850°F High Temperature Walk-In Oven from Grieve

Grieve Oven 852No. 852 is an 850°F (454°C), high temperature walk-in oven from Grieve, currently used for heat treating and baking varnish at the customer’s facility. Workspace dimensions of this oven measure 60” W x 96” D x 72” H. 120 KW are installed in Incoloy-sheathed tubular heating elements, while a 7800 CFM, 5-HP recirculating blower provides combination airflow to the workload.

This Grieve oven has 8” insulated walls and a 4” insulated floor. Additional features include an aluminized steel interior and exterior and safety equipment for handling flammable solvents, including explosion venting door hardware.

Controls on the No. 852 include a digital indicating temperature controller & manual reset excess temperature controller with separate contactors.


For more information, please contact: THE GRIEVE CORPORATION, 500 Hart Road, Round Lake, Illinois 60073-2835 USA. Phone: (847) 546-8225. Fax: (847) 546-9210. Web: www.grievecorp.com. Email: sales@grievecorp.com. Attention: Frank Calabrese.

Continue reading

350°F Belt Conveyor Oven from Grieve

350°F Belt Conveyor Oven from Grieve No.897No. 897 is a 350°F (177°C), belt conveyor oven from Grieve, currently used for preheating trays of parts prior to potting operations at the customer’s facility. Workspace dimensions of this oven measure 36” W x 120” D x 15” H. 30 KW are installed in Incoloy-sheathed tubular heating elements, while a 6000 CFM, 5-HP recirculating blower provides vertical downward airflow to the workload.

This Grieve belt conveyor oven has a 48” long open belt loading zone and a 10’ long insulated heat zone with recirculated airflow. Features include a 30” wide, 1” x1” high carbon steel flat wire conveyor belt with 1/4-HP motor drive, variable from 1.4 to 27 inches per minute. Additional features include 4” insulated walls, aluminized steel interior and exterior and a manually operated vertical lift door at unload with viewing window. The oven also has a photo cell to automatically stop the belt when parts reach the unload position.

Controls on the No. 897 include a digital indicating temperature controller, manual reset excess temperature controller with separate contactors, recirculating blower airflow safety switch and SCR power controller.


For more information, please contact: THE GRIEVE CORPORATION, 500 Hart Road, Round Lake, Illinois 60073-2835 USA. Phone: (847) 546-8225. Fax: (847) 546-9210. Web: www.grievecorp.com. Email: sales@grievecorp.com. Attention: Frank Calabrese.

Continue reading

500°F Inert Atmosphere Walk-In Oven from Grieve

grieve oven inert atmosphereNo. 1038 is a 500°F (260°C), inert atmosphere walk-in oven from Grieve, currently used for annealing polyurethane tubing at the customer’s facility. Workspace dimensions of this oven measure 60” W x 72” D x 84” H. 40 KW are installed in Incoloy-sheathed tubular heating elements, while a 4200 CFM, 3-HP recirculating blower provides vertical downward airflow to the workload.

This Grieve walk-in oven has 6” insulated walls and an aluminized steel exterior with white epoxy paint. Type 304, 2B finish stainless steel interior with continuously backwelded seams and inert atmosphere construction are also onboard, including a pressure regulator, flow meter, pressure gauge, inner oven walls sealing directly against ½” thick silicone rubber door seal, blower shaft seal, positive latching door hardware, adjustable offset door hinges, outlet with pressure relief, interior seams welded gas-tight and all wall penetrations fitted with compression fittings. The oven has a 4” insulated floor with truck wheel guide tracks mounted on top of the floor.

Controls on the No. 1038 include a digital programming temperature controller plus a paperless event recorder.


For more information, please contact: THE GRIEVE CORPORATION, 500 Hart Road, Round Lake, Illinois 60073-2835 USA. Phone: (847) 546-8225. Fax: (847) 546-9210. Web: www.grievecorp.com. Email: sales@grievecorp.com. Attention: Frank Calabrese.

Continue reading

500°F Truck Oven from Grieve

No. 913 is 500°F (260°C), truck oven from Grieve, currently used for curing rubber parts hanging from the oven’s ceiling at the customer’s facility. Workspace dimensions of this oven measure 48” wide x 52” deep x 96” high. 24 KW are installed in Nichrome wire tubular heating elements, while a 1000 CFM, 1-HP recirculating blower provides combination airflow.

Grieve 913 truck ovenThis Grieve truck oven has 4” insulated walls and an aluminized steel interior and exterior. The ceiling of the workspace is reinforced for 200 lb. load at customer support rack. It is sectioned to fit in a 5’ wide x 8’ deep x 6’8” high elevator.

