Tag Archives: Industrial PR

Grieve Cleanroom Electric Oven

500ºF Class 100 Cleanroom Electric Cabinet Pass-Through Oven From Grieve

Grieve Cleanroom Electric OvenNo. 971 is an electrically-heated, 500ºF (257ºC) Class 100 cleanroom cabinet oven from Grieve, currently used to sterilize glassware at the customer’s facility. Workspace dimensions measure 36” W x 36” D x 39” H.  20KW are installed in Incoloy sheathed tubular elements to heat the unit, while a 1200 CFM, 1-1/2 HP recirculating blower motor provides horizontal airflow to the workload.

This Grieve cleanroom oven features 4” thick insulated walls throughout and a Type 304, 2B finish stainless steel interior with 1/2” inside radius corners, all seams welded, ground and polished.  The stainless steel exterior has a #4 brushed finish.  The unit is equipped with front and rear access doors for pass-through to the cleanroom plus an integral wall sealing flange.  A red pilot light onboard the oven signals when the opposite door is open.  All door hardware is chrome plated.

For Class 100 cleanroom compliance, this cabinet oven has a 12” x 12” x 6” thick HEPA fresh air filter with 2” prefilter and a 30” x 24” x 6” thick stainless steel high temperature HEPA recirculating filter.

Controls on No. 971 include a minihelic pressure gauge and DOP validation port across each set of filters, digital programming temperature controller, manual reset excess temperature controller with separate contactors, recirculating blower airflow safety switch, 10” diameter circular chart temperature recorder, fused disconnect switch and an SCR power controller.

A stainless steel loading truck with six removable pans and a transfer dolly with oven-to-dolly and dolly-to-truck latches are also furnished with this Grieve oven.


For more information, please contact:
THE GRIEVE CORPORATION
500 Hart Road
Round Lake, Illinois 60073-2835
Phone: (847) 546-8225
Fax: (847) 546-9210
Web: www.grievecorp.com
Email: sales@grievecorp.com
Attention: Frank Calabrese.

Continue reading
Grieve 954

2000°F Inert Atmosphere Heavy-Duty Box Furnace

No. 954Grieve 954 is an electrically-heated 2000°F(~1093°C) inert atmosphere heavy-duty box furnace from Grieve, currently used for heat treating titanium at the customer’s facility. 57 KW are installed in nickel chrome wire coils, supported by vacuum-formed ceramic fiber, to heat the load. Workspace dimensions are 30” wide x 48” deep x 30” high. The oven’s 7” thick insulated walls comprise 5” of 2300°F ceramic fiber and 2” of 1700°F ceramic fiber, while the 6-1/2” floor insulation comprises 4-1/2” of 2300°F firebrick and 2” of 1200°F block insulation.

The unit is equipped with a roof-mounted heat-resisting alloy recirculating fan, powered by a 1-HP motor with V-belt drive, motor-operated vertical lift door, 100 lb. capacity alloy loading cart with cast alloy roller rails, 3-1/2” diameter cast alloy rollers and a roller rail loading table with 4” diameter cast iron rollers.

This Grieve furnace also features inert atmosphere construction, consisting of a continuously welded outer shell, high temperature door gasket, sealed heater terminal boxes, inert atmosphere inlet, inert atmosphere outlet and inert atmosphere flowmeter.

Controls onboard No. 954 include a digital programming temperature controller, manual reset excess temperature controller with separate contactors, plus a strip chart recorder.


For more information, please contact:
THE GRIEVE CORPORATION
500 Hart Road
Round Lake, Illinois 60073-2835
Phone: (847) 546-8225
Fax: (847) 546-9210
Web: www.grievecorp.com
Email: sales@grievecorp.com
Attention: Frank Calabrese.

Continue reading
Profilator S-150

GMTA Presents New Profilator Machines

GMTA, the North American distributor of Profilator, has added new machines using the process modules it already supplies. Profilator is suitable when customers require complex machining processes to be carried out effectively, efficiently and with high precision.

Example of Scudding®
Example of Scudding®

Today, an operator working on a modern machine expects a flexible manufacturing process, short cycle times, reduced investment and running costs. With these requirements in mind, Profilator offers polygon & face slot machining, gear tooth pointing, chamfering and deburring, gear and spline cutting, shifter stop machining and Scudding®.

