60” x 120” workpiece capacity complements state-of-the-industry laser and machine control technology
Han-Kwang USA announces immediate availability of its new Series PL, specifically Model PL 3015, a long bed, 2D flying optic laser system capable of handling 60” wide x 120” long workpieces. With a long bed gantry arrangement, less motion is required on the machine, providing greater working stability and reduced maintenance requirements.
Model PL 3015 features rapid single axis speed of 4724 ipm, simultaneous X-Y axis speed of 7900 ipm and maximum cutting speed of 1181 ipm, all with positioning accuracies better than +/- 0.004” per 118” of travel and repeatability to 0.001”. A dual shuttle pallet system is onboard to maintain optimum productivity in processing.
This Han-Kwang laser system features a powerful Panasonic CO2 laser resonator in 2, 2.5, 4 and 6 KW versions, as well as the builder’s patented beam radius control, which optimizes the beam diameter for various material substrates and thickness variations, resulting in improved part quality. Additionally, the constant beam delivery system on the Han-Kwang laser provides better consistency in the beam quality at the focal point. These features and benefits to the user are delivered in the S5 high-speed cutting head found on the machine. The advanced Han-Kwang sensing board and head design improve cutting speed for all sheet metals, according to the manufacturer.
A plasma monitoring unit constantly tracks cut errors to further reduce out-of-tolerance conditions in the cutting cycle, while a built-in lens crack sensor monitors the state of lens contamination, with instant alerts through the onboard Siemens CNC to provide operators and maintenance personnel useful and immediate alarm notifications.
All machine mechanical movements and laser cutting operations are controlled by the powerful Siemens SINUMERIK 840D CNC. With its open architecture, 10GM hard drive and plain language commands, the CNC enables faster start-up and reduced time to first part for the programmers and operators alike. Further, a remote service support feature allows online communication to the CNC manufacturer for troubleshooting assistance.
An optional rotary axis is available for tube cutting up to 12” OD with this Han-Kwang laser system. Fully automated materials handling systems, pallet towers and other equipment for production improvement are also offered by the company.
For more information, the name of a local Han-Kwang dealer or to arrange a demonstration, please contact:
HAN-KWANG USA INC. 1120 Garfield Street Lombard, IL 60148 Phone: 630-916-0200 Fax: 630-916-0300 Web: www.hankwangus.com Email: salesusa@hankwang.co.kr Attention: Robert Won or Erik Kim
Siemens CNC controls all machine movements, allows remote service support
Editor note: Robert Won, director for North American operations, is available for interviews to discuss the company, its laser technology and other aspects of the industry. Han-Kwang is Korea’s largest laser builder and the company has embarked on an aggressive marketing effort in North America.
Agency contact: Tim Daro Bernard & Company tdaro@bernardandcompany.com 847-934-4500
Continue readingOver 400 customers attend Sominn event to see metalworking machines, meet company representatives.
Han-Kwang USA, a leading supplier of CO2 lasers and automated handling equipment for metalcutting operations, attended the Open House held on July 21-22 by its dealer, Southern Minnesota Machinery Sales (Sominn) in Dodge Center, Minnesota, just south of the Twin Cities. Over 400 customers of this major machine dealer attended the event, where Han-Kwang’s Director of North American Operations, Robert Won, was present to discuss his company’s offerings. Highlighting the Han-Kwang presentation was the new PL-3015, a dual-shuttle table, 60” x 120” workpiece, long bed CNC laser, available in various KW power models.
Sominn is the Han-Kwang dealer for Minnesota, North Dakota, South Dakota and Eastern Iowa. The company sells and services Han-Kwang plate and tube lasers, as well as over 20 other leading brands of metalworking and fabricating machinery, including various waterjet, plasma cutting, press brake, shear, saw, bending and other equipment.
The open house was held at Sominn’s 30,000 square-foot showroom, with representatives from all their lines present to discuss the equipment needs of those in attendance. Sominn President J.J. Francis hosted the event, which drew attendees from this dealer’s entire territory, during the two days.
Sominn has been a major dealer in the area for 38 years and is a member of the Machinery Dealers National Association (MDNA).
