Tag Archives: brochure

Suhner Offers Various Tooling Products in Its Machining Division

New brochure details wide assortment of components for machine tool builders, integrators and end users in all metalworking sectors

Suhner, a leading manufacturer of automated tooling components, slides and multi-spindle components, has expanded its product offering, detailed in a new brochure the Machining Division. Known best for its drilling and tapping units, milling units, machining slides and other specially designed devices for high production work, the company continues to experience increased demand for its machining products and services.  As detailed in this new brochure, the Suhner Machining Division offers several new and enhanced products including flex shaft multiple drive system, QUILLmaster Drilling Units, TAPmaster tapping units, stationary and self-feed, flexible-shaft driven drilling units, POLYdrill multiple spindle heads, SPINDLEmaster machining spindles and SLIDEmaster.  All are designed for high-production work, especially in the automotive and other mass component market sectors.

The flex shaft multiple drive system works with MULTImaster drilling units. It offers up to 8 driving units, a motor rating of 5 HP (3.7 kW) standard and an output speed between 46-9,320 rpm. Optional features include a larger motor and a right angle drive.

QUILLmaster drilling units are self-fed drilling units, motor driven and pneumatic-fed. The total stroke is up to 4.9 in. (125mm), same as the controlled stroke. Furthermore, the QUILLmaster has a drilling capacity with  diameter up to  0.8 in.  (20 mm) for mild steel and a motor rating between 0.3-5 HP (0.22 kW -3.7kW). Tool holding options include ER, ST, ISO/CAT, HSK & custom.

Suhner stationary and self-feeding, flexible shaft driven drilling units feature total stroke up to  3.1 in. (80 mm) and controlled stroke up to 2.9 in. (75 mm).  The flexible shaft drilling unit has a drilling capacity with diameter up to 0.47 in. (12 mm) into mild steel. Available tooling holding options are ER, ST and custom.

TAPmaster includes CNC or leadscrews tapping units. Leadscrew tappers offer a total stroke up to 3.9 in. (100 mm), a tapping capacity up to .787 in. (20 mm) and a thread pitch between 64-13 TPI (0.4-1.75 mm). Available options are custom leadscrew pitches and crash protection on some units. Servo tappers feature a total stroke up to 5.5 in. (140 mm) and a tapping capacity up to .787 in. (20 mm).

POLYdrill multiple spindle heads include adjustable and fixed spindle heads. Drilling capacity ranges from 0.06 to 1 in. (1.5-25 mm). Minimum hole spacing is 0.27 in. (7 mm), while maximum hole spacing is limitless. Tooling options include ER, ST, JT33, Weldon and custom. Additional features are axial and radial compensation and custom layout/spacing.

The company’s SPINDLEmaster features precision turning spindles and slide units. The drilling capacity has a diameter up to 1.6 in. (40 mm) into mild steel and a motor rating between 0.75-10 HP (0.56 kW-7.5 kW). Tool holding options include ER, ISO/CAT,  HSK, Weldon and ABS. Available options  are coolant through automatic tool charger, taper roller or angular contact bearings and higher capacity spindles.

Lastly, the SLIDEmaster offers pneumatic, hydraulic and servo (ball screw) slide types. Stroke options include 6.3, 12.6 and 18.9 in. (160, 320 and 480 mm). Additional options include custom stroke lengths and higher capacity slides.

For more information, please contact:

Suhner Industrial Products, LLC
43 Anderson Road SW
Rome, GA 30161
Phone 706/235-8046
Fax 706/235-8045
Attention: Lee Coleman

Continue reading

BCN Offers Press Parts, Repairs, and Rebuilds to OEMs

Brands of the Schuler Group provide customers with a wide range of products and services to meet their needs

BCN Parts Repair and Rebuild BrochurePart of the Schuler Group, a technological and global market leader in forming technology, BCN stands for machine brands Bliss, Clearing, and Niagara. BCN’s parts and products are available at the company’s 180,000 sq. foot facility in Hastings, Michigan. At this ISO 9001 certified facility, 150 skilled technicians and engineers manufacture quality parts for various pieces of equipment. These include face bridge mills, CNC lathes, CNC boring mills, surface grinders, rotary grinders, turret lathes, and many others.