The polygon turning unit is used for castle teeth machining on automotive gearbox parts. The rotating cutterhead is synchronized with the workplace spindle and a front face coupling is produced with the carbide insert arrangement and the transmission ratio. With additional inserts on the same cutter head, the part can be deburred. In gear tooth pointing, the pointing tower can be used in both rotative and indexing modes. Settings and corrections are made through the new Ergo Control SIMPS® (Profilator Simplified Integrated Machine Programming System). For the chamfering and deburring of splines, gear wheels and shafts, Profilator uses the ZEM series gear deburring machines. This vertical, single spindle gear deburring machine offers clear advantages over conventional deburring machines. Gear cutting is used both for the Profilator rotative gear cutting with inserts and for hobbing. Through the application of Schlagzahn tools and carbide inserts, customers achieve the most economical manufacture of splines, gears, involute gears and front face gears. The shifter stop is synchronized so that the tool machines each tool flank. Lastly, Scudding® can be used for a wide range of symmetrical gear applications as well as non-symmetrical gear or profile applications such as belt pulleys and synchronize gears. The same machine can be used for internal and external Scudding® applications.

Example of Scudding®
Example of Scudding®

Profilator developed the S-type machine. This is a compactly and modularly designed, vertical single spindle pick-up gear cutting machine. Machines in the S Series are better than broaching and most applications feature a dry machining process. All machine components are designed for especially high static stiffness and optimal dynamic behavior. Furthermore, the machine’s twin spindle arrangement speeds up the process considerably. A control panel and a media container are installed on the rear of the machine bed. The workplace flow direction is variable. S-type machines are available in three sizes, namely Profilator S-150, Profilator S-250 and Profilator S-500. Profilator S-150 has a part diameter up to 150 mm, while Profilator S-250 and S-500 have a part diameter up to 250 mm and 500 mm, respectively.


For more information, please contact:
Walter Friedrich
President
GMTA
4630 Freedom Drive
Ann Arbor, MI 48108
+1-734-973-7800
walter@gmtamerica.com
www.gmtamerica.com

GMTA is the exclusive distributor for a number of top-quality German and other metalworking machine builders companies including Arnold, BvL, K+G, Praewema, Profilator, Rasoma, Samag and WEMA Glauchau. The company’s headquarters is located in Ann Arbor, Michigan with a subsidiary in Queretaro, Mexico.

Continue reading

Arnold’s 100th Anniversary Celebrates Company’s History and Technology

Presentations were given by company personnel on September 13, 2019 in Ravensburg, Germany.

Arnold employees from 1919Arnold, a major manufacturer of laser technologies, recently celebrated 100 years at its headquarters in Ravensburg, Germany. The event included various presentations such as: “Development of Technologies,” “Laser Polishing-Development and Opportunities,” “Laser Treatment of Electric Sheet,” “Laser Use in e-mobility” and “From Regional Provider to Global Player.” A brief history with a focus on emerging technologies was given by Hansjörg Klotz, the sales director.

The company was founded in 1919 as a mechanical workshop by Anton Arnold. At the time, the company was considered a special welding plant for cast iron and aluminum. From 1950, under the leadership of Karl Arnold, the company developed contract turning for automatic turning parts. From 1969, the focus shifted to equipment construction and special machines for various industries. In 1985, the first laser system was built for ZF Friedrichshafen.

Arnold machineIn 1985, Spectra Physics, the predecessor of Rofin Sinar, reached out to Arnold for the construction of a rotary axis and clamping technology for a laser welding system for transmission wheels. This project was the first step for Arnold into laser technology. Driven by the idea of using the laser not only as a tool, but as the technology for beam guidance requirements and understanding of the processes, many components have been developed and patented over time. They can still be applied today with improved details. Available in 1985 and beyond, Arnold constructed thousands of clamping devices for milling machines and engine processing. Also included were pallet change systems for large machining centers, assembly lines for motors, test fields, keyboard drills and battery levels.

While competitors need to adjust beam guidance after every mirror change, the change was a matter of a few minutes for Arnold and production could be continued immediately. This production-oriented thinking has continued with the company’s machine designs. All important components were geometrically overdetermined and could only be installed with proper production.

In the first years, Arnold focused purely on welding machines. The aim was always to build a single block machine, possibly supplemented by conveyor belts for component supply and removal.

Current Arnold MachineLater on, more and more functions were integrated. Parts had to be pressed, heated and brushed, and seam detection systems, component handling, conversion strategies, process monitoring, different beam sources, laser concepts, to name a few, had to be integrated into the systems. The effort for commissioning and control grew almost limitless.

Even though there were isolated laser projects parallel to the classic special machine construction of the first few years, the main focus of the company since the 1990s has been the construction of laser systems. The first few laser applications were used in gear wheels, heat exchangers, shaft welding with induction and starter contacts for incandescent lamps.