Robert Won of Han-Kwang commented, “This was a first-class event, as customers could see the substantial inventory Sominn maintains and also learn about their full sales and service capability. We had many excellent inquiries about our lasers. Han-Kwang is proud to call Sominn our partner in this region.”
For more information on this dealer, please visit www.sominn.com.
For more information on lasers, the name of your local Han-Kwang dealer or to arrange a demonstration, please contact:
HAN-KWANG USA INC. 1120 Garfield Street Lombard, IL 60148 Phone: 630-916-0200 Fax: 630-916-0300 Web: www.hankwangus.com Email: salesusa@hankwang.co.kr
Attention: Robert Won or Erik Kim
Editor note: Robert Won, director for North American operations, is available for interviews to discuss the company, its laser technology and other aspects of the industry. Han-Kwang is Korea’s largest laser builder and the company has embarked on an aggressive marketing effort in North America.
Agency contact: Tim Daro Bernard & Company tdaro@bernardandcompany.com 847-934-4500
Continue reading60” x 120” workpiece capacity complements state-of-the-industry laser and machine control technology
Han-Kwang USA announces immediate availability of its new Series PS, specifically Model PS 3015, a short gantry, 2D flying optic laser system capable of handling 60” wide x 120” long workpieces. With the short gantry arrangement, operator vision is enhanced on the machine, plus the more compact design facilitates a high degree of regulation in the cutting process.
Model PS 3015 features rapid single axis speed of 4724 ipm, simultaneous X-Y axis speed of 7900 ipm, driven by twin servos on the gantry and maximum cutting speed of 1181 ipm, all with positioning accuracies better than +/- 0.004” per 118” of travel and repeatability to 0.001”. A dual shuttle pallet system is onboard to maintain optimum productivity in processing.
This Han-Kwang laser system features a powerful Panasonic CO2 laser resonator in 2.5, 4 and 6 KW versions, as well as the builder’s patented beam radius control, which optimizes the beam diameter for various material substrates and thickness variations, resulting in improved part quality. Additionally, the constant beam delivery system on the Han-Kwang laser provides better consistency in the beam quality at the focal point. These features and benefits to the user are delivered in the S5 high-speed cutting head found on the machine. The advanced Han-Kwang sensing board and head design improve cutting speed for all sheet metals, according to the manufacturer.
A plasma monitoring unit constantly tracks cut errors to further reduce out-of-tolerance conditions in the cutting cycle, while a built-in lens crack sensor monitors the state of lens contamination, with instant alerts through the onboard Siemens CNC to provide operators and maintenance personnel useful and immediate alarm notifications.
All machine mechanical movements and laser cutting operations are controlled by the powerful Siemens SINUMERIK 840D CNC. With its open architecture, 10GB hard drive and plain language commands, the CNC enables faster start-up and reduced time to first part for the programmers and operators alike. Further, a remote service support feature allows online communication to the CNC manufacturer for troubleshooting assistance.
An optional rotary axis is available for tube cutting up to 12” OD with this Han-Kwang laser system. Fully automated materials handling systems, pallet towers and other equipment for production improvement are also offered by the company.
For more information, the name of a local Han-Kwang dealer or to arrange a demonstration, please contact:
HAN-KWANG USA INC. 1120 Garfield Street Lombard, IL 60148 Phone: 630-916-0200 Fax: 630-916-0300 Web: www.hankwangus.com Email: salesusa@hankwang.co.kr Attention: Robert Won or Erik Kim
Editor note: Robert Won, director for North American operations, is available for interviews to discuss the company, its laser technology and other aspects of the industry. Han-Kwang is Korea’s largest laser builder and the company has embarked on an aggressive marketing effort in North America.
Continue readingShow attracts hundreds to see cost-effective solutions for laser cutting
Han-Kwang USA recently attended the Fabtech Mexico show, co-located with the Metalform and Weldmex shows. Over 8000 visitors per day were in attendance to see over 400 exhibitors and hundreds visited the Han-Kwang booth to watch the company’s plate laser, Model FS3015, in action. Onsite for this exhibition were Han-Kwang’s director of North American sales, Robert Won, as well as engineer Philip Kim and the company’s distributors in Mexico.
