Guill Tool Launches In-House Rheology Lab

With the ability to test materials before they are extruded, Guill customers receive testing coupled with industry experience and shorter lead times

Guill Tool, manufacturers of extrusion tooling for the global market, has opened an in-house rheology laboratory, making it the only extrusion tooling manufacturer in the industry with such a capability. Seeking to obtain better results and minimize the time it takes between testing and production, Guill built its own rheology lab in their facility in West Warwick, Rhode Island, USA. The lab features several key machines that ensure optimum results, when testing materials, especially new compounds to be extruded.  The testing equipment includes a Hybrid Rotational Rheometer, a Differential Scanning Calorimeter, and a Thermal Conductivity Meter.

Third-party testing facilities are typically not experienced in extrusion processes.  Guill, however, can not only gather data the same way third-party testers can, but can also interpret that data as it applies specifically to extrusion.  Likewise, third-parties simply supply data, not recommendations.  Guill is now equipped to both test its customer’s materials and work with them to create extrusion tooling that will give them a competitive edge.  Accurate simulation and interpretation by extrusion experts greatly reduces the number of physical reworks needed, as the tooling has a greater chance of producing a good product at the outset. In-house testing also speeds up the turnaround on test results, reducing delays during the tool design process and offering better control over the processes and test parameters.

The new Guill rheology lab processes standard materials, custom formulae and it is equipped to mix materials. These materials include plastics, thermoplastic elastomers, all types of rubber and silicone. Information from the lab is transmitted directly to the Guill engineering department via computer link for review by the design team.

The lab will be offered for use by extruders and chemical formulators, among others in the industry.  Please contact Guill for full details.


For more information, please contact:

Bill Conley, Sales Manager
Guill Tool & Engineering
10 Pike Street
West Warwick, RI 02893
USA
Phone:  401-828-7600
www.guill.com
bconley@guill.com

Continue reading

Guill Announces New 800 Series Hybrid Extrusion Tooling

800 Series HybridGuill announces the introduction of a new version of its popular 800 series, known as 800 Series Hybrid. In some extrusion applications that utilize crossheads and inlines, layers of the exact same material are applied multiple times, using a single die. This method is used to reduce the propensity for errors caused by gels breaking through a thin wall, weld lines, inconsistent wall thickness, plus material and process variations. Additional errors include difficult-to-process materials and demanding applications where there is zero fault tolerance.

Seeking to design the next generation multi-layer die to overcome these challenges, the engineers at Guill looked for a way to incorporate this technology into an updated version of the 800 Series. This led to the creation of the 800 Series Hybrid. The inherent benefits of the 800 Series are retained, including compact design, low residence time and a common deflector bore that eliminates tolerance stack up. The challenge was to create a hybrid design that incorporates the benefits of layer overlapping, while reducing unnecessary complexity and making the technology more cost-affordable for customers. This was achieved by overlapping layers in each semi-deflector, using a single cone. The highly efficient design of the 800 Series Hybrid reduces cost and size, as opposed to other methods of overlapping layers.

Essential benefits of the 800 Series Hybrid include eliminating weld lines in materials through patented overlapping technology, producing a more consistent finished product; reduced sensitivity to changes in viscosity; reduced sensitivity to changes in line speed; myriad material and multi-layer application possibilities; works in all tubing and jacketing applications with a wide range of materials; low residence time; compact design and a low tolerance stack-up error factor, all resulting in improved concentricity.

The 800 Series Hybrid extrusion tool greatly reduces stagnation, because overlapping layers are more inherently balanced than single layers and also because each semi-deflector is “tuned to flush.” Conventional deflectors must simultaneously achieve a balance between flushing, balancing and eliminating the weld line. There is less difference between the slowest moving material and the fastest moving material in the deflector channels, thus making the viscosity more consistent in the deflector.

For more information, please contact:

Bill Conley, Sales Manager
Guill Tool & Engineering
10 Pike Street
West Warwick , RI 02893
(401) 823-7600
www.guill.com
sales@guill.com

Continue reading

Bernal Industrial Named Guill Representative for Mexico

Firm has agents throughout the country, serving the extrusion industry

Guill dies and crossheads for plastic, rubber and other material extrusions are now being sold by Bernal Industrial throughout Mexico. With more than 50 years of experience, Guill is a recognized technology leader in the design and manufacture of extrusion tooling for various applications. These include medical tubing, multi-lumen, multi-layer, profile products, rubber, plastics, wire & cable and fiber optic sheathing.

bernal

Bernal Industrial operates as a consultative engineering representative agency, distributor and service provider for its lines. Daniel Bernal is the manager and director of Bernal Industrial. Besides its main office in El Paso, Texas, Bernal Industrial has Mexican offices in Baja California, Chihuahua, Tamaulipas, Nuevo Leon, Mexico City and Queretaro. Bernal also sells products for Nordson PPS (Xaloy, BKG, EDI), American Roller, Scantech, Regloplas, Getcha, Matsui and Pillar Tech, among others.