New technology developed by Arnold features systems for rotary parts such as a double station and the M800/1500 units. In addition, the company offers new concepts of 3D systems used for welding, cutting, powder application welding, hardening and polishing. The newest flex cell and gantry systems feature up to 7 axes working simultaneously. Lastly, the company developed two extreme expansion stages of gear wheel welding systems. These are fully automated systems.

Functional extensions on the current machines include robots, conveyors, press stations, additional axes, induction preheating, UMH preheating, brushing stations, runout test stations and ultrasonic testing.

Current Arnold MachineIt has always been important for Arnold to participate in European-funded research projects. After the fall of the Berlin Wall, contact with Fraunhofer-IWS in Dresden was established. Countless mutual visits, the exchange of process experience and material knowledge on the part of the IWS as well the mechanical engineering experience and enthusiasm of Arnold quickly bore fruit. In 1994, Arnold, together with the IWS and EFD (manufacturer of induction plants), delivered the world’s first plant for welding cast iron to steel. Ford in Düren, Germany was the customer that benefitted from this, producing drive shafts.

Current projects include Melato (manufacture of pressing tools from layered, laser-cut sheets), POLAR (laser polishing), KLASSE (laser cutting and solidification with an optic in a gantry system) and GeKoWig (titanium powder application welding in a protective gas atmosphere).

Together with IWS, Arnold has developed Remoweld Optic, a high-frequency optic scanner. With this scanner, copper, aluminum and mixed compounds can be welded virtually splash-free. With IWS, the company exhibited the optic scanner at various trade shows. The response has been very positive and several interested parties have approached IWS with potential applications.

In conclusion, Arnold has undergone many transformative changes in the past 100 years and it continues to expand its capabilities to better serve its customers.


For more information, please contact:

Walter Friedrich
President
GMTA
4630 Freedom Drive
Ann Arbor, MI 48108
1-734-973-7800
walter@gmtamerica.com

GMTA is the exclusive distributor for a number of top-quality German and other metalworking machine builders companies including Arnold, BvL, K+G, Praewema, Profilator, Rasoma, Samag and WEMA Glauchau. The company’s headquarters is located in Ann Arbor, Michigan with a subsidiary in Queretaro, Mexico.

Continue reading

SencorpWhite Announces New Distribution Agreement with WM Thermoforming Machines

SencorpWhite LogoSencorpWhite, Hyannis, Massachusetts, industry leader in thermoforming machines, is pleased to announce today a new distribution agreement for the United States and Canada with WM Thermoforming Machines.

WM Thermoforming Machines of Stabio, Switzerland, www.wm-thermoforming.com designs and manufactures both in-line and tilt-bed thermoformers that will greatly expand market presence for SencorpWhite. Their FC and Flex Series in-line thermoformers are all-electric with the size and through-put that complements SencorpWhite 2500 and ULTRA series thermoformers. The FT and Twist Series tilt-bed thermoformers, with optional extrusion and rimming stations, fulfils the market requirement for high-volume food container applications.

With this new partnership, SencorpWhite now offers an extended range of thermoforming technology for a broader range of applications. In addition, WM enters the North American market with a highly respected partner, and the expertise and service backed by over seventy years of experience.

The WM-Sencorp team will be at the SPE Thermoforming Conference in Milwaukee, Wisconsin from September 9-11. For more information, please visit: https://thermoformingdivision.com/conference. SencorpWhite will also be exhibiting at Pack Expo in Las Vegas at Booth C-2205 from September 23-25, www.packexpolasvegas.com and the K-Show in Dusseldorf, Germany from October 16-23 www.k-online.com

WM Thermoforming Machines Logo


About SencorpWhite

SencorpWhite, a Connell Limited Partnership portfolio company, is a leading provider of unique end-to-end solutions for the packaging and management of high-value inventory. The company’s products and services, which range from innovative thermoformers and other packaging technologies to automated storage and retrieval systems plus inventory management software, cover the entire supply chain spectrum, from the point-of-manufacture through distribution and point-of-use.

For more information, please contact:
Victoria Garofalo
SencorpWhite
400 Kidds Hill Rd
Hyannis, MA 02601 USA
Phone: 508-771-9400
Email: VGarofalo@sencorpwhite.com
www.sencorpwhite.com

Continue reading

Dukane Announces Acquisition of Aurizon, LLC.

