error and frees up staff to perform more value-adding activities. After the initial investment, this asset will perform long-term over many years with a very low level of maintenance required.
ANCA offers two automatic laser marking options for a range of applications and individual requirements.
RoboMate LaserEtch
RoboMate LaserEtch is an integrated laser system that can be added to the ANCA RoboMate loader for the TX and MX platforms, allowing laser marking of individual tools in-process. This is a convenient, compact and flexible solution. After grinding, the tool is automatically laser marked, for example tool ID and graphics such as a company logo – all without any increase to tool takt time. This solution means:
AutoMarkX
An automatic stand-alone laser marking station, the AutoMarkX is the latest addition to ANCA’s family of tool production solutions. The operator simply loads up to two full pallets of tools and the robot performs the laser marking operations, freeing up staff to take care of other tasks in the factory. The unit can accommodate a wide range of tool sizes, making it a versatile proposition for many manufacturers.
ANCA’s laser marking systems can be integrated into the AIMS Server to become a part of a fully automated production cell. In this case, sequential tool production processes are fully automated right through to laser marking on the tool. AIMS also provides a platform for extended functionality including tool traceability and serialization.
For further information, please contact:
Johanna Boland
PR and Communications Manager, ANCA
M: +61 407 799 779
Johanna.Boland@anca.com
ANCA is a market leading manufacturer of CNC grinding machines. It was founded in 1974 in Melbourne, Australia where the company still has its global headquarters. ANCA has offices in the UK, Germany, China, Thailand, India, Japan, Brazil and the USA as well as a comprehensive network of representatives and agents worldwide. ANCA CNC grinders are used for manufacturing.
ANCA CNC grinders are used for manufacturing precision cutting tools and components across a diverse range of competitive industries including cutting tool manufacture, automotive, aerospace, electronics and medical.
ANCA website: www.anca.com