The company has been in business for 18 years and has 15 employees. During that time, Bernal Industrial has become a major force in Mexico by aligning themselves with industry leaders in the plastics and rubber processing market to provide cutting-edge technology to all the major markets in Mexico, including auto, aero, medical and appliance. Their team comprises industry professionals who have hands-on experience and can provide highly technical application assistance for the products that they bring to the market. Bernal Industrial currently contacts all plastic and elastomer processors in Mexico, including the affiliates of major U.S. and international companies.

Bernal will be promoting the complete line of Guill products. Asked about this partnership, Daniel Bernal commented, “We are looking forward to working with Guill and finding many new business opportunities for them throughout Mexico.”
bernal-company-logo

For more information, please contact:

Thomas Baldock
Guill Tool & Engineering
10 Pike Street
West Warwick , RI 02893
(401) 823-7600
www.guill.com
tbaldock@guill.com

Continue reading

New 500 Series Rubber/Silicone Extrusion Crosshead from Guill Tool

New extrusion head from market leader features Mechanically Assisted Gum Space (MAGS) adjustment

Guill Series 500 crosshead with Mechanically Assisted Gum Space (MAGS) adjustment…specially designed for the flow characteristics of elastomeric compounds

Guill Series 500 crosshead with Mechanically Assisted Gum Space (MAGS) adjustment…specially designed for the flow characteristics of elastomeric compounds

Guill Tool introduces the NEW 500 Series crosshead with MAGS gum space adjustment. The 500 Series is designed specifically for the flow characteristics and unique processing challenges of elastomeric compounds. One of the key features engineered by Guill on this new crosshead design is the mechanically assisted gum space (MAGS) adjustment system. This new method of gum space adjustment allows the operator to make an effortless adjustment from a single point using a common socket wrench. No more need to struggle with multiple nuts and bolts in order to adjust gum space, which leads to faster adjustments. The visual indicator on the core tube allows the operator to see how far the gum space has been moved, making those adjustments much more accurate and repeatable.

The hardware-free and patented cam lock design of the NEW 500 Series from Guill means no time is wasted unbolting and re-securing fasteners for disassembly and re-assembly. Only half of a rotation of the cam nut is required to loosen and automatically extract the deflector from the head body, which is another time saver. Also, with no undercuts on the deflector, there are no material hang-ups when extracting the deflector, allowing for faster and easier cleaning and changeover.

The NEW 500 Series also features the latest Center-Stage concentricity adjustment system that significantly reduces pressure on the tooling, allowing easier and more precise concentricity adjustments without loosening the face bolts. Easy-Out inserts for the adjusting bolts also allow simple replacement of locked or damaged adjusting bolts, which further saves on repair and downtime.

Another innovative feature of this new rubber/silicone crosshead is a cast aluminum liquid-fed cooling sleeve that allows the user to switch out the cooling jacket in the event of a line obstruction, again reducing downtime compared to traditional integrated cooling systems.

The NEW 500 Series crosshead with MAGS gum space adjustment is a drop-in replacement on most existing NRM lines, however this crosshead design can also be adapted to fit any extruder design or line layout.

The addition of a newly designed flow inlet channel reduces the shear and heat that is generated as the materials are being processed. This leads to lower head pressures allowing the material to move through the head in a much more balanced and even flow.

All crossheads supplied by Guill are furnished with a tool kit for assembly and disassembly as well as a detailed operator’s instruction manual. The engineering team at Guill will gladly assist users in the implementation and operation of the NEW 500 series crosshead.

For a video of the NEW Guill 500 Series crosshead with MAGS gum space adjustment, please go to:



For more information, please contact:



Bill Conley, Sales Manager
Guill Tool & Engineering
10 Pike Street
West Warwick, RI 02893
USA
Phone: 401-828-7600
www.guill.com
sales@guill.com



Continue reading

Co-extrusion Crosshead For Irrigation Tubing From Guill Tool



New low-volume spiral flow ABA crosshead with 2-stage clamping for easy concentricity adjustment

Series 824 Co-Extrusion Crosshead

Series 824 Co-Extrusion Crosshead

Guill Tool introduces Series 824, a co-extrusion crosshead designed for irrigation tubing with an emitter tool.   Manufactured from stainless steel, this new crosshead features balanced flow design with spiral technology that improves flow characteristics at all extruder speeds.  Dual feed ports provide concentric compound flow, while the splits flow from one extruder to feed the inside and outside layers via a manifold assembly.   Series 824 is adaptable to all popular extruders on the market currently.