Mr. Won commented, “The Mexican market has been excellent for Han-Kwang. We’re assisted by a very strong distributor, who has an extensive sales and service network to cover the entire region with us. Our sales recently have been quite strong, because of the quality of our machines and the quality of our representation in Mexico. I believe this will continue to be a very good market for our plate and tube lasers into the future.”
The FS3015 is a 5’ x 10’ plate laser with shuttle tables, flying optic design, fast-axial flow type Panasonic resonator, S5 high-speed cutting head, twin servos for precise gantry motion and Siemens CNC, motors and drives to power and control the machine’s total operation. This plate laser is available in 2, 2.5, 4 and 6KW models to handle any type of plate cutting with speed and precision position accuracy to +/- 0.004” per 120” of travel. The machine also has automatic focus control with multi-pulse piercing technology, unique to Han-Kwang.
This machine was specifically chosen for display at the booth during Fabtech Mexico, because of its performance and value combination for the local market.
Han-Kwang enjoyed a very successful exhibition at Fabtech Mexico, held May 11-13
For more information or to arrange a visit to Han-Kwang for a demonstration, please contact:
HAN-KWANG USA INC. 1120 Garfield Street Lombard, IL 60148 Phone: 630-916-0200 Fax: 630-916-0300 Web: www.hankwangus.com Email: salesusa@hankwang.co.kr Attention: Robert Won, Eric Kim or Jane Lee
Agency contact: Tim Daro Bernard & Company tdaro@bernardandcompany.com 847-934-4500
Continue readingLasers under power for demonstration, test cuts, time studies and more; new facility will also house full application engineering, parts and service departments
Han-Kwang USA announces the opening of its new 13,000 square-foot Chicago-area facility with showroom for laser machine demonstrations, as well as application engineering, parts and service departments. Typically, the new showroom will house multiple plate and tube cutting laser machines for customer use in test cuts and time studies, plus interested parties can see these powerful CO2 lasers in action, when considering a purchase or investigating laser technology for their shops and in-house fabrication processes.
In announcing this opening, Han-Kwang USA VP Robert Won commented, “This showroom is a further step in our company’s long-term commitment to the North American market. We have worked hard over the recent years to develop our business, build relationships with our North American dealer network and especially support our customers with the latest technology and application assistance.”
The parts department is fully stocked with all key consumable and mechanical components for the full range of Han-Kwang lasers currently in the field and offered by the company, including the new PS, PL and TL plate and tube cutters.
Additional key personnel at this new facility include Eric Kim, operations manager, and Jane Lee, administrative assistant.
For more information or to arrange a visit, please contact: HAN-KWANG USA INC. 1120 Garfield Street Lombard, IL 60148 Phone: 630-916-0200 Fax: 630-916-0300 Web: www.hankwangus.com Email: salesusa@hankwang.co.kr Attention: Robert Won, Eric Kim or Jane Lee.
Agency contact: Tim Daro Bernard & Company tdaro@bernardandcompany.com 847-934-4500
Release: HAN-KWANG USA INC.
Date: April 1, 2010
Continue reading
Automated loading and parts handling system complement state-of-the-industry laser and machine control technology
Han-Kwang USA announces immediate availability of its new Model TL 6015, a tube cutting laser system capable of handling 24’ long, 6.5” diameter workpieces up to 1/4” wall thickness in mild steel and 0.200” in stainless steel. Equipped with a powerful 2.5KW Panasonic laser and a versatile Siemens 840D CNC to control all functions of the machine, the TL 6015 can significantly increase the tube production in any department or shop, especially when used with Han-Kwang’s proprietary “Flex 3D” tube cutting software . The unit comprises an automatic bundle loading system with tube V-support, auto-centering rotary chucking system, laser cutting station and automatic parts removal station.