Dukane Booth at IDEA Show - Acquisition of AurizonDukane acquired all the assets and intellectual property of Aurizon, LLC in Kimberly, Wisconsin. Aurizon is a global leader in developing high-power rotary ultrasonic systems for converting nonwoven materials, bonding textiles & films and sealing packages. With 30+ years of R&D in product design and application experience, Aurizon holds a significant patent portfolio. These patents and the team’s experience have significantly improved the speed and capabilities of the ultrasonic continuous bonding process. Over the years, Dukane and Aurizon have worked together closely to develop a generator solution for continuous ultrasonic bonding, sealing and converting.  This collaboration advanced the core technology and application knowledge of Aurizon, Dukane and our customers.

This acquisition will create significant synergies and opportunities for Dukane and Aurizon, allowing both companies to share their technical expertise in the hygiene, personal care, medical disposable and packaging industries. For the hygiene market, Aurizon’s product line will expand with Dukane’s fixed (blade) sonotrode technology for customers who don’t require continuous rotary bonding.  For the packaging industry, both Dukane and Aurizon have developed several applications and will combine their sales and engineering efforts to better meet the demands of our packaging customers. Dukane’s product portfolio includes the ultrasonic, vibration welder, spin welders, laser welders, hot plate welders, hot gas welders and infrared welders. These products will now be complimented by Aurizon’s rotary ultrasonic technology. This addition to the product portfolio will be supported through Dukane’s worldwide sales and service network in conjunction with the team at Aurizon. With Dukane products installed at manufacturing facilities all over the world, Aurizon’s rotary ultrasonic technology will be a welcome addition for existing and future customers.

Dukane and Aurizon Banner - Acquisition of AurizonAurizon will continue sales, support, manufacturing and design at the Kimberly, Wisconsin facility. This facility houses a state-of-the-art application laboratory for rotary ultrasonic applications. The plan is to expand the capabilities of the lab to handle fixed blade horn technology as well. Moving forward, both Dukane’s and Aurizon’s electrical and mechanical engineering groups will be working together in bringing new products and advanced technologies to the market.

President and CEO of Dukane, Mike Johnston says, “I have personally worked with Aurizon’s team for over 25 years. Knowing their technical capabilities and seeing the products they have developed makes me very proud to have Aurizon part of the Dukane organization.  The rotary technology for continuous applications and Aurizon’s capabilities far exceed any supplier in the industry. Rotary technology expands Dukane’s current wide range of ultrasonic processes. Whatever your bonding needs, Dukane has a solution.”


For more information:

Dukane
2900 Dukane Drive
St. Charles, Illinois 60174 USA
Tel: (630) 797-4900
www.dukane.com

Contact:
 Shivani Singh
Marketing Associate
630-762-4325
ssingh@dukane.com

Continue reading
GMTA Hard Scudding

GMTA Presents Profilator and its “Micro-Finishing” Technology at Motion + Power Technology Expo

GMTA Hard Scudding Micro-FinishingWith over 300 exhibiting companies, the Motion+ Power Technology Expo is the ideal show for gear, electric and fluid power industries. Taking place between October 15 and 17, GMTA is one of the exhibitors at the Cabo Center in Detroit, Michigan.

GMTA will feature its Profilator line of gear pointing, rounding, cutting, Scudding®, Hard Scudding®, deburring and polygon machine tools for North America. The highly modular machines are used for polygon and slot facing, shifter stop machining, chamfering and deburring of highly complex automotive and other powertrain gears. The “Scudding®” and the “Hard Scudding®” process sets the Profilator apart in the market because of its manufacturing efficiency. “Hard Scudding®” allows the machining of green and hardened gears on the same machine, using the same programs. Furthermore, it is a superior technology to skiving, the previous technology used in the gear industry.

GMTA Hard Scudding Micro-FinishingWhile Profilator GmbH & Co. KG introduced the concept of “Hard Scudding®” in 2015, it expanded scudding technology with “Micro-Finishing.” “Micro-Finishing” takes place after the Hard Scudding® process has been completed. The process takes a high quality “Hard Scudding®” part and improves its surface quality. Additionally, this is a completely “dry” machining process and requires no cutting fluids or MQL technology. The total cycle time for finishing a ring gear via Hard Scudding® and “Micro-Finishing” is approximately 64 seconds but the cycle time could be decreased by 10%, keeping it under one minute for all automotive gear rings.

GMTA Hard Scudding Profilator Micro-Finishing Machine “Micro-Finishing” technology is aimed at making at quieter gear and the superfinishing process reduces friction, increases pitting resistance and the life of gears. This process uses a high quality diamond plated tool, designed to remove only a small amount of part material. The resulting part greatly increases surface quality on the gear teeth.