Bliss Clearing Niagara technical services offer a complete range of related products-including spare parts, repair, inspections, remanufacturing, rebuilds, and modernizations.

Modernization services include complete press teardown and analysis, engineering analysis, repair or manufacture of parts and assembly that shows the original OEM specs. Also available are field service, on-site repair, trouble shooting, press relocations and press inspections.

Inside of BCN Repair BrochurePress rebuilds and upgrades are available for clutch and brake systems, overload systems, speed changes, automated die changes, can machinery and electrical controls.

Remanufacturing is offered on all brands of mechanical presses/ hydraulic presses and some forging presses.

OEM users can quickly receive their needed parts, thanks to a unique parts record that contains over 300,000 parts. These include clutches, brakes, gears, bearings, conversions/upgrades, perishable parts, frames, and connections. In addition to the brands that make up BCN, they also carry USI, Toledo, Consolidated Press, Wilkins and Mitchell and Warco.

No matter the age of your part, BCN can provide you with timely and high quality retrofits, repairs, modernizations, replacements and services. Interested parties can contact Tony DeMerle, BCN’s Director of Sales.

For further information, please contact:

Tony DeMerle, Director of Sales
Bliss Press Systems
1004 East State Street
Hastings, MI 49058 USA

About the Schuler Group – www.schulergroup.com

Schuler is the technology and global market leader in the field of forming technology. The company provides presses, automation solutions, dies, process expertise and service for the entire metalworking industry and lightweight automobile construction. Its customers include automobile manufacturers and automotive suppliers, as well as companies from the forging, household appliance, packaging, energy and electronics industries. Schuler is a leader in coin minting presses and implements system solutions for the aerospace, rail transport and large-dimension pipe manufacturing sectors. In the 2016 fiscal year, Schuler generated sales of 1.174 billion euros. After acquiring toolmaker AWEBA and a majority stake in Chinese press manufacturer Yadon, Schuler has a presence in 40 countries with roughly 6,600 employees. Schuler is majority-owned by the Austrian ANDRITZ Group.

Continue reading


Forest City Gear Capabilities Brochure - Click Image To Download

Forest City Gear proudly announces the availability of its new capabilities brochure.  This new literature details the many markets for which the company produces highly-specialized, custom gears to suit the most demanding applications for accuracy, stability and wear.  A world-class gearmaker, Forest City Gear has a reputation in the international market for “excellent without exception,” the mantra of company CEO, Fred Young.

Forest City Gear produces precision gears for a variety of markets, most notably aircraft, aerospace, defense, instruments, medical, racing (boat and auto), high-end sporting goods and more.  The company’s products are found on the Space Shuttle, every car in the starting field at the Indy 500, the world’s longest distance casting reel, highly sophisticated measuring instruments and Siemens magnetic resonance imaging (MRI) machines, as well as Howitzer’s, surface-to-air missiles and other military ordnance.  The company proudly boasts it will have every wheel and actuator gear on Curiosity, the next generation Mars Rover vehicle.  That achievement was based on its outstanding performance on Spirit and Opportunity, the current vehicles occupying the Red Planet.

Long recognized internationally as a leading gear manufacturer, the company continues its philosophy of reinvestment and ongoing purchase of the latest, most advanced gearmaking technology in the world.  As Fred Young explains, “We don’t wait for the order to buy the machine, we acquire the best technology available to push our capabilities into new arenas, every day.  That policy, coupled with arguably the most sophisticated gear quality lab in the world, has kept us in the forefront of the industry for decades.  We’re very proud of that fact.  As evidence of same, Forest City Gear counts dozens of other gear companies among our customers, as they bring work to us which they cannot perform themselves.”

The full brochure is available online at www.forestcitygear.com, which also details the company in a virtual tour of the facility, plus videos and a full personnel directory of key contacts.

For more information or a copy of this new capabilities brochure, please contact:

11715 Main Street
Roscoe, IL 61073-0080
Phone:  815-623-2168
Fax:  815-623-6620
Web:  www.forestcitygear.com
Email:  wyoung@forestcitygear.com
Attention:  Wendy Young, President