Maximum positioning speed on this new laser system is 4700 ipm for the X-
axis and 120 rpm for the rotary A-axis. Max acceleration rate is 1G, while the laser beam is precisely controlled by the unique Han-Kwang Auto Focus Control (AFC). This AFC technology allows the machine to automatically adjust the focal length of the cutting lens to accommodate variations in the materials being processed or changes in material feed, which eliminates the downtime normally associated with manual adjustments.
A new generation of sensing board in the S5 laser cutting head on the TL 6015 translates into faster cutting speeds on round, square or rectangular shapes.
In a recent design modification, the entire loading section of the machine has been enclosed, as depicted in the attached illustration.
For more information or to arrange a demonstration, please contact:
HAN-KWANG USA INC. Phone: 630-916-0200 Web: www.hankwang.com
Agency contact: Tim Daro Bernard & Company tdaro@bernardandcompany.com www.bernardandcompany.com
Continue readingHAN-KWANG INTRODUCES THREE NEW LASERS
Korean giant enters U.S. market with big splash at recent FABTECH show
At the recent FABTECH show in Chicago, the largest builder of laser machines in Korea introduced three new CO2 lasers for metal fabrication, including two plate/sheetmetal machines and one tube/pipe cutter. Reaction from the attendees was very positive and interest quite high, as all three machines ran continuously throughout the show.
Details on the machines follow here:
Han-Kwang takes the next step in its technology development with the introduction of the Series PL laser system. Incorporating our unique Beam Radius Control (BRC) and Constant Beam Delivery System (CBDS), Series PL also features the newest Han-Kwang laser technology, our S5 High-Speed Cutting Head, which significantly increases the cutting speeds on all sheet metals, up to 1120 IPM for 20ga mild steel and 790 IPM for 16ga stainless. In addition, the practical machine design and highly functional, ergonomic controls make the Series PL the new benchmark in long gantry laser systems.
Features
• BRC-Beam Radius Control
Through optimizing the beam diameter for each different material and thickness, cut quality is greatly increased.
• CBDS-Constant Beam Delivery System
By keeping the entire length of the beam delivery constant over the work area, beam quality at the cutting focal point is enhanced.
• S5 High Speed Cutting Head
Adopting the new generation of the sensing board and the cutting head means cutting speeds for sheet metals such as mild steel, stainless and aluminum are dramatically increased.
• PMU-Plasma Monitoring Unit
Constantly monitors cut error such as plasma and restart with faster piercing and more stable cutting quality.
• LCS-Lens Crack Sensor
Built-in LCS monitors the status of lens contamination to give maintenance personnel instant alerts for replacement.
• Rotary axis for tube cutting
Cuts tubes up to 12” OD to give your operation substantial flexibility in work strategies
• Siemens SINUMERIK 840D with 15” touch screen
Use of the highest powered CNC, with open architecture and simplified set-up with plain language commands, plus full interface to your shop programming/monitoring network, means greater productivity at the machine and overall in your operation
• Onboard high-efficiency air filter & dehumidifier with monitoring window
Utilizing its own power supply, this unique Han-Kwang system guarantees contamination-free cutting and unmatched consistency.
—————————————————————–
Han-Kwang takes the next step in its technology development with the introduction of the Series PS laser system. Incorporating our unique Beam Radius Control (BRC) and Constant Beam Delivery System (CBDS), Series PS also features the newest Han-Kwang laser technology, our S5 High-Speed Cutting Head, which significantly increases the cutting speeds on all sheet metals, up to 1120 IPM for 20ga mild steel and 790 IPM for 16ga stainless. In addition, the practical machine design and highly functional, ergonomic controls make the Series PS the new benchmark in short gantry laser systems.
Features
• BRC-Beam Radius Control
Through optimizing the beam diameter for each different material and thickness, cut quality is greatly increased.
• CBDS-Constant Beam Delivery System
By keeping the entire length of the beam delivery constant over the work area, beam quality at the cutting focal point is enhanced.
• S5 High Speed Cutting Head
Adopting the new generation of the sensing board and the cutting head means cutting speeds for sheet metals such as mild steel, stainless and aluminum are dramatically increased.
• PMU-Plasma Monitoring Unit
Constantly monitors cut error such as plasma and restart with faster piercing and more stable cutting quality.