Capacities include a max. die ID of 1.875”, max. core OD of 1.250”, max. tip OD of 1.500” and max. emitter tool OD of 30mm (1.18”).   The Series 824 design allows the emitter insertion tool to pass completely through the crosshead ID.  Gum space adjustment is performed with die nut rotation, while the Guill 2-stage clamping mechanism allows easier concentricity adjustment.   Quick-change tooling and a tool kit for disassembly and re-assembly are provided with the unit.

Series 824 Crosshead Core

Core of Series 824 Crosshead

Bill Conley, sales manager for Guill, comments, “On this project, the customer challenged us with an application that required precise placement and bonding of preformed emitters within the extruded tubing without melting them in the crosshead.   It was also necessary to process either a low-cost ABA layer construction or single-layer construction within the same unit.”

With the Series 824, the customer realized cost reductions, better quality, less scrap and more uptime in their process.  The Guill cool-tube design prevented the emitter from melting in the head and the overall unit mechanics allowed more rapid and easier changeover from a co-extrusion to a single layer.

Series 824 Crosshead on Tool Stand

Series 824 Crosshead on Tool Stand

On this project, Guill also supplied the customer the company’s extrusion tool cart, which facilitates easy alignment and tool changes.  The removable cart swing gates stay free from accumulated process fluids, while the adjustable height means the cart is compatible with virtually any extruder model.  Thermal isolation in the design keeps heat in the head, not the cart.

For further information, please contact:

GUILL TOOL & ENGINEERING CO., INC.
10 Pike Street
West Warwick, RI 02893
Phone:  401-828-7600
Web:  www.guill.com
Email:  sales@guill.com
Attention:  Bill Conley
Connect with Guill Tool online:  twit gplus fb

Continue reading

“The Bullet™” Extrusion Head from Guill Tool

New extrusion head from market leader features NO hardware, for easy cleaning, plus quick-change tooling, as tips removes from the back, die from the front

The Bullet, showing the absence of hardware, i.e. nuts and bolts, so disassembly, cleaning and restart are made easier | Guill Tool

The Bullet, showing the absence of hardware, i.e. nuts and bolts, so disassembly, cleaning and restart are made easier

Guill Tool introduces The Bullet™, a new extrusion head with fixed center design, multi-port spiral flow design and gum space adjustment, plus the added feature of no fastening hardware, so cleaning and restart are easier and faster than any conventional head on the market currently, according to company sources.

The Bullet allows quick tooling changes, as the tips remove from the back and the die removes from the front of the unit.  The absence of fastening hardware eliminates leaking, as does the taper body and deflector design pioneered by Guill.

High- and low-volume applications are suitable for this head and are accommodated with the simple, easy changing of just one component.   A family of crosshead designs is available and users can specify the “caliber”, that is, the max. die ID.

A vacuum chamber and kit for assembly and disassembly are included with the unit.   Optional keyed tooling capability offers machine designers and end users quick orientation, so the overall unit design enables faster disassembly, proper cleaning and restart, allowing the line to become more profitable.

For further information, please contact:

GUILL TOOL & ENGINEERING CO., INC.
10 Pike Street
West Warwick, RI 02893
Phone:  401-828-7600
Web:  www.guill.com
Email:  sales@guill.com
Attention:  Bill Conley
Connect with Guill Tool online:  twit gplus fb

Continue reading

Guill Tool Offers Wide Variety of Extrusion Tooling at NPE 2015, Booth 5549

Guill Tool, a West Warwick, RI designer and builder of extrusion tooling, offers an assortment of literature for machine builders and extruders at its website, www.guill.com.

Individual brochures are offered, depicting the wide array of tooling possibilities…straight inline heads, rotary heads and crosshead dies…available to suit any extrusion machine built anywhere in the world, running all types of compounds.

Guill provides tooling for plastic, rubber, TPE and other material extrusions, with end products ranging from extremely thin-walled, multi-lumen medical tubing and catheter balloon tubings up to multi-layer wire & cable jacketing and 20” diameter pipe for industrial applications and agricultural drip lines. Guill also provides tooling for film, sheet and profile extrusions.

The company designs, engineers, machines, assembles, tests and delivers all tooling to its worldwide customer base in all the consuming industries for extrusions. The company also offers tooling carts and disassembly/cleaning stations for easier line integration.

According to company sources, the utilization of properly designed and engineered tooling can result in substantial material savings for extruders of all types.

NOTE: Guill will attend MD&M West in February, NPE in March and Interwire in April, 2015.

Please visit www.guill.com to request a quotation or obtain company literature.

For further information, please contact:

GUILL TOOL & ENGINEERING CO., INC.
10 Pike Street
West Warwick, RI 02893
Phone: 401-828-7600
Web: www.guill.com
Email: sales@guill.com
Attention: Bill Conley
Connect with Guill Tool online: twit gplus fb