Controls on the No. 913 include a digital indicating temperature controller, manual reset excess temperature controller with separate contactors, recirculating blower air flow safety switch and a 10” diameter circular chart recorder.

For more information, please contact: THE GRIEVE CORPORATION, 500 Hart Road, Round Lake, Illinois 60073-2835 USA. Phone: (847) 546-8225. Fax: (847) 546-9210. Web: www.grievecorp.com. Email: sales@grievecorp.com. Attention: Frank Calabrese.

Continue reading

600°F Truck Oven from Grieve

936

No. 936 is a 600°F (316°C) truck oven from Grieve, currently used for hi-temp processing of parts at the customer’s facility. Workspace dimensions of this oven measure 36” W x 36” D x 60” H. 24 KW are installed in Nichrome wire heating elements, while a 1500 CFM, 1-1/2 HP recirculating blower provides horizontal airflow to the workload.

This Grieve truck oven has 5” insulated walls, top-mounted heat chamber and Type 304 2B finish stainless steel interior. Features also include a stainless steel exterior with #4 brushed finish, solenoid operated door lock and safety equipment for handling flammable solvents, including explosion venting door hardware. The oven includes a 325 CFM powered forced exhauster plus motorized dampers on intake and exhaust for accelerated cooling.

Controls on No. 936 include a digital programming temperature controller and SCR power controller.

THE GRIEVE CORPORATION
500 Hart Road
Round Lake, IL  60073-2898
Phone:  (847) 546-8225
Fax:  (847) 546-9210
Web:  www.grievecorp.com
Email:  sales@grievecorp.com
Attention:  Frank Calabrese, VP

Continue reading

2000°F Gas-Fired, Heavy-Duty Furnace

No. 1042 is a 2000°F (1093°C), gas-fired heavy-duty furnace from Grieve, currently used for heat treating at the customer’s facility. Workspace dimensions of this furnace measure 30″ W x 60″ D x 30″ H.  750,000 BTU/HR are installed in four modulating natural gas burners with a floor mounted combustion air blower. Burners fire below hearth, with 9″ thick insulated walls comprising 5″ thick 2300°F ceramic fiber, 4″ 1900°F block insulation and 8 1/2″ floor insulation made from 4-1/2″ of 2300°F firebrick and 4” of 1900°F block insulation.

This Grieve furnace has two lanes of roller rails supported by firebrick piers and an air-operated platform with roller rails to bridge from loading table to workspace. Features include a 1/4” plate steel exterior reinforced with structural steel, 1/2″ steel faceplate at doorway and an air-operated vertical lift door.

Other features include safety equipment required by IRI, FM and National Fire Protection Association Standard 86 for gas-heated equipment plus a free-standing 390 CFM high-pressure combustion blower.

Controls on the No. 1042 include a digital indicating temperature controller and manual reset excess temperature controller with separate contactors.

THE GRIEVE CORPORATION
500 Hart Road
Round Lake, IL  60073-2898
Phone:  (847) 546-8225
Fax:  (847) 546-9210
Web:  www.grievecorp.com
Email:  sales@grievecorp.com
Attention:  Frank Calabrese, VP

Continue reading

550°F Belt Conveyor Oven from Grieve



No 866 Grieve Belt Conveyor OvenNo. 866 is a 550° (288°C) belt conveyor oven from Grieve, currently used for heat treating coiled spring steel at the customer’s facility. Workspace dimensions of this oven measure 18” W x 20’ D x 15” H. 60 KW are installed in Nichrome wire heating elements to heat the oven, while a 4200 CFM, 3 HP recirculating blower provides vertical downward airflow to the workload.

The oven travel comprises an 1-1/2’ long open belt loading zone, 20’ long insulated heat zone with recirculated airflow, 1’ long open zone, plus a 12’ long cooling zone and an 1-1/2’ long open unloading zone.

This Grieve belt conveyor oven features 4” insulated walls, aluminized steel exterior and stainless steel interior. Two 12” diameter tubeaxial fans, each driven by a ½ HP motor, push/pull air through cooling zone and a 12” wide, ½” x ½” high carbon steel flat wire conveyor belt with 1/3 HP motor drive, variable from 16 to 44 inches per minute, are also onboard the oven.

Controls on the No. 866 include a 10” diameter circular chart recording temperature controller and a manual reset excess temperature controller.



For more information, please contact:

THE GRIEVE CORPORATION
500 Hart Road
Round Lake, Illinois 60073-2835 USA
Phone: (847) 546-8225
Fax: (847) 546-9210.
Web: www.grievecorp.com.
Email: sales@grievecorp.com.
Attention: Frank Calabrese.