• LCS-Lens Crack Sensor
Built-in LCS monitors the status of lens contamination to give maintenance personnel instant alerts for replacement.
•Siemens SINUMERIK 840D with 15” touch screen
Use of the highest powered CNC, with open architecture and simplified set-up with plain language commands, plus full interface to your shop programming/monitoring network, means greater productivity at the machine and overall in your operation
• Onboard high-efficiency air filter & dehumidifier with monitoring window
Utilizing its own power supply, this unique Han-Kwang system guarantees contamination-free cutting and unmatched consistency.
—————————————————————–
Han-Kwang takes the next step forward in fully automated tube cutting systems with the introduction of the new Series TL. All our experience in tube cutting technology has joined with our expertise in the design and engineering of materials handling systems to offer users a very affordable yet superior quality and highly flexible system for virtually non-stop production of tubes and shapes. Coupled with our exclusive Han-Kwang ProDesign 3D CAM/CAM software and fully controlled by a single CNC workstation, Series PL will provide unmatched productivity to your operation.
Highlight of the Series TL is our highly advanced S5 cutting head, which combines superior measurement and sensing mechanisms to change from signal size to pulse monitoring, resulting in optimum cutting conditions. This new cutting head design is further enhanced by Han-Kwang’s quick piercing nitrogen-injection technology. Smaller holes, quicker ambient area cooling and a substantial reduction in hole-to-hole cutting time will all benefit your production and your bottom line.
Features
• BRC-Beam Radius Control
• CBDS-Constant Beam Delivery System
• Magazine-fed bundle tube loading system
• Tube V-support system
• Rotary chucking system
• Completely enclosed safety workstation with automatic doors and light barrier system
• Panasonic 2500W resonator
• Cutting capability to 21’ long x 6” diameter
• Material thicknesses to 0.25” mild steel and 0.2” stainless
• Siemens SINUMERIK 840D, the highest-powered CNC on the market for maintaining complete processing cycle control by a single operator, using touchscreen and simple language commands
• ProDesign 3D CAD/CAM enabling fast adjustments to the production scheduling to yield maximum productivity from the system
• Unique Han-Kwang air filtration and dehumidifying system for cleaner cuts and more operator-friendly environment
For more information on this emerging new player in the laser machine market, please contact:
Robert Won, Director/North American Sales
HANKWANG USA, INC. Web: www.hankwang.com
Agency contact: Tim Daro Bernard & Company www.bernardandcompany.com
Automated loading and parts handling system complement state-of-the-industry laser and machine control technology
Han-Kwang USA announces immediate availability of its new Model TL 6015, a tube cutting laser system capable of handling 24’ long, 6.5” diameter workpieces up to 1/4” wall thickness in mild steel and 0.200” in stainless steel. Equipped with a powerful 2.5KW Panasonic laser and a versatile Siemens 840D CNC to control all functions of the machine, the TL 6015 can significantly increase the tube production in any department or shop, especially when used with Han-Kwang’s proprietary “Flex 3D” tube cutting software . The unit comprises an automatic bundle loading system with tube V-support, auto-centering rotary chucking system, laser cutting station and automatic parts removal station.
Maximum positioning speed on this new laser system is 4700 ipm for the X-
axis and 120 rpm for the rotary A-axis. Max acceleration rate is 1G, while the laser beam is precisely controlled by the unique Han-Kwang Auto Focus Control (AFC). This AFC technology allows the machine to automatically adjust the focal length of the cutting lens to accommodate variations in the materials being processed or changes in material feed, which eliminates the downtime normally associated with manual adjustments.
A new generation of sensing board in the S5 laser cutting head on the TL 6015 translates into faster cutting speeds on round, square or rectangular shapes.
In a recent design modification, the entire loading section of the machine has been enclosed, as depicted in the attached illustration.
For more information or to arrange a demonstration, please contact:
HAN-KWANG USA INC. Phone: 630-916-0200 Web: www.hankwang.com
Agency contact: Tim Daro Bernard & Company tdaro@bernardandcompany.com www.bernardandcompany.com