Stop by at booth 4439 to find out more about the technologies at GMTA.






For more information, please contact:

Walter Friedrich
President
GMTA
4630 Freedom Drive
Ann Arbor, MI 48108
1-734-973-7800
walter@gmtamerica.com

GMTA is the exclusive distributor for a number of top-quality German and other metalworking machine builders companies including Arnold, BvL, K+G, Praewema, Profilator, Rasoma, Samag and WEMA Glauchau. The company’s headquarters is located in Ann Arbor, Michigan with a subsidiary in Queretaro, Mexico.

Continue reading
Wardwell at Interwire 2019

Wardwell Has a Successful Show at Interwire

Wardwell at Interwire 2019Interwire, the largest and longest-running wire and cable show, took place between May 13 and May 16, at the World Congress Center in Atlanta, Georgia. Wardwell Braiding Company had quite a turnout at their booth. They were able share their knowledge and interact with many potential customers.

Wardwell offered a sneak peak of their new 24 carrier Maypole style braiding machine at booth #1306. The braiding machine has an independently driven capstan instead of change gears to vary the pitch. It is also features a driven wind-up mechanism for reels with a flange diameter of up to 14,” which is rarely used on Maypole style units.  These two features make the B10 the ideal test machine by combining versatility and low cost. Furthermore, the braiding machine works best in a laboratory environment or an R&D environment because users can test run materials or the size of products.

Another product shown at Wardwell’s booth was the Speedmaster 150, a 10 carrier braiding machine for fine wire and integrated with windup for reels up to 35 mm. Additional features include special lower carriers for fine wire, an enhanced sound enclosure with lights and a fan, as well as an automatic central lube system. Finally, the Speedmaster 150 features a tape attachment and a core run-out sensor.




For more information, please contact:

Cynthia Chen
Wardwell Braiding Co.
1211 High Street
Central Falls
Rhode Island, 02863
Phone: 401 724 8800 X 183
Fax: 401 723 2690
Web: www.wardwell.com

Continue reading

NOARK Electric Features New Extended Frame Size at ATX Canada 2019

Noark Ex9C 1000APomona, California– NOARK Electric, a leading low-voltage, electrical product manufacturer, now offers an extended frame size for the Ex9C 1000A.

NOARK Electric has extended its Ex9C general purpose contactor product line up to a 1000 ampacity frame size. NOARK’s popular line of IEC style of AC and DC contactors are UL508 certified and tested for the NEMA market. With the latest extension of the line up to 1000 amperage, NOARK can now address a much larger portion of the industrial control and automation market. The Ex9C1000 frame size will be offered in a 630, 800, and 1000A offering.

NOARK Electric (North America), located in Pomona, California, is a leading global electrical component and intelligent control system supplier. The company is establishing a representative and distribution network to serve its primary markets, which include the building trades and electric panel board builders in various industries. As a global supplier, NOARK currently operates four R&D centers, three distribution centers, 15 office locations and employs over 1,000 associates. Sales currently exceed $2 billion worldwide.

To see firsthand a demonstration of Noark’s latest product developments, visit us at the ATX Canada 2019 Show at Booth 968 or contact your local sales representative at nasales@noark-electric.com


For more information, please contact:

Ed Joe, Marketing Director
Noark Electric (North America)
2188 Pomona Blvd
Pomona, CA 91768
Phone: 779-771-8881
Email: ed.joe@noark-electric.com
Website: na.noark-electric.com

Continue reading

Wardwell Introduces New Braiding Machine at Interwire

Warwell Braiding MachineInterwire took place between May 13 and May 16, at the World Congress Center in Atlanta, Georgia. Wardwell Braiding offered a sneak peak of their new 24 carrier Maypole style braiding machine at booth #1306.

The braiding machine has an independently driven capstan instead of change gears to vary the pitch. It is also features a driven wind-up mechanism for reels with a flange diameter of up to 14,” which is rarely used on Maypole style units.  These two features make the B10 the ideal test machine by combining versatility and low cost. Furthermore, the braiding machine works best in a laboratory environment or an R&D environment because users can test run materials or the size of products.








For more information, please contact:

Cynthia Chen
Wardwell Braiding Co.
1211 High Street
Central Falls
Rhode Island, 02863
Phone: 401 724 8800 X 183
Fax: 401 723 2690
Web: www.wardwell.com

Continue reading