Continue reading

850ºF Heat Treating Belt Conveyor Oven from Grieve

867 for Heat Treating Metal Springs | #GrieveCorpNo. 867 is an 850ºF (454ºC), gas-heated belt conveyor oven from Grieve, currently used for production heat treating of metal springs at the customer’s facility. Workspace dimensions of this oven measure 36” W x 18’ D x 15” H. 800,000 BTU/HR are installed in a natural gas burner to heat the oven chamber, while a 12,500 CFM, 10-HP stainless steel recirculating blower provides vertical downward airflow to the workload.

The oven travel comprises a 3’ long open belt loading zone, 18’ long insulated heat zone with recirculated airflow, 3’ long open belt unloading zone and a 30” wide, Type 304 stainless steel woven wire conveyor belt with 3” high flex plate edges, driven by a ½-HP motor v-belt drive, variable from 1-19 IPM.

This Grieve belt conveyor oven features 7” thick insulated walls, aluminized steel exterior and interior, exhaust hoods over each end equipped with a 12” diameter tubeaxial fan, driven by a ½-HP motor, plus all safety equipment required by IRI, FM and NFPA Standard 86 for gas-heated equipment, including a 650 CFM, ½-HP powered forced exhauster.

Controls on No. 867 include a digital indicating temperature controller and 10” diameter circular chart recorder.

For more information, please contact:

THE GRIEVE CORPORATION
500 Hart Road
Round Lake, IL  60073-2898
Phone:  (847) 546-8225
Fax:  (847) 546-9210
Web:  www.grievecorp.com
Email:  sales@grievecorp.com
Attention:  Frank Calabrese, VP

Continue reading

1000°F Electric High Temperature Universal Oven for Cleaning and Heat Treating

818 Grieve (2014_02_19 02_56_07 UTC)Grieve Corporation introduces No. 818, a 1000°F high-temperature universal oven, currently in use for cleaning and heat treating fuel nozzles at a customer’s facility.

Workspace dimensions inside this unit measure 24” wide x 36” deep x 24” high.  24kW power is installed in Incoloy sheathed tubular heating elements.  A 1000 CFM, 3/4 HP recirculating blower provides a front-to-back horizontal “universal” airflow to completely surround the workload.

This Grieve oven features 8” thick insulated walls, an aluminized steel interior and exterior, plus inner and outer door gaskets.  The inner gasket seals directly against the door plug, while the other gasket seals directly against the front face of the oven for optimum seal integrity.  The unit accommodates up to seven shelves on 3” centers.

Standard equipment includes a digital indicating temperature controller, manual reset excess temperature controller with separate heating element control contactors, a recirculating blower airflow safety switch and a UL Listed control panel, top-mounted to minimize floor space requirements.

All standard universal ovens by Grieve meet the requirements of National Fire Protection Association Standard 86, Industrial Risk Insurers, Factory Mutual and OSHA Standards.

This unit was entirely designed, engineered, built and full tested by Grieve.

For more information, please contact:

THE GRIEVE CORPORATION
500 Hart Road
Round Lake, IL  60073-2898
Phone:  (847) 546-8225
Fax:  (847) 546-9210
Web:  www.grievecorp.com
Email:  sales@grievecorp.com
Attention:  Frank Calabrese, VP

Continue reading

Special Vertical Airflow Cabinet Oven for Heat Treating

Grieve No. 814No. 814 is a 500ºF (260ºC), electrically-heated cabinet oven from Grieve, currently used for various plastic and metal part heat treating operations at the customer’s facility.  Workspace dimensions of this oven measure 22” W x 21” D x 85” H.  18 kW are installed in Nichrome wire  tubular elements to heat the oven chamber, while a 750 CFM, 3/4-HP recirculating blower provides a vertical downward airflow to the workload.

This Grieve cabinet oven features 4” insulated walls, aluminized steel exterior and interior, three integral metal shelves, plus all safety equipment required by NFPA Standard 86 for handling flammable solvents, including a powered forced exhauster, airflow safety switch and purge timer.

Other controls on No. 814 include a fused disconnect switch, digital temperature controller and manual reset excess temperature controller.

For more information, please contact:

THE GRIEVE CORPORATION
500 Hart Road
Round Lake, IL  60073-2898
Phone:  (847) 546-8225
Fax:  (847) 546-9210
Web:  www.grievecorp.com
Email:  sales@grievecorp.com
Attention:  Frank Calabrese, VP

Continue reading
